| Audio Capability |
Two-way audio (Full duplex) |
Audio Compression |
G.711, G.726 |
Audio Interface |
External line input
External line output |
| Effective Range |
5 meters |
Network |
Users |
Live viewing for up to 10 clients |
Security |
Access list, Digest authentication, HTTPS , IEEE 802.1x, password protection, Secure boot, Signed firmware, Trend Micro IoT Security (brute force attack event, cyberattack event, quarantine event), User access log, User account management |
| Protocols |
802.1X, ARP, Bonjour, CIFS/SMB, DDNS, DHCP, DNS, FTP/SFTP, HTTP, HTTPS, ICMP, IGMPv3, IPv4, IPv6, NTCIP, NTP, PPPoE, QoS (CoS/DSCP), RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS 1.2, UDP, UPnP |
Interface |
10 Base-T/100 Base-TX Ethernet (RJ-45)
*It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard. |
AI Analytics |
Compute Capability |
SoC with built-in hardware deep learning accelerator |
Vision Object Analytics |
Object Detection: People, Vehicle (4-wheeled, 2-wheeled); Attribute Extraction: People (gender, clothing color, bag, hat), Vehicle (bike, bus, car, motorcycle, truck, color); Re-Search Extraction; Path Extraction |
Application available with license |
Deep Learning VCA (Smart Motion Detection, Smart Tracking Advanced)
Smart Tracking Advanced (Intrusion detection, Loitering detection, Line crossing detection, Face detection, Unattended object detection, Missing object detection) |
Solution Integration |
Applications |
Trend Micro IOT Security (3-year free trial) |
Alarm and Event |
Event Trigger |
Audio detection, camera tampering detection, cybersecurity events (brute force attack event, cyberattack event, quarantine event), digital input, manual trigger, motion detection, periodical trigger, recording notification, SD card life expectancy, smart tracking advanced trigger, system boot, preset reached |
Event Action |
Event notification via audio clip, camera link, digital output, email, HTTP, FTP/SFTP, NAS server, SD card, push notification
File upload via email, HTTP, FTP/SFTP, NAS server, SD card |
General |
Connectors |
RJ-45 cable connector for 10/100Mbps Network/PoE connection
Audio line input
Audio line output
AC/DC 24V power input
Digital input *2
Digital output *1
RS-485*1 |
LED Indicator |
System power and status indicator |
| Power Input |
AC 24V, DC 48V, IEEE 802.3 bt Class 6 PoE
(Simultaneous Power Redundancy Supported) |
| Power Consumption |
PoE
Max: 51W/26W (IR on/off)
DC 48V
Max: 51W/26W (IR on/off)
AC 24V
Max: 51W/26W (IR on/off) |
| Dimensions |
256 x 336 mm |
| Weight |
7.3 kg |
| Certifications |
EMC: CE (EN 55032 Class A, EN55035, EN50121-4), UKCA (BS EN 55032: 2015 +A11: 2020, BS EN 55035: 2017), FCC (FCC Part 15 Subpart B Class A), IC (ICES-003:2020 Issue7, Class A), RCM (AS/NZS CISPR 32 Class A), VCCI (VCCI-CISPR 32 Class A); Safety: UKCA (BS EN 62368-1:2014+A11:2017), UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 60950-22, IEC/EN 62471); Environment: IK10 (IEC 62262), IP66 (IEC 60529), NEMA (NEMA 250 Type 4X); IA: BIS (IS 13252), BSMI |
| Operating Temperature |
Starting Temperature:
-40°C ~ 55°C (-40°F ~ 131°F)
Working Temperature:
-40°C ~ 55°C (-40°F ~ 131°F) (IR off)
-40°C ~ 50°C (-40°F ~ 122°F) (IR on) |
| Humidity |
98% RH (non-condensing) |
System Requirements |
| Operating System |
Microsoft Windows 10/8/7
Mac 10.12 (Chrome only) |
| Web Browser |
Chrome 58.0 or above
Internet Explorer 10/11 |
| Other Players |
VLC: 1.1.11 or above |
Included Accessories |
| Packing Contents |
Wall mount bracket, Screw pack, Screws and anchors, T10 and T25 L-wrench, Waterproof round cap, Quick installation guide, Terminal blocks (for DI/DO audio, AC/DC/GND wires, RS485), Ground wire. |
| Optional Accessories |
Please refer to Accessory Selection Guide |
