Video |
|
Imaging Device |
1/2.8" 5MP CMOS |
Resolution |
5MP mode : 2592x1944, 1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 4MP mode : 2560x1440, 1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz) MJPEG: Max. 15fps/12fps(60Hz/50Hz) |
NETD |
None |
Pixel Size |
None |
Min. Illumination |
Color: 0.15Lux(F2.0, 1/30sec) BW: 0Lux(IR LED on) |
Video Out |
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation |
Video Transmission Distance |
None |
Lens |
Focal Length (Zoom Ratio) |
2.8mm fixed focal |
Max. Aperture Ratio |
F2.0 |
Angular Field of View |
H: 104.7°/ V: 76.5°/ D: 136.0° |
Min. Object Distance |
None |
Focus Control |
Fixed |
Lens Type |
None |
Mount Type |
None |
Optional Lens |
None |
Pan / Tilt / Rotate |
Pan / Tilt / Rotate Range |
0˚~350˚ / 0˚~67˚ / 0˚~355˚ |
Pan Range |
None |
Pan Speed |
None |
Tilt Range |
None |
Tilt Speed |
None |
Rotate Range |
None |
Sequence |
None |
Preset Accuracy |
None |
Operational |
Camera Title |
Displayed up to 85 characters |
Direction Indicator |
None |
Day & Night |
Auto(ICR) |
Backlight Compensation |
BLC, WDR, SSDR |
Wide Dynamic Range |
120dB |
Digital Noise Reduction |
SSNR |
Digital Image Stabilization |
None |
Defog |
None |
Motion Detection |
4ea, polygonal zones |
Privacy Masking |
6ea, rectangular zones |
Gain Control |
Low / Middle / High |
White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
LDC |
Support |
Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (1/5~1/12,000sec) |
Digital PTZ |
None |
Video Rotation |
Flip, Mirror, Hallway view(90˚/270˚) |
Analytics |
Defocus detection, Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line |
Business Intelligence |
None |
Serial Interface |
None |
Alarm I/O |
Input 1ea / Output 1ea |
Alarm Triggers |
Analytics, Network disconnect, Alarm input |
Alarm Events |
File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers Alarm output |
Audio In |
None |
Audio Out |
None |
IR Viewable Length |
20m(65.62ft) |
IR Illuminator (Optional) |
None |
Water Removal |
None |
Auto Tracking |
None |
Coaxial Protocol |
None |
Color Palettes |
None |
Radiometry |
Temperature detect range |
None |
Temperature accuracy |
None |
Temperature detection |
None |
Additional |
None |
Network |
Ethernet |
RJ-45(10/100BASE-T) |
Video Compression |
H.265/H.264: Main/High, MJPEG |
Audio Compression |
None |
Smart Codec |
WiseStreamⅡ |
Video Quality Adjustment |
H.264/H.265: Target bitrate level control MJPEG: Quality level control |
Bitrate Control |
H.264/H.265: CBR or VBR MJPEG: VBR |
Streaming |
Unicast(6 users) / Multicast Multiple streaming(Up to 3 profiles) |
Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP |
Security |
HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP) |
Application Programming Interface |
ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform |
General |
Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch |
Web Viewer |
None |
Edge Storage |
Micro SD/SDHC/SDXC 1slot 128GB |
Memory |
512MB RAM, 256MB Flash |
Environmental & Electrical |
Operating Temperature / Humidity |
-10°C ~ +50°C(+14°F ~ +122°F) / Less than 90% RH |
Storage Temperature / Humidity |
-30°C ~ +60°C(-22°F ~ +140°F) / Less than 90% RH |
Certification |
None |
Input Voltage |
PoE(IEEE802.3af, Class3) |
Power Consumption |
PoE: Max 7.50W, typical 5.80W |
Mechanical |
Color / Material |
White / Plastic, Aluminum |
RAL Code |
RAL9003 |
Product dimensions / weight |
Ø110.6x89.5mm(Ø4.35x3.52"), 360g(0.79 lb) |
Conduit hole |
None |
Hanging mount(Dome) |
SBP-300HMW7 |
Skin cover(Dome) |
None |
Weather cap(Dome) |
None |
Power module |
None |
Backbox |
None |
DORI (EN62676-4 standard) |
Detect (25PPM/ 8PPF) |
40.0m(131.20ft) |
Observe (63PPM/ 19PPF) |
16.0m(52.48ft) |
Recognize (125PPM/ 38PPF) |
8.0m(26.24ft) |
Identify (250PPM/ 76PPF) |
4.0m(13.12ft) |
