Built-in System |
Operating System |
Android 8.0 |
CPU |
Dual-core A53 + dual-core A73 |
RAM |
4 GB |
ROM |
32 GB |
LCD Panel |
Panel Dimensions |
65-inch; 75-inch; 86-inch |
Brightness |
65-inch: 350 cd/m²; 75-inch: 400 cd/m²; 86-inch: 400 cd/m² |
Contrast |
1200: 1 |
Resolution |
3840 (H ) × 2160 (V) |
Aspect Ratio |
16: 9 |
Backlight |
DLED |
Lifespan |
30,000 hours |
Viewing Angle |
H: 178°; V: 178° |
Touchscreen |
Touch Technology Type |
Infrared touch technology |
Touch Points |
20 |
Writing Mode |
Finger + Pen |
Response Time |
<10 ms |
Valid Touch |
2 mm |
Communication Mode |
USB |
Camera |
Pixel |
8 MP (live view) |
Auto Control |
Auto white balance |
Distortion |
≤5% |
Max. Resolution |
4K@30 fps |
Field of View |
H: 104°; V: 70.2°; D: 112.7° |
Speaker |
Built-in Speaker |
3 |
Power |
Full frequency: 15 W × 2; bass: 15 W × 1 |
Microphone |
Pick-up Distance |
Far-field sound pickup: 6 m–8 m (19.69 ft–26.25 ft) |
Number of Microphones |
8 |
AGC |
Yes |
Echo Cancellation |
Yes |
Intelligent Noise Filtering |
Yes |
Polar Pattern |
Omnidirectional |
Fingerprint |
Fingerprint Capacity |
256 |
Fingerprint Resolution |
508 DPI |
FAR |
<0.001% |
FRR |
<0.1% |
Function |
Operating System of External Module |
Windows 7/8/10;Android |
WiFi |
Dual-band 2.4G/5G |
Wi-Fi Hotspot |
Dual-band 2.4G/5G; supports enabling Hotspot and Wi-Fi at the same time |
Device Ports |
Light Sensor |
1 |
Front Button |
1 × power button |
Front Ports |
1 × HDMI IN; 1 × touch; 2 × USB3.0 |
Network Port |
2 × RJ-45 |
Wi-Fi |
1 × Wi-Fi; 1 × Hotspot |
USB |
3 × USB3.0; 1 × USB2.0 |
RS-232 |
1 × RS-232 |
Video Input |
3 × HDMI IN; 1 × DP; 1 × MINI AV IN; 1 × MINI YPBPR; 1 × VGA IN |
Video Output |
1 × HDMI OUT |
Audio Input |
1 × 3.5 mm; 1 × MIC IN |
Audio Output |
1 × 3.5 mm (EarPhone OUT); 1 × SPDIF |
IrDA |
1 |
Others |
2 × Touch |
General |
Power Supply |
100–240 VAC, 50/60 Hz |
Power Consumption |
65-inch: 150 W; 75-inch: 300 W; 86-inch: 400 W |
Product Dimensions |
65-inch: 1,504.5 mm × 952.5 mm × 86.1 mm (59.23" × 37.5" × 3.39");
75-inch: 1,715.5 mm × 1,066.7 mm × 85.4 mm (67.54" × 42.00" × 3.36");
86-inch: 1,960.8 mm × 1,204.7 mm × 85.4 mm (77.20" × 47.43" × 3.36") |
Packaging Dimensions |
65-inch: 1,660 mm × 1,045 mm × 245 mm (65.35" × 41.14" × 9.65")
75-inch: 1,880 mm × 1,160 mm × 280 mm (74.02" × 45.67"" × 11.02")
86-inch: 2,140 mm × 1,340 mm × 280 mm (84.25" × 52.76" × 11.02") |
Operating Temperature |
–10 °C to +45 °C (+14 °F to +113 °F) |
Storage Temperature |
–20 °C to +55 °C (–4 °F to +131 °F) |
Operating Humidity |
10%–90% |
Storage Humidity |
10%–90% |
Product Material |
Metal casing |
Glass |
Anti-dazzle tempered glass with a hardness of 7 on the Mohs scale |
Casing Color (Frame/Rear) |
Bottom: Space gray; top/left/right: black |
Net Weight |
65-inch: 44 kg (97.00 lb)
75-inch: 54 kg (119.05 lb)
86-inch: 66.75 kg (147.16 lb) |
Gross Weight |
65-inch: 56 kg (123.46 lb)
75-inch: 71.5 kg (157.63 lb)
86-inch: 87.05 kg (191.91 lb) |
Installation |
Wall mount; floor-standing |
