Hanwha Wisenet 2MP Outdoor Bullet Camera, H.265, 30fps, IK10, 30m IR, 2.8-12mm - HAN-QNO-6070R

Description

Description

 Special Order

This device is available for special orders only and is not always locally available. Please contact our team by phone or email for more details on its availability and acquisition.

The advanced compression technology of WiseStream that is incorporated into the Hanwha HAN-QND-6010R can reduce bandwidth by up to 50% and when combined with H.265, the bandwidth efficiency can be improved by up to 75% compared to the current H.264 technology. Defocus detection helps to recognise images that are out of focus and significantly improves efficiency. Lens distortion correction easily removes imperfections in images, making image quality impeccable. Users can also adjust the optimal focus remotely via network which reduces the installation time of the camera. The HAN-QND-6010R offers a seamless solution for small to medium sized applications and ultimately minimises time and costs for installation.

Features
  • Max. 2MP resolution
  • 2.8 - 12mm (4.3x) varifocal lens
  • Max. 30fps at 2MP at all resolutions (H.265/H.264)
  • H.265, H.264, MJPEG codec supported, multiple streaming, motion detection, tampering, defocus detection
  • Micro SD/SDHC/SDXC memory slot (max. 128GB), PoE/ 12V DC
  • 30m IR
  • Hallway view
  • LDC support (lens distortion correction)
Datasheet
Tech Specs
Video
Imaging Device 1/2.9" 2.19M CMOS
Total Pixels 2,000(H) x 1,121(V)
Effective Pixels 1,984(H) x 1,105(V)
Scanning System Progressive
Min. Illumination Color : 0.095Lux (30IRE), B/W : 0Lux (IR LED on)
Lens
Focal Length (Zoom Ratio) 2.8 ~ 12mm (4.3x) manual
Max. Aperture Ratio F1.4
Angular Field of View H : 103.8˚ ~ 32.4˚ / V : 53.7˚ ~ 18.4˚ / D : 121.9˚ ~ 37.1˚
Focus Control Manual
Lens Type DC auto iris
Mount Type Board type
Operat ional
IR Viewable Length 30m (98.43ft)
Camera Title Off / On (Displayed up to 20 characters per line)
- W/W : English / Numeric / Special characters
- China : English / Numeric / Special / Chinese characters
- Common : Multi-line (Max. 5), Color (Grey / Green / Red / Blue / Black / White), Transparency, Auto scale by resolution
Day & Night True Day & Night
Backlight Compensation Off / BLC / WDR
Wide Dynamic Range 120dB
Digital Noise Reduction SSNR (Off / On)
Motion Detection Off / On (4ea polygonal zones)
Privacy Masking Off / On (6ea rectangular zones)
Gain Control Off / Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor
LDC (Lens Distortion Correction) Off / On (5 levels with min / max)
Electronic Shutter Speed Minimum / Maximum / Anti flicker
Flip / Mirror Flip / Mirror / Hallway view
Intelligent Video Analytics Motion detection with metadata, Tampering, Defocus deteciton
Alarm I/O Input 1 / Output 1
Alarm Triggers Motion detection, Tampering detection, SD card error, NAS error, Alarm input, Defocus detection
Alarm Events File upload via FTP and E-mail, Local storage recording at event, Notification via E-mail, External output
Pixel Counter Support (Plug-in viewer only)
Netw ork
Ethernet RJ-45 (10/100BASE-T)
Video Compression Format H.265, H.264, MJPEG
Resolution 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 720 x 576, 720 x 480, 640 x 480, 320 x 240
Max. Framerate H.265/H.264 : Max. 30fps at 2M all resolutions, MJPEG : 15fps
Smart Codec WiseStream
Video Quality Adjustment H.265/H.264 : Target bitrate level control, MJPEG : Quality level control
Bitrate Control Method H.265/H.264 : CBR or VBR, MJPEG : VBR
Streaming Capability Multiple streaming (Up to 3 profiles)
Audio I/O Line in
Audio Compression Format G.711 u-law / G.726 selectable
G.726 (ADPCM) 8KHz, G.711 8KHz, G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps
Audio Communication Uni-directional audio
IP IPv4, IPv6
Protocol TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
Security HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication
Streaming Method Unicast / Multicast
Max. User Access 6 users at unicast mode
Storage micro SD/SDHC/SDXC max. 128G, NAS
- Motion images recorded in the SD memory card can be downloaded
- Manual recording at local PC
Application Programming Interface ONVIF Profile S/G, SUNAPI (HTTP API)
Webpage Language English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungary, Greek
Web Viewer Supported OS : Windows 7, 8.1, 10, Mac OS X 10.9, 10.10, 10.11
Plug-in free Webviewer
- Supported Browser : Google Chrome 47, MS Edge 20
Plug-in Webviewer
- Supported Browser : MS Explore 11, Mozilla Firefox 43, Apple Safari 9 * Mac OS X only
Central Management Software SmartViewer
Environmental
Operating Temperature / Humidity -30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH * Start up should be done at above -20°C (-4°F)
Storage Temperature / Humidity -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
Ingress Protection IP66
Vandal Resistance IK10
Electr ical
Input Voltage / Current PoE (IEEE802.3af, Class3) / 12V DC
Power Consumption Max. 8W (PoE), Max. 7W (12V DC)
Mechanical
Color / Material Dark gray / Metal
Dimensions (WxH) Ø70.0 x 246.0mm (Ø2.76" x 9.69") (Without sunshield)
Weight 730g (1.61 lb)

Read more

Hanwha Wisenet 2MP Outdoor Bullet Camera, H.265, 30fps, IK10, 30m IR, 2.8-12mm - HAN-QNO-6070R

Product form

SKU: QNO-6070R

$334.00 Incl. GST
