| Audio Capability |
Two-way Audio |
Audio Compression |
G.711, G.726 |
Audio Interface |
External Microphone input
External line output |
| Effective Range |
5 meters |
Network |
Users |
Live viewing for up to 10 clients |
Security |
Access list, digest authentication, HTTPS , IEEE 802.1x, password protection, secure boot, signed firmware, Trend Micro IoT Security (brute force attack event, cyberattack event, quarantine event), user access log, user account management |
| Protocols |
802.1X, ARP, Bonjour, CIFS/SMB, DDNS, DHCP, DNS, FTP/SFTP, HTTP/HTTPS, ICMP, IGMPv3, IPv4, IPv6, NTP, PPPoE, QoS (CoS/DSCP), RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS 1.2, UDP, UPnP |
Interface |
10 Base-T/100 Base-TX Ethernet
*It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard. |
Solution Integration |
| VADP Package |
Trend Micro IoT Security |
Alarm and Event |
Event Trigger |
Audio detection, camera tampering detection, cybersecurity events (brute force attack event, cyberattack event, quarantine event), digital input, manual trigger, periodical trigger, recording notification, SD card life expectancy, shock detection, system boot |
Event Action |
Camera:
Event notification via digital output, email, HTTP, FTP, NAS server, SD card
File upload via email, HTTP, FTP, NAS server, SD card
ANPR Software:
Socket client, socket server, onvif event, digital output trigger, HTTP, FTP, wiegand protocol supported
VaxALPR Software:
FTP, JSON, XML, TCP Server, TCP client, wiegand protocol supported |
General |
Connectors |
RJ-45 cable connector for Network/PoE connection
Audio line in
Audio line out
AC 24 V
DC 12 V
Digital input *2
Digital output *2 (dry contact, Load voltage 30V AC/ DC, Load current 1A max) |
| LED Indicator |
System power and status indicator |
| Power Input |
AC 24V, DC 12V, IEEE 802.3at PoE Class 4 |
| Power Consumption |
PoE: Max. 26 W
DC 12V: Max. 29.5 W
AC 24V: Max. 28 W |
| Dimensions |
118 x 118 x 294 mm |
| Weight |
1.3 kg |
| Certifications |
EMC: CE (EN 55032 Class A, EN 55035), UKCA (BS EN 55032:2015+A11: 2020, BS EN 55035:2017+A11:2020, BS EN IEC 62368-1:2020+A11:2020), RCM (AS/NZS CISPR 32 Class A), FCC (FCC Part 15 Subpart B Class A), ICES (ICES-003 Issue 7), VCCI (VCCI-CISPR 32 Class A); Safety: UL (UL 62368-1 Ed.3), CB (IEC/EN 62368-1, EN 62471); Environment: IK10 (IEC 62262), IP66/67 (IEC 60529); IA: BIS (IS 13252, IEC 60950-1), BSMI (EMC: CNS15936) |
| Operating Temperature |
Starting Temperature: -10°C ~ 60°C (14°F ~ 140°F)
Working Temperature: -30°C ~ 60°C (-22°F ~ 140°F) |
| Humidity |
90% |
System Requirements |
| Operating System |
Microsoft Windows 10/8/7
Mac 10.12 (Chrome only) |
| Web Browser |
Chrome 58.0 or above
Internet Explorer 10/11 |
| Other Players |
VLC: 1.1.11 or above |
Included Accessories |
| Packing Contents |
Quick installation guide, alignment sticker, L-shaped wrench, screw pack, waterproof accessory pack, sunshield |
| Optional Accessories |
Please refer to Accessory Selection Guide |
