The VSPOE-SW8H is a DIN rail mountable, fast PoE switch in 8 ports. It is ideal for building secondary networks - providing data and power to devices on the edge of a network, such as CCTV cameras, wireless access points, IP telephones, network access control systems and more.
Product features:
• 8 x PoE+ device ports with 100Mbps per port
• 1 x Hi-PoE device port with 100Mbps per port
• 1 x 1000Mbps Gigabit RJ45 & SFP fibre uplink ports
• Total PoE power load up to 96W
• Unmanaged switch for plug and play applications
• DIN rail mountable for neat rackmount installations
• Professional appearance full metal enclosure
Datasheets
Tech Specs
| Device Ports | 8 x 10/100 Base-T (PoE power supply ports) |
| DHCP | N/A |
| Dimensions | 150 x 100 x 42mm |
| Exchange Mode | Store & forward |
| Extend Mode | N/A |
| Flow Control | Enabled |
| Input Power | 48 ~ 57VDC |
| Lightning Protection | Common Mode: 6kV / Differential Mode: 4kV |
| LLDP | N/A |
| MAC Address Capacity | 8K |
| Mounting Options | DIN rail |
| Network Management | N/A |
| Network Time Protocol | N/A |
| Operating Environment | -30°C~65°C / RH5%~95% |
| Packet Forwarding Rate | 4.17Mpps |
| PoE | Yes |
| PoE Management | N/A |
| PoE Protocol | PoE (IEEE802.3af) / PoE+ (IEEE802.3at) / Hi-PoE |
| Port Aggregation | N/A |
| Port Mirroring | N/A |
| Ports | 8 ports |
| Quality of Service | N/A |
| Security Features | N/A |
| Spanning Tree Protocol | N/A |
| Speed | Fast 10/100 |
| Switch Management | Unmanaged |
| Switch Power Load | Ports 1-2: ?60W / Port 3-8: ?30W (Total: ?96W) |
| Switching Capacity | 7.6Gbps |
| System Maintenance | N/A |
| Uplink Ports | 1 x 100/1000 Base-X / 1 x 10/100/1000 Base-T |
| Virtual LAN | N/A |
| Weight | 0.54kg |
