IPC3638SS-ADF28KMC-I1 |
IPC3638SS-ADF40KMC-I1 |
Camera |
Sensor |
1/2.8", 8.0 megapixel, progressive scan, CMOS |
Minimum Illumination |
Colour: 0.001 Lux (F1.0, AGC ON) 0 lux with IR on |
Day/Night |
IR-cut filter with auto switch (ICR) |
Shutter |
Auto/Manual, 1 ~ 1/100000s |
Adjustment angle |
Pan: 0° ~ 360°, Tilt: 0° ~ 80°, Rotate: 0° ~ 360° |
WDR |
130dB |
S/N |
>56dB |
Lens |
Lens type |
2.8mm@F1.0 |
4.0mm@F1.0 |
Iris |
Fixed |
Field of View (H) |
106.5° |
92° |
Field of View (V) |
57.9° |
51° |
Field of View (D) |
132° |
106° |
DORI |
DORI Distance |
Lens (mm) |
Detect (m) |
Observe (m) |
Recognize (m) |
Identify (m) |
2.8 |
86.9 |
34.8 |
17.4 |
8.7 |
4.0 |
124.1 |
49.7 |
24.8 |
12.4 |
Illuminator |
IR Range |
Up to 30m (98.4 ft) |
Warm Light Range |
Up to 30m (98.4 ft) |
Wavelength |
850nm |
IR On/Off Control |
Auto/Manual |
Video |
Video Compression |
Ultra 265, H.265, H.264, MJPEG |
H.264 code profile |
Baseline profile, Main profile, High profile |
Frame Rate |
Main Stream:8MP (3840*2160), Max 30fps; 5MP (3072*1728), Max 30fps; 4MP (2560*1440), Max 30fps; 1080P (1920*1080), Max 30fps; 720P (1280*720), Max 30fps; Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360, Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; |
Video Bit Rate |
128 Kbps~16 Mbps |
U-code |
Support |
OSD |
Up to 8 OSDs |
Privacy Mask |
Up to 4 areas |
ROI |
Up to 8 areas |
Video Stream |
Triple streams |
Image |
Auto Scene Match (ASM) |
Support(Only WDR) |
Digital Noise Reduction |
2D/3D DNR |
White Balance |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
Smart IR |
Smart IR Support |
Flip |
Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise |
Dewarping |
N/A |
HLC |
Supported |
BLC |
Supported |
Defog |
Defog Digital Defog |
Intelligent |
Smart intrusion prevention |
Support false alarm filtering: Cross Line detection, Intrusion detection, Enter Area detection, Leave Area detection |
Statistical Analysis |
People counting, support people flow counting and crowd density monitoring |
Events |
Basic Detection |
Motion detection, Ultra motion detection, Tampering alarm, Audio detection |
General Function |
Watermark, IP address filtering, tampering alarm, alarm input, alarm output, access Policy, ARP protection, RTSP authentication, user authentication |
Audio |
Audio Compression |
G.711U, G.711A |
Audio Bitrate |
64 Kbps |
Two-way audio |
Supported |
Suppression |
Supported |
Sampling Rate |
8KHZ |
Storage |
Edge Storage |
Micro SD, up to 256 GB |
Network Storage |
ANR, NAS(NFS) |
Network |
Protocols |
IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP,SSL/TLS, SSH |
Compatible Integration |
ONVIF (Profile S, Profile G, Profile T) , API,SDK |
User/Host |
Up to 32 users. 3 user levels: administrator,common user and operator |
Security |
Password protection; Strong password; HTTPS encryption; Export operation logs; Basic and digest authentication for RTSP; Digest authentication for HTTP; TLS 1.2; WSSE and digest authentication for ONVIF |
Client |
EZStation EZView EZLive |
Web Browser |
Plug-in required live view: IE 10 and above, Chrome 45 and above, Firefox 52 and above, Edge 79 and above |
Plug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above |
Interface |
Audio I/O |
Input: impedance 35kΩ; amplitude 2V [p-p]
Output: impedance 600Ω; amplitude 2V [p-p]
|
Alarm I/O |
1/1 |
RS485 |
N/A |
Built-in Mic |
Support |
Built-in Speaker |
Support |
WIFI |
N/A |
Network |
1 * RJ45 10M/100M Base-TX Ethernet |
Video Output |
N/A |
Certifications |
EMC |
CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020) FCC (FCC CFR 47 part15 B, ANSI C63.4-2014) |
Safety |
CE-LVD (EN 62368-1) CB (IEC 62368-1) UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1) |
Environment |
CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU) |
Protection |
IP67 (IEC 60529) |
General |
Power |
DC 12V±25%, PoE (IEEE 802.3af) |
Power consumption: Max 10.0W |
Power Interface |
Ø 5.5mm coaxial power plug |
Dimensions (Ø x H) |
Φ129 x 118mm (Ø5.1” x 4.7”) |
Weight |
0.69kg (1.53lb) |
Material |
Metal |
Working Environment |
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
Storage Environment |
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing |
Surge Protection |
4KV |
Reset Button |
Support |
