Description
Engineered by Uniview, one of the world's leading video surveillance innovators, Uniarch devices combine convenience, durability, and cost-efficiency. Designed to provide optimal security solutions to small and medium applications, it is a perfect system for those looking for a simple, reliable, feature-rich, and affordable solution.
- Authorised Uniarch Dealer, Australian Stock, No Grey Imports!
- Uniarch 3 years Manufacturer Warranty!
- Free Express Courier Shipping!
Uniarch Tri-Guard - Combining the visual clarity of ColourHunter, the algorithm of Smart Intrusion Protection, and the added security of Active-Deterrence features, the Tri-Guard series offers a well-rounded security solution in every device. These features work together to provide reliable 24/7 surveillance whilst also minimizing false alarms caused by waving branches and waving leaves. On top of that, it discourages intruders with its built-in speakers and active deterrence. Developed and manufactured to abide by Uniview's strict standard for quality and functionality, these devices will provide an intelligent and reliable surveillance security solution to protect you, your family, and your property.
Features
- High quality image with 8MP, 1/2.8"CMOS sensor
- 8MP(3840*2160)@20fps; 5MP(3072*1728)@30/25fps; 4MP(2560*1440)@30/25fps; 2MP(1920*1080)@30/25fps
- Ultra 265, H.265, H.264, MJPEG
- Smart intrusion prevention, include cross line, intrusion, enter area, leave area detection
- Based on target classification, smart intrusion prevention significantly reduce false alarm caused by leaves, birds and lights etc., accurately focus on human and, motor vehicle and non-motor vehicle
- Supports sound and light alarm linkage. When Smart intrusion prevention is triggered, the camera links sound alarm and light linkage.
- 120dB true WDR technology enables clear image in strong light scene
- Support 9:16 Corridor Mode
- Built-in Mic and Speaker
- Smart IR, up to 30m (98ft) IR distance
- Supports 256 G Micro SD card
- IP67 protection
More Info
Uniarch Tri-Guard - Your Intelligent Security System
Many video security cameras face real-world challenges like:
- Delayed and incomplete alert information.
- False Alarms caused by wind and pets.
- Lack of colour and clarity in a dark environment.
UNV Tri-Guard technology innovates by combining Smart Intrusion Prevention (SIP), ColorHunter and Active Deterrence. It’s designed to prevent crimes at night - It can not only alert when events happen, but also get colour information in a low-light environment.
Core Technologies - Security Through Synergy
Active Deterrence - Ward off intruders via alarms through the built-in speakers.
Smart Intrusion Protection - Significantly reduces false alarms caused by leaves, birds and lights etc., accurately focusing on humans and vehicles.
Colorhunter - Colour details in a dark environment.
Smart LED: automatic intensity adjustment prevents overexposure.
Two Warm LEDs: further complementary light distance.
Friendly Lighting: ColorHunter IP camera uses warm LEDs that are friendly to human eyes.
Camera with UNV ColorHunter Technology
Standard Infrared Camera
Dual-Way Talk - This function helps the guards to monitor and communicate to more areas on time using the camera's built-in microphone and speakers.
Two Light Modes - On-demand visual clarity and active deterrence.
Standard Infrared - Consumes less energy and minimizes storage consumption.
Warm Infrared LED Lights - Increase colour and scene clarity, provides deterrence.
Uniarch Security Camera: 8MP Turret Tri-Guard - IPC-T1P8-AF28KC Datasheet Download
If you have any questions, please email us at support@SpyMonkey.com.au and let's build a system customized to your preference.
Send us an Email! Fill out a Quote Form! Chat with us via Live Chat!
Videos
Tech Specs
Uniarch Security Camera: 8MP Turret Tri-Guard - IPC-T1P8-AF28KC
| IR Range |
Up to 30m (98ft) IR range |
| Wavelength |
850nm |
| IR On/Off Control |
Auto/Manual |
| Video |
| Video Compression |
Ultra 265,H.265, H.264, MJPEG |
| H.264 code profile |
Baseline profile, Main Profile |
| Frame Rate |
Main Stream: 8MP (3840*2160), Max 20fps; 5MP (3072*1728), Max 30fps; 4MP (2560*1440), Max 30fps; 1080P (1920*1080), Max 30fps; Sub Stream: 1080P (1920*1080), Max 30fps;720P (1280*720), Max 30fps; 640*360,Max 30fps; D1 (720*576), Max 30fps; 2CIF (704*288), Max 30fps; CIF (352*288), Max 30fps; Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF (704*288), Max 30fps; CIF (352*288), Max 30fps; |
| Video Bit Rate |
128 Kbps~16 Mbps |
| U-code |
Supported |
| ROI |
Up to 8 areas |
| Video Stream |
Triple streams |
| OSD |
Up to 8 OSDs |
| Privacy Mask |
Up to 4 areas |
| Image |
| White Balance |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Image Setting |
Image rotation, brightness, saturation, contrast, sharpness, gain adjustable by web browser |
| Digital noise reduction |
2D/3D DNR |
| Smart IR |
Supported |
| Flip |
Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise |
| Dewarping |
Supported |
| HLC |
Supported |
| BLC |
Supported |
| Defog |
Digital Defog |
| Intelligent |
| Smart intrusion Prevention |
Support false alarm filtering: Line crossing detection, Intrusion detection, Region entrance detection, Region exit detection |
| Events |
| Basic Detection |
Motion detection, tampering alarm, audio detection |
| General Function |
Watermark, IP address filtering, tampering alarm, access policy, ARP protection, RTSP authentication, user authentication |
| Audio |
| Audio Compression |
G.711 |
| Audio Bitrate |
64 Kbps |
| Two-way Audio |
Supported |
| Suppression |
Supported |
| Sampling Rate |
8 KHZ |
| Storage |
| Edge Storage |
Micro SD, up to 256 GB |
| Network Storage |
ANR, NAS(NFS) |
| Network |
| Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS ,RTMP,SSL/TLS, SSH |
| Compatible Integration |
ONVIF (Profile S, Profile G, Profile T), API,SDK |
| User/Host |
Up to 32 users. 2 user levels: administrator and common user |
| Security |
Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF |
| Web Browser |
Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below |
| Plug-in free live view: Chrome 57.0+, Firefox 58.0+, Edge 16+ |
| Interface |
| Audio I/O |
N/A |
| Alarm I/O |
N/A |
| RS485 |
N/A |
| Built-in Mic |
Support |
| Built-in Speaker |
Support |
| WIFI |
N/A |
| Network |
1 RJ45 10M/100M Base-TX Ethernet |
| Video Output |
N/A |
| General |
| Power |
DC 12V±25%, PoE (IEEE802.3 af) |
| Power consumption: Max 10.5 W |
| Power Interface |
Ø 5.5mm coaxial power plug |
| Dimensions (Ø x H) ) |
Φ111 x 95mm (Φ4.4” x 3.7”) |
| Weight |
0.48kg (1.058lb) |
| Material |
Metal |
| Working Environment |
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Storage Environment |
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Surge Protection |
4KV |
| Reset Button |
N/A |
| Protection |
Ingression protection: IP67 |
