| Video |
|---|
| Imaging Device |
1/2.8" 2MP CMOS: each CH |
| Effective Pixels |
1945(H)x1097(V): each CH |
| Min. Illumination |
Color: 0.05lux(F1.6,30 IRE)
BW: 0Lux(IR LED on) |
| Lens |
|---|
| Focal Length (Zoom Ratio) |
3.2~10mm(3.1x) motorized varifocal |
| Max. Aperture Ratio |
F1.6(Wide)~F2.9(Tele) |
| Angular Field of View |
H: 109.0°(Wide)~33.2°(Tele), V: 57.4°(Wide)~18.7°(Tele), D: 132.0°(Wide)~38.0°(Tele) |
| Min. Object Distance |
0.5m(1.64ft) |
| Focus Control |
Simple focus |
| Pan / Tilt / Rotate |
|---|
| Pan / Tilt / Rotate Range |
Remote adjustment (Max. 200cycles)
Pan : 0~360˚, Tilt : 30~80˚, Rotate : 0~90˚ |
| Operational |
|---|
| IR Viewable Length |
30m |
| Camera Title |
Displayed up to 85 characters |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, HLC, WDR, SSDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
SSNRⅤ |
| Digital Image Stabilization |
Support |
| Defog |
Support |
| Motion Detection |
8ea, 8point polygonal zones |
| Privacy Masking |
32ea, polygonal zones
- Color: Grey/Green/Red/Blue/Black/White
- Mosaic |
| Gain Control |
Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| LDC |
Support |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2~1/12,000sec) |
| Video Rotation |
Flip, Mirror, Hallway view(90˚/270˚) |
| Analytics |
Defocus detection, Directional detection, Fog detection, Face detection, Motion detection, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Audio detection |
| Alarm I/O |
Input 1ea / Output 1ea |
| Alarm Triggers |
Analytics, Network disconnect, Alarm input |
| Alarm Events |
File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC at event triggers
Alarm output
Handover |
| Audio In |
Selectable(mic in/line in)
Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
| Audio Out |
Line out, Max.output level: 1Vrms |
| Network |
|---|
| Ethernet |
RJ-45(10/100/1000BASE-T) |
| Video Compression |
H.265/H.264: Main/Baseline/High, MJPEG |
| Resolution |
1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
| Max. Framerate |
H.265/H.264: Max. 60fps/50fps(60Hz/50Hz)
MJPEG: Max. 30fps/25fps(60Hz/50Hz) |
| Smart Codec |
Manual(5ea area), WiseStreamⅡ |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(20 users) / Multicast
Multiple streaming(Up to 10 profiles) |
| Audio Compression |
G.711 u-law /G.726 Selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
AAC-LC: 48Kbps at 16KHz |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP |
| Security |
HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access log
802.1X Authentication(EAP-TLS, EAP-LEAP) |
| Edge Storage |
Micro SD/SDHC/SDXC 4slot 512GB(Each CH) |
| Application Programming Interface |
ONVIF Profile S/T
SUNAPI(HTTP API)
Wisenet open platform |
| Web Viewer |
Supported OS: Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12
Recommended Browser: Google Chrome
Supported Browser: MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OS X only) |
| Memory |
5GB RAM, 1280MB Flash |
| Environmental |
|---|
| Operating Temperature / Humidity |
-40°C~+55°C(-40°F~+131°F) / Less than 90% RH |
| Storage Temperature / Humidity |
-50°C~+60°C(-58°F~+140°F) / Less than 90% RH |
| Certification |
IP66, IK10, NEMA4X |
| Electrical |
|---|
| Input Voltage |
HPoE, 12VDC |
| Power Consumption |
Max : 42W Typical : 28W |
| Mechanical |
|---|
| Color / Material |
White / Aluminum |
| RAL Code |
RAL9003 |
| Product dimensions / weight |
∮315x145.9mm / 5.2kg |
