| VIDEO |
| Imaging Device |
1/2.3" 12M CMOS |
| Effective Pixels |
3008(H) x 3008(V) |
| Min. Illumination |
Color: 0.39 Lux (F2.2, 1/30sec) |
| Video Out |
CVBS : 1.0 Vp-p / 75O composite, 720x480(N), 720x576(P), for Installation |
| LENS |
| Focal Length (Zoom Ratio) |
1.08mm fixed focal |
| Max. Aperture Ratio |
F2.2 |
| Angular Field of View |
H: 187° / V: 187° / D: 187° |
| Min. Object Distance |
0.5m(1.64ft) |
| OPERATIONAL |
| Camera Title |
Displayed up to 85 characters |
| Day & Night |
Auto(Electrical) |
| Backlight Compensation |
BLC, WDR, SSDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
SSNR. |
| Motion Detection |
4ea, polygonal zones |
| Privacy Masking |
6ea, Rectangle zones
- Color: Grey/Green/Red/Blue/Black/White |
| Gain Control |
Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2~1/12,000sec) |
| Video Rotation |
Flip, Mirror |
| Analytics |
Defocus detection, Motion detection, Tampering |
| Business Intelligence |
People counting, Heatmap |
| Alarm Triggers |
Analytics, Network disconnect |
| Alarm Events |
File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC or NAS recording at event triggers |
| NETWORK |
| Ethernet |
RJ-45(10/100BASE-T) |
| Video Compression |
H.265/H.264: Main/High, MJPEG |
| Resolution |
Overview : 3008x3008, 640x640
Double panorama: 2560x1280, 1920x960, 1280x640, 1024x512, 640x320
Single panorama: 3200x800, 2560x640, 1920x480, 1280x320, 1024x256
Quad view: 2560x1920, 1920x1440, 1280x960, 1024x768, 640x480 |
| Max. Framerate |
H.265/H.264:
Overview-Max. 30fps/25fps@3008x3008(60Hz/50Hz),
Double panorama-Max. 28fps/25fps@3200x800(60Hz/50Hz)
Single panorama-Max. 28fps/25fps@2560x1280(60Hz/50Hz)
MJPEG: Max. 5fps(60Hz/50Hz) |
| Smart Codec |
Manual(5ea area), WiseStreamⅡ |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(6 users) / Multicast
Multiple streaming(Up to 3 profiles) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour |
| Security |
HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access log
802.1X Authentication(EAP-TLS, EAP-LEAP)
Device Certificate(Hanwha Techwin Root CA) |
| Edge Storage |
Micro SD/SDHC/SDXC 1slot 256GB |
| Application Programming Interface |
ONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platform |
| Web Viewer |
Supported OS: Windows 7, 8.1, 10, Mac OS X 10.12, 10.13, 10.14
Recommended Browser: Google Chrome
Supported Browser : MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OS X only) |
| Memory |
2048MB RAM, 256MB Flash |
| ENVIRONMENTAL |
| Operating Temperature / Humidity |
-10°C ~ +40°C(+14°F ~ +104°F) / Less than 90% RH |
| Storage Temperature / Humidity |
-50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH |
| Certification |
IP42 |
| ELECTRICAL |
| Input Voltage |
PoE(IEEE802.3af, Class3) |
| Power Consumption |
PoE: Max 7.7W, typical 6.4W |
| MECHANICAL |
| Color / Material |
White / Plastic |
| RAL Code |
RAL9003 |
| Product dimensions / weight |
Ø99x49mm, 370g |
| DORI |
| Detect (25PPM/ 8PPF) |
34.9m(114.49ft) |
| Observe (63PPM/ 19PPF) |
13.9m(45.60ft) |
| Recognize (125PPM/ 38PPF) |
7.0m(22.96ft) |
| Identify (250PPM/ 76PPF) |
3.5m(11.48ft) |
