Hanwha Wisenet 4K AI Indoor Dome Camera, H.265, 30fps, WDR, IR, IK10, 4.5-10mm - HAN-PND-A9081RF

Description

Description

 Special Order

This device is available for special orders only and is not always locally available. Please contact our team by phone or email for more details on its availability and acquisition.

Hanwha's HAN-PND-A9081RF categorises what it sees into broad categories such as 'person', 'face', 'vehicle' and 'licence plate'. Delving deeper, Wisenet artificial intelligence algorithms are quickly and accurately able to identify the different attributes of the objects within the camera's field of view. This camera is also equipped with a BestShot feature which ensures that only the most suitable images of classified objects are sent to the storage server. Users have the option to set the image resolution at 2MP for full video streaming or use the BestShot feature to minimise bandwidth and storage requirements. Store operators are able to combine the HAN-PND-A9081RF with the Retail Insight v2.0 business intelligence application, to analyse what is happening within their stores, with the camera using attribution identification to help track customer demographics, age and gender. All of these features make this camera suitable for a range of applications.

Features

  • Max. 4K resolution
  • 0.05Lux at F1.6 (colour), 0Lux (B/W, IR LED on)
  • Day and night (ICR), WDR (120dB)
  • H.265, H.264, MJPEG codec, WiseStream II
  • Video analytics based on AI: object detection and classification (person, face, vehicle, licence plate)
  • Compatible with Wisenet Retail Insight v2.0 for business intelligence
  • BestShot
  • Age/gender based people counting
  • Heatmap
  • Queue management
  • Modular structure for easy installation
Datasheet
Tech Specs
Camera
Sensor 8 MP 1/1.8" CMOS
Focal Length 4.5 to 10mm
Maximum Aperture f/1.6 to 2.65
Zoom Optical: 2.2x
Lens Field of View Horizontal: 101.4 to 45.5°
Vertical: 53.6 to 25.5°
Diagonal: 120.7 to 52.3°
IR Cut Filter Mechanical
Day/Night Yes
Minimum Illumination Color: 0.05 Lux
B&W: 0 Lux
Shutter Speed 1/12,000 to 1/5 Seconds
Camera Angle Adjustment Horizontal: 0 to 360°
Vertical: -45 to 85°
Video
Streaming Resolution 3840 x 2160 at 30 fps
Supported Video Compression H.264, H.265, MJPEG
Multi-View Streaming Yes, 3 Streams
Audio
1- or 2-Way Audio Two-Way
Audio Formats AAC-LC, G.711, G.726
Built-In Mic No
Networking
Security Digest Authentication, HTTPS, IEEE 802.1X, IP Address Filtering, User Access Log
Supported Protocols ARP, Bonjour, DDNS, DHCP, DNS, FTP, HTTP, ICMP, IGMP, IPv4/v6, LLDP, NTP, QoS Layer 3 DiffServ, RTCP, RTP, RTSP, SMTP, SNMP v1/v2c/v3 (MIB-II), SRTP, SSL/TLS, TCP, UDP, UPnP
System Integration
Application Programming Interface (API) ONVIF Profiles G, S & T, SUNAPI (HTTP API), Wisenet Open Platform
Analytics Object Detection & Classification (Person, Face, Vehicle, License Plate), Face Mask Detection, Directional Detection, Digital Auto Tracking, Enter/Exit, Loitering, Virtual Line, Social Distancing Detection, Defocus Detection, Motion Detection (8 Polygonal Zones), Appear/Disappear, Tampering, Audio Detection, Sound Classification, Shock Detection, People Counting (Age/Gender Based), Queue Management, Heat Map
Event Trigger Yes
Event Action Recording, Notification, Alarm
Data Streaming Yes
Environmental
Operating Temperature -13 to 122°F / -25 to 50°C
Storage Temperature -58 to 140°F / -50 to 60°C
Operating Humidity 0 to 90%
IP Rating IP52
IK Rating IK10
General
Memory 4096 MB RAM / 512 MB Flash
Media/Memory Card Slot Dual Slot: microSD/microSDHC/microSDXC [256 GB Maximum]
Pan/Tilt None
Alarm I/O 1 / 1
I/O Connections 1 x RJ45
1 x Power
1 x Micro-USB
1 x BNC
IR Range 98.4' / 30 m
Video Management Software Wisenet Retail Insight v2.0, Wisenet WAVE 4.1, Wisenet SSM (v2.10.8 or Later)
Supported Languages Czech
Dutch
English
French
German
Greek
Hungarian
Italian
Japanese
Korean
Polish
Portuguese
Russian
Simplified Chinese
Spanish
Swedish
Turkish
Internal Storage None
External Storage Options NAS
Power Source DC, PoE 802.3at (30 W)
Power Consumption PoE+: 16 W
DC: 14 W
Material of Construction Aluminum
Dimensions ø: 8.1 x H: 6.4" / ø: 205.0 x H: 163.0 mm
Weight 4.3 lb / 1.95 kg
Packaging Info
Package Weight 7.07 lb
Box Dimensions (LxWxH) 17.4 x 11.5 x 7.8"

Read more

Hanwha Wisenet 4K AI Indoor Dome Camera, H.265, 30fps, WDR, IR, IK10, 4.5-10mm - HAN-PND-A9081RF

Product form

SKU: PND-A9081RF

$1,798.00 Incl. GST

    • Guaranteed secure & safe checkout.

      paypal
    • FREE Express Courier Shipping for all orders over $100
    • 30-Day Returns Policy
    • Back to Base Australian Warranty & Tech Support
