| Video |
|---|
| Imaging Device |
Uncooled micro bolometer |
| NETD |
＜50mK |
| Pixel size |
17㎛ |
| Video Out |
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation
USB: Micro USB Type B, 1280x720 for installation |
| Lens |
|---|
| Focal Length (Zoom Ratio) |
19mm fixed focal |
| Max. Aperture Ratio |
F1.0 |
| Angular Field of View |
H: 32˚ / V: 24.3˚ / D: 39.2˚ |
| Min. Object Distance |
11m(36.09ft) |
| Focus Control |
Fixed |
| Operational |
|---|
| Camera Title |
Displayed up to 85 characters |
| Digital Image Stabilization |
Support(built-in gyro sensor) |
| Motion Detection |
8ea, 8point polygonal zones |
| Privacy Masking |
32ea, polygonal zones
- Color: Grey/Green/Red/Blue/Black/White
- Mosaic |
| Video Rotation |
Flip, Mirror, Hallway view(90˚/270˚) |
| Analytics |
Directional detection, Motion detection, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Audio detection, Temperature ditection, Sound classification, Shock detection |
| Serial Interface |
RS-485(Samsung-T, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell) |
| Alarm I/O |
Input 1ea / Output 2ea |
| Alarm Triggers |
Analytics, Network disconnect, Alarm input |
| Alarm Events |
File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC or NAS recording at event triggers
Alarm output
Handover |
| Audio In |
Selectable(mic in/line in)
Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
| Audio Out |
Line out, Max.output level: 1Vrms |
| Radiometry |
|---|
| Temperature detect range |
-20˚C~130˚C(-4˚F~266˚F) |
| Temperature accuracy |
±5 ℃(≤100℃), ±20%(>100℃) |
| Temperature detection |
3ea rectanguler |
| Additional |
Hybrid palettes, Spot temperature reading |
| Network |
|---|
| Ethernet |
RJ-45(10/100BASE-T) |
| Video Compression |
H.265/H.264: Main/Baseline/High, MJPEG |
| Resolution |
640x480, 640x360, 320x240 |
| Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 30fps/25fps(60Hz/50Hz) |
| Smart Codec |
Manual(5ea area), WiseStreamⅡ |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(20 users) / Multicast
Multiple streaming(Up to 10 profiles) |
| Audio Compression |
G.711 u-law /G.726 Selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
AAC-LC: 48Kbps at 16KHz |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
| Security |
HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access log
802.1X Authentication(EAP-TLS, EAP-LEAP) |
| Edge Storage |
Micro SD/SDHC/SDXC 1slot 256GB |
| Application Programming Interface |
ONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platform |
| Web Viewer |
Supported OS: Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12
Recommended Browser: Google Chrome
Supported Browser: MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OS X only) |
| Memory |
1024MB RAM, 256MB Flash |
| Environmental |
|---|
| Operating Temperature / Humidity |
-40°C ~ +60°C (-40°F ~ +140°F) / 90% RH 이하 |
| Storage Temperature / Humidity |
-50°C ~ +60°C (-58°F ~ +140°F) / 90% RH 이하 |
| Certification |
IP66, IK10, NEMA4X |
| Electrical |
|---|
| Input Voltage |
PoE(IEEE802.3af, Class3), 24VAC, 12VDC |
| Power Consumption |
PoE: Max. 10W, typical 8.6W
12VDC: Max. 9W, typical 7.5W
24VAC: Max. 10.5W, typical 8.9W |
| Mechanical |
|---|
| Color / Material |
White / Aluminum |
| RAL Code |
RAL9003 |
| Product dimensions / weight |
Φ101.97x309mmmm(4.01x12.17") / 2452g(5.41 lb) |
