Camera Features |
Image sensor |
1/2.7" Progressive CMOS |
Resolution |
SD: 1280 x 960
HD: 2560 x 1920
|
Lens Types |
Fixed-focal |
Focal Length |
f = 2.8 mm |
Aperture |
F2.0 |
Iris |
Fixed iris |
Field of View |
103° (Horizontal)
76° (Vertical)
134° (Diagonal)
|
Camera Movement |
Pan 350° Tilt: 80° Rotate:±175° |
Shutter Speed |
1/5 sec. to 1/32,000 sec. |
Day/Night |
Yes |
IR Cut Filter |
Yes |
IR Range |
30 meters |
WDR Technology |
WDR Pro |
Minimum Illumination |
0.06 lux @ F2.0 (Color)
0.01 lux @ F2.0 (B/W)
0 lux with IR illumination on
|
Onboard Storage |
MicroSD/SDHC/SDXC card slot
(Built-in 256GB industrial SDCard)
|
Standard Video Settings |
Frame Rate |
15FPS |
Video Streaming Settings |
HD Video 2560 x 1920@15fps 1.2Mbps upload
SD Video 1280 x 960@15fps 300Kbps upload
|
Standard Audio Settings |
|
Audio |
One-way Audio |
Interface |
Built-in microphone |
Effective Range |
5 meters |
Power and Network |
|
Power input |
IEEE 802.3af PoE Class 0 |
Power Consumption |
Max. 6.3 W (IR on)
Max. 3.9 W (IR off)
|
Connectivity |
RJ-45 cable connector for 10/100 Mbps PoE network connection |
RTSP |
WebRTC, ARP, DHCP, DNS, HTTP, HTTPS, ICMP, IPv4, IPv6, NTP, QoS (CoS/DSCP),
RTSP/RTP/RTCP, SSL, TCP/IP, TLS 1.2, UDP
|
Users |
Up to 6 clients
*Live viewing for 6 clients
*live viewing up to 4 clients and playback 2 clients)
|
Security |
Secure boot
Signed firmware
HTTPS/TLS encryption
Video encryption
|
Interface |
10 Base-T/100 Base-TX Ethernet (RJ-45)
*It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard.
|
General |
Operating Temperature |
Starting Temperature:
0°C ~ 50°C (32°F ~ 122°F)
Working Temperature:
-10°C ~ 50°C (14°F ~ 122°F) (IR off)
-10°C ~ 45°C (14°F ~ 113°F) (IR on)
|
Humidity |
90% RH (non-condensing) |
Certifications |
EMC: CE (EN55032, EN55024 Class B, E50121-4), FCC (FCC Part 15 Subpart B Class B),
RCM (AS/NZS CISPR32 Class B), VCCI (VCCI-CISPR 32 Class B);
Safety : UL (UL62368-1), CB (IEC/EN 62368-1, IEC/EN 60950-22, IEC/EN 62471)
|
Warranty |
120-month |
Included Accessories |
Quick installation guide, alignment sticker, screw pack |
Mechanical |
Weight |
350g |
Dimensions |
Ø 130 x 95 mm |
Body |
Plastic |
AI Analytics |
Audio detection |
Yes |
Tampering detection |
Yes |
People Analytics |
Intrusion detection, Line crossing detection,Loitering detection, Scene Search |
Vehicle Analytics |
Intrusion detection, Line crossing detection,Loitering detection, Scene Search |
Object Analytics |
Unattended object detection,Missing object detection |
