| VIDEO |
| Imaging Device |
Uncooled microbolometer, Pixel size : 17. |
| Effective Pixels |
640(H) x 480(V) |
| NETD |
<50mK |
| Video Out |
CVBS : 1.0 Vpp / 75O composite, 720 x 480(N), 720 x 576(P), for installation |
| LENS |
| Focal Length (Zoom Ratio) |
19mm fixed |
| Max. Aperture Ratio |
F1.0 |
| Angular Field of View |
H : 32° / V : 24.3° / D : 39.2° |
| Min. Object Distance |
11m (36.09ft) |
| Focus Control |
Fixed |
| Lens / Mount Type |
Board-in type |
| OPERATIONAL |
| Camera Title |
Off / On
- W/W : English / Numeric / Special characters
- China : English / Numeric / Special / Chinese characters
- Common : Multi-line (Max. 5), Color (Gray / Green / Red / Blue / Black / White), Transparency, Auto scale by resolution |
| Motion Detection |
Off / On (8ea, 8point polygonal zones), Handover |
| Privacy Masking |
Off / On (32ea, polygonal zones)
- Color : Gray / Green / Red / Blue / Black / White - Mosaic |
| Flip / Mirror |
Off / On |
| Video & Audio Analytics |
Tampering, Loitering, Directional detection, Virtual line, Enter/Exit, (Dis) Appear, Audio detection, Motion detection, Sound classification, Shock detection, Temperature change detection |
| Alarm I/O |
Input 1ea / Output 2ea |
| Digital Image Stabilization |
Off / On (Built-in Gyro sensor) |
| Remote Control Interface |
RS485 |
| RS-485 Protocol |
Pelco D/P, Samsung T, Honeywell, Bosch, Pansonic, Sungin, AD, Vicon, GE |
| Alarm Triggers |
Alarm input, Motion detection, Video & Audio analytics, Network disconnect |
| Alarm Events |
File upload Via FTP, E-mail, Notification Via E-mail, Local storage (SD/SDHC/SDXC) or NAS recording at event triggers, External output |
| Pixel count |
Support |
| NETWORK |
| Ethernet |
RJ-45 (10/100 BASE-T) |
| Video Compression Format |
H.265 / H.264 (MPEG-4 part 10/AVC) : Main / Baseline / High, MJPEG |
| Resolution |
640 x 480, 640 x 360, 320 x 240 |
| Max. Framerate |
H.265 / H.264 : Max. 30fps at all resolutions, MJPEG : Max. 30fps |
| WiseStreamII |
Support |
| Video Quality Adjustment |
H.265 / H.264 / MJPEG : Target Bitrate Level Control |
| Bitrate Control Method |
H.265 / H.264 : CBR or VBR, MJPEG : VBR |
| Streaming Capability |
Multiple streaming (Up to 10 profiles) |
| Audio In |
Selectable (Mic in / Line in), Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm |
| Audio Out |
Line out, Max output level : 1 Vrms |
| Audio Compression Format |
G.711 u-law / G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz,
G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps, AAC-LC : 48Kbps at 8 / 16 / 32 / 48KHz |
| Audio Communication |
Bi-dierctional (2-Way) |
| IP |
IPv4, IPv6 |
| Protocol |
TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3 (MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour |
| Security |
HTTPS(SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x authentication (EAP-TLS, EAP-LEAP) |
| Streaming Method |
Unicast / Multicast |
| Max. User Access |
20 users at Unicast mode |
| Edge Storage |
SD/SDHC/SDXC (up to 256GB)
- Motion images recorded in the SD/SDHC/SDXC memory card can be downloaded.
NAS (Network Attached Storage), Local PC for instant recording |
| Application Programming Interface |
ONVIF Profile S/G, SUNAPI (HTTP API), Wisenet Open Platform |
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Web Viewer |
Supported OS : Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12
Non-plugin Webviewer
- Supported Browser : Google Chrome 63, MS Edge 41, Mozilla Firefox 57 (Window 64bit only), Apple Safari 11 (Mac OS X only)
Plug-in Webviewer
- Supported Browser : MS Explore 11, Apple Safari 11 (Mac OS X only) |
| Central Management Software |
SmartViewer, SSM |
| ENVIRONMENTAL |
| Operating Temperature / Humidity |
-40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH |
| Storage Temperature / Humidity |
-50°C ~ +60°C (-58°F ~ +140°F) / Less than 90% RH |
| Ingress Protection |
IP66, NEMA 4X |
| Vandal Resistance |
IK10 |
| ELECTRICAL |
| Input Voltage / Current |
24V AC ±10%, 12V DC ±10%, PoE (IEEE802.3af, class 3) |
| Power Consumption |
Max. 10.5W (24V AC), Max, 9W (12V DC), Max. 10W (PoE)
Typical 8.9W (24V AC), Typical 7.5W (12V DC), Typical 8.6W (PoE) |
| MECHANICAL |
| Color / Material |
White (RAL-9003) / Aluminum |
| Dimensions (WxH) |
Ø101.97 x 309mm (Ø4.01" x 12.17") |
| Weight |
2,452g (5.41 lb) |
