| Model Name |
ProID 101 |
| Processor |
32-bit ARM Cortex-M0 48MHz |
| Read Range |
0-3 cm
(The application environment influences the performance of the card and the card's reading distance it covers.)
|
| Reading Frequency |
125kHz ID card / 13.56MHz IC card |
| Reading Time |
≤0.3s |
| Card Type |
ID (Standard) / IC Card (ProID 101, ProID102, ProID103)
IC&CPU & NFC (ProID 104) |
| Input Port |
External LED Control
External Buzzer Control |
| Casing Material |
Aluminum Alloy
Tempered glass surface |
| Power |
Operating Voltage DC 7 to 13V
Current Draw ≤350mA 5V
ProID104: DC 12V 1A
Current Draw ≤300mA |
| Output Format |
ProID 101: Wiegand 26-bit or 34-bit (Adjustable); RS485 |
| Status Indicator |
Pulsing White Standby Light
Red and Green LEDs |
| Operating Temperature |
-20 °C ~ 65 °C |
| Supported Panel |
InBio, InBio pro, C3 Series |
| Operating Humidity |
10% ~ 90% RH
Non-Condensing |
| Buzzer |
Beep |
| Ingress Protection Rating |
IP65 (Only ProID101, ProID 102 and ProID 103)
IK04 |
| Operating Environment |
Indoor & Outdoor |
| Dimension |
ProID101: 111 x 44.5× 11mm |
| Mounting Method |
Mullion mount |
| Colour |
Black & White |
| Certifications |
ISO9001, ISO14001, CE, FCC |
