| Audio Capability |
Two-way audio (Full duplex) |
Audio Compression |
G.711, G.726, MPEG-2 AAC-LC |
Audio Interface |
Built-in microphone
External microphone input
External line output |
| Effective Range |
5 meters |
Network |
Users |
Live viewing for up to 10 clients |
Security |
Access list, Account block , Audit log, Configurable password strength protection, CSRF protection, Digest authentication, HTTPS , IEEE 802.1x, Secure boot, Session timeout, Signed firmware, Trend Micro IoT Security (Brute force attack event, Cyberattack event, Quarantine event), User access log, User account management |
| Protocols |
802.1X, ARP, Bonjour, CIFS/SMB, DDNS, DHCP, DNS, FTP/SFTP, HTTP/HTTPS, ICMP, IGMPv3, IPv4, IPv6, NTP, PPPoE, QoS (CoS/DSCP), RTSP/RTP/RTCP, SMTP, SNMP, SSL, TCP/IP, TLS 1.2, UDP, UPnP |
Interface |
10 Base-T/100 Base-TX Ethernet
*It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard. |
ONVIF |
Profile G, S, T supported, specification available at www.onvif.org |
AI Analytics |
Compute Capability |
SoC with built-in hardware deep learning accelerator |
Application |
Deep Learning VCA (Smart Motion Detection, Smart VCA)
Smart Motion Detection (Five-window video motion detection, People detection, Vehicle detection, Time filter), Smart VCA (Intrusion detection, Loitering detection, Line crossing detection, Unattended object detection, Missing object detection, Face detection, Crowd detection |
Application available with license |
Running detection, Parking Violation Detection, Restricted Zone Detection
Support for more analytic applications and free trial, please visit vivotek.com/video-analytics |
AI-powered Image Enhancement |
Smart IR III |
Solution Integration |
VADP Package |
Stratocast, Trend Micro IoT Security (3-year free trial) |
Alarm and Event |
Event Trigger |
Audio detection, camera tampering detection, cybersecurity events (brute force attack event, cyberattack event, quarantine event), digital input, manual trigger, motion detection, periodical trigger, recording notification, SD card life expectancy, shock detection, system boot |
Event Action |
Event notification via audio clip, camera link, digital output, email, HTTP, FTP/SFTP, NAS server, SD card
File upload via email, HTTP, FTP/SFTP, NAS server, SD card |
General |
Connectors |
RJ-45 cable connector for 10/100 Mbps PoE network connection
Audio line input
Audio line output
DC 12V power input
AC 24V power input
Digital input*3
Digital output*3
Micro USB |
LED Indicator |
System power and status indicator |
| Power Input |
AC 24V, DC 12V, IEEE 802.3at PoE Class 4 (Power Redundancy) |
Power Consumption |
PoE: Max. 19.38/15.80 W (IR on/off)
DC 12V: Max. 15.84/12.26 W (IR on/off)
AC 24V: Max. 16.52/12.94 W (IR on/off) |
| Dimensions |
ø 153 x 283 mm |
| Weight |
1.87 kg |
| Certifications |
EMC: CE (EN 55032/EN 55035 Class A, EN 50121-4), FCC (FCC Part 15 Subpart B Class A), UKCA (BS EN 55032/BS EN 55035 Class A),RCM (AS/NZS CISPR 32 Class A), VCCI (VCCI-CISPR 32 Class A), IC (ICES-003 Issue 7); Safety: UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 60950-22, IEC/EN 62471), LVD, (EN 62368-1), UKCA (BS EN IEC 62368-1);; Environment: IK10 (IEC 62262), IP66/67 (IEC 60529), NEMA (NEMA 250 Type 4X), IEC 60068-2-11; IA: BIS (IS 13252), BSMI (EMC: CNS 15936, Safety: CNS 15598-1) |
| Operating Temperature |
Starting Temperature:
-30°C ~ 60°C (-22°F ~ 140°F)
Working Temperature:
-50°C ~ 60°C (-58°F ~ 140°F) (IR off)
-50°C ~ 50°C (-58°F ~ 122°F) (IR on) |
| Humidity |
98% RH (non-condensing) |
System Requirements |
| Operating System |
Microsoft Windows 10/8/7
Mac 10.12 (Chrome only) |
| Web Browser |
Chrome 58.0 or above |
| Other Players |
VLC: 1.1.11 or above |
Included Accessories |
| Packing Contents |
Quick installation guide, product labels, alignment sticker, L-shaped wrench, screw pack, waterproof accessory pack, sunshield, I/O cable, adaptor plate, conduit bracket |
| Optional Accessories |
Please refer to Accessory Selection Guide |
