| Camera Type |
Turret |
| Image Sensor |
1/2.3″ Progressive CMOS |
| Maximum Video Resolution (Megapixels) |
12 |
| Maximum Video Resolution |
4096 × 3072 |
| Frames Per Second (FPS) |
15 |
| Lens |
3.6 |
| Lens Type |
Fixed |
| Maximum Night IR Distance (M) |
30 |
| LED |
IR, Red & Blue, White |
| Video Compression |
H.265+, H.265, H.264+, H.264, MJPEG |
| ONVIF depends on firmware version |
ONVIF (Profile S/G/T) |
| Accessories |
IV2422X, IV2433X, IV2444X, IV2455X, IV2457X, IV2477X |
| Outdoor Use |
Yes |
| IP Rating |
IP67 |
| Vandal Resistant |
Yes (IK10) |
| Day/Night Mode |
Auto |
| Image Enhancement |
Smart IR, Flip mode, Brightness, Contrast, Saturation, Sharpness, Hue, Corridor Mode, Mirror, Angle Flip, Back Light, White Balance, Shutter, Time Exposure, Defog, 3D Noise Reduction |
| Intelligent Video (IVS) |
Perimeter Intrusion Detection, Line Crossing Detection, Stationary Object Detection, Human and vehicle detection, Face Detection, Cross Counting, Crowd Density Detection, Queue Length Detection, Heatmap |
| Edge Recording microSD/SDHC Card |
Micro SD/SDHC Card |
| Multiple Streams (encode format) |
3 Streams |
| Software |
Device Search/Config Tool, Surveillance Client (CMS/VMS), Mobile app (QR code) |
| Protocols |
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPnP, SNMP, HTTPS, FTP, PPPoE |
| Cloud option (camera only) |
Dropbox |
| Audio Streaming |
Yes – input connector for external mic |
| Ethernet |
Ethernet (10/100/1000 Base-T) |
| Power Over Ethernet |
Yes |
| Power Supply |
Power over Ethernet IEEE 802.3at, DC12V, AC24V |
| Power Consumption |
< 14W |
| Connectors |
RJ-45, DC Power Input, Analog Video Output, Audio In, Audio Out, Alarm in or out *4. |
| Operating Environment |
-30ºC to 55ºC (-22ºF-131ºF) Humidity: ≤95% RH |
| In The Box |
Free Software available from FTP, Printed quick user guide, Installation template, Mounting screws and plugs |
| Product Dimensions (H x W x L) mm |
100 x 100 x 100 |
| Weight (Net) kg |
0.44 |
| Warranty |
3 Year Warranty |
