Shutter |
Auto/Manual, 1 ~ 1/100000s |
Minimum Illumination |
Colour: 0.003Lux (F1.6, AGC ON) 0Lux with IR |
Day/Night |
IR-cut filter with auto switch (ICR) |
Digital Noise Reduction |
2D/3D DNR |
S/N |
>56dB |
IR Range |
Up to 40m (131ft) IR range |
Wavelength |
850nm |
IR On/Off Control |
Auto/Manual |
Defog |
Digital Defog |
WDR |
120dB |
Video |
Video Compression |
Ultra 265, H.265, H.264, MJPEG |
H.264 code profile |
Baseline profile, Main Profile, High profile |
Frame Rate |
Main Stream: 8MP (3840*2160), Max 20fps;5MP (3072*1728), Max 30fps; 4MP (2560*1440), Max30fps; 1080P (1920*1080), Max 30fps; Sub Stream: 1080P (1920*1080), Max 30fps;720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; |
Video Bit Rate |
128 Kbps~16 Mbps |
OSD |
Up to 8 OSDs |
Privacy Mask |
Up to 4 areas |
ROI |
Up to 8 areas |
Motion Detection |
Up to 4 areas |
Image |
White Balance |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
Digital noise reduction |
2D/3D DNR |
Smart IR |
Support |
Flip |
Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise |
Dewarping |
Supported |
HLC |
Supported |
BLC |
Supported |
Audio |
Audio Compression |
G.711 |
Suppression |
Supported |
Sampling Rate |
8KHZ |
Storage |
Edge Storage |
Micro SD, up to 256GB |
Network Storage |
ANR |
Network |
Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL,SNMP |
Compatible Integration |
ONVIF (Profile S, Profile G, Profile T), API |
Client |
EZStation EZView EZLive |
Web Browser |
Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below |
Plug-in free live view: Chrome 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ |
Interface |
Built-in Mic |
Supported |
Network |
1 RJ45 10M/100M Base-TX Ethernet |
Certifications |
Certifications |
CE: EN 60950-1 UL: UL60950-1 FCC: FCC Part 15 |
General |
Power |
DC 12V±25%, PoE (IEEE 802.3af) |
Power consumption: Max 9.0W |
Dimensions (Ø x H) |
?129 x 110mm (Ø5.1” x 4.3”) |
Net Weight |
0.69kg (1.52lb) |
Material |
Metal |
Working Environment |
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ?95% RH (non-condensing) |
Strorage Environment |
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ?95% RH (non-condensing) |
Surge Protection |
6KV |
Ingress Protection |
IP67 |
Vandal Resistant |
IK10 |
Reset Button |
Supported |
