Networking Specifications |
| Gigabit Ethernet RJ45 PoE Port |
4 |
| Gigabit Ethernet RJ45 port |
2 |
| Gigabit SFP Port |
2 |
| Ethernet Performance |
| Switching Bandwidth |
16 Gbps |
| MAC Address |
4 K |
| Buffer Memory |
128 KB |
| Jumbo Frame |
9 K |
| Transmission Method |
Store and Forward |
| Auto-MDI/MDI-X, Auto-Negotiation |
Supported |
| Standards |
| IEEE 802.3 10-BASE-T (Ethernet) |
Supported |
| IEEE 802.3u 100-BASE-TX (Fast Ethernet) |
Supported |
| IEEE 802.3ab 1000-BASE-T (Gigabit Ethernet) |
Supported |
| IEEE 802.3af/at |
Supported |
| IEEE 802.3z 1000-BASE-X (Gigabit Ethernet) |
Supported |
| IEEE 802.3x Flow Control (Full-Duplex Flow Control) |
Supported |
| IEEE 802.3af Power over Ethernet |
Supported |
| IEEE 802.3at Power over Ethernet Plus |
Supported |
| Power Specifications |
| Power Input Voltage |
PW1: 48 ~ 56VDC
PW2: 48 ~ 56VDC
Redundant Power Backup |
| Max. PoE Output Power /Per PoE Port |
54VDC, Max. 30W |
| |
|
| Total PoE Power Budget |
120W |
| IEEE 802.3af/at |
Supported |
| Power Pin Assignment |
1/2(+), 3/6(-) |
| PoE PD Auto Detection |
Supported |
| Surge Protection/Per PoE Port |
12KV |
| General |
| Operating Temperature |
-40°C ~ 75°C (-40°F ~ 167°F) |
| Storage Temperature |
-40°C ~ 85°C (-40°F ~ 185°F) |
| Operating Humidity |
5%-95% non-condesing |
| Dimensions |
172 (L) x 132 (W) x 39 (H) mm |
| Weight |
0.7 kg |
| Warranty |
24 months |
| Certifications |
| EMS |
EN55024, IEC 61000-4-2(ESD), IEC 61000-4-3(RS), IEC 61000-4-4(EFT), IEC 61000-4-5(Surge), IEC 61000-4-6(CS), IEC 61000-4-8(PFMF), IEC 61000-4-11(DIP) |
| EMI |
EN 55032, EN 61000-3-2, EN 61000-3-3, AS/NZS CISPR 32, FCC Part15 Class A, VCCI |
| Safety |
LVD, EN60950 |
| Vibration |
IEC 60068-2-6 |
| Shock |
IEC 60068-2-27 |
| Freefall |
IEC 60068-2-32 |
