| Image Sensor |
1/2.8″ Progressive CMOS |
| Maximum Video Resolution (Megapixels) |
5 |
| Maximum Video Resolution |
2560 x 1920 |
| Lens |
4.3mm -142mm (H.FOV: 60 to 2.4°) |
| Lens Type |
Motorised Pan, tilt and Zoom |
| Maximum Night IR Distance (M) |
150 |
| Image clarity |
3.5 |
| Connectors |
RJ-45 , Analog Video Out, Audio In, Audio Out, Alarm in or out *4 |
| Video Compression |
H.265, H.264 |
| ONVIF (depends on firmware version) |
19.12 |
| Operating Environment |
-20ºC to 55ºC (14ºF-131ºF) Humidity: 20%-80% RH |
| Weight (Net) |
2 |
| Power Supply |
Power over Ethernet IEEE 802.3at, DC12V, AC24V |
| Power Consumption |
<25W |
| Connectors (web) |
RJ-45 , DC Power Input, Analog Video Output, Audio In, Audio Out, Alarm in or out *4. |
| Outdoor Use |
Yes |
| IP Rating |
IP66 |
| Vandal Resistant |
Yes |
| Frame Rate at Resolution |
25 |
| Day/Night Mode |
Auto |
| Image Enhancement |
Rotate, Flip mode, Brightness, Contrast, Saturation, Sharpness, Hue |
| Video Compression |
H.265, H.264 (3 streams) |
| Audio Streaming |
Yes – input connector for external mic |
| Protocols |
TCP/IP, UDP, HTTP, HTTPS, DHCP, FTP, RTP/RTSP, DNS, DDNS, NTP, PPPOE, UPNP, SMTP, SMTP, P2P (QR code) |
| Intelligent Video |
IVS such as Perimeter Intrusion Detection, Human and Vehicle Detection, Face Detection, Motion Detection and more |
| Software |
Device Search/Config Tool, Surveillance Client (CMS/VMS), Mobile app |
| Power Over Ethernet |
Yes |
| Ethernet |
Ethernet (10/100 Base-T) |
| UPNP |
Yes |
| In The Box |
Free Software available from FAQ, Printed quick user guide, Installation template, Mounting screws and plugs |
| Warranty |
3 Year Warranty |
