| VIDEO |
| Imaging Device |
1/2.8" 2.38M CMOS x 4 |
| Total / Effective Pixels |
1,945(H) x 1,109(V) 2.16M x 4 / 1,945(H) x 1,097(V) 2.13M x 4 |
| Scanning System |
Progressive Scan |
| Min. Illumination |
Color : 0.015 Lux (F1.4, 1/30sec), B/W : 0.0015 Lux (F1.4, 1/30sec) |
| S / N Ratio |
50dB |
| Video Out |
CVBS : 1.0 Vp-p / 75O composite, 720 x 480(N), 720 x 576(P), for installation (selectable CVBS per Channel) |
| LENS |
| Focal Length (Zoom Ratio) |
2.8 ~ 12mm (4.3x) motorized varifocal |
| Max. Aperture Ratio |
F1.4(Wide) ~ F3.6(Tele) |
| Angular Field of View |
H : 119.5°(Wide) ~ 27.9°(Tele), V : 62.8°(Wide) ~ 15.7°(Tele), D : 142.1°(Wide) ~ 32.0°(Tele) |
| Min. Object Distance |
0.5m (1.64ft) |
| Focus Control |
Simple focus (Motorized V/F) / Manual, Remote control via network (Manual, Simple focus) |
| Lens / Mount Type |
DC Auto Iris, P-Iris / Board-in Type |
| PAN / TILT / ROTATE |
| Pan / Tilt / Rotate Range |
Quad mode : ±30° / 10° ~ 41° / ±90°,
Center mode : ±60° / 10° ~ 41°, 10° ~ 90°(CH2/Center) / ±90° |
| OPERATIONAL |
| Camera Title |
Off / On (Displayed up to 85 characters) : Each Ch
- W/W : English / Numeric / Special Characters
- China : English / Numeric / Special / Chinese Characters
- Common : Multi-line (Max 5), Color (Grey / Green / Red / Blue / Black / White), Transparency, Auto Scale by Resolution |
| Day & Night |
Auto (ICR) / Color / B/W / External / Schedule |
| Backlight Compensation |
Off / BLC / HLC (Masking / Dimming), WDR |
| Wide Dynamic Range |
150dB |
| Contrast Enhancement |
SSDR (Off / On) |
| Digital Noise Reduction |
SSNRV (2D + 3D Noise Filter) (Off / On) |
| Digital Image Stabilization |
Off / On (Built-in Gyro sensor) |
| Defog |
Off / Auto / Manual |
| Motion Detection |
Off / On (8ea, 8point Polygonal zones) |
| Privacy Masking |
Off / On (32ea, polygonal zones)
- Color : Grey / Green / Red / Blue / Black / White - Mosaic |
| Gain Control |
Off / Low / Middle / High / Manual |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor (included Mercury & Sodium) |
| Contrast |
Level Adjustment |
| LDC |
Off / On (5 Levels with Min / Max) |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec) |
| Digital Zoom |
24x |
| Flip / Mirror |
Flip : Off / On, Mirror : Off / On, Hallway View : 90° / 270° |
| Intelligent Video Analytics |
Tampering, Loitering, Directional Detection, Defocus Detection, Fog Detection, Virtual Line, Enter/Exit, (Dis) Appear, Motion Detection |
| Alarm I/O |
Input 1ea / Output 1ea |
| Alarm Triggers |
Alarm Input, Motion Detection, Video Analytics, Network Disconnect, SD card error |
| Alarm Events |
File upload via FTP, E-Mail, Notification via E-Mail, Local Storage (SD/SDHC/SDXC) recording at Event Triggers, External output |
| Pixel Counter |
Support |
| NETWORK |
| Ethernet |
RJ-45 (10/100/1000BASE-T) |
| Video Compression Format |
H.265 / H.264 (MPEG-4 Part 10/AVC) : Main / Baseline / High, Motion JPEG |
| Resolution |
1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 450, 720 x 576, 640 x 480, 640 x 360, 320 x 240 |
| Max. Framerate |
H.265 / H.264 : Max. 60fps at all resolutions, Motion JPEG : Max. 30fps |
| Smart Codec / WiseStreamII |
Manual Mode (Area-Based : 5ea) / Support |
| Video Quality Adjustment |
H.265 / H.264 : Target Bitrate Level Control, MJPEG : Quality Level Control |
| Bitrate Control Method |
H.265 / H.264 : CBR or VBR, with WiseStream, MJPEG : VBR |
| Streaming Capability |
Multiple Streaming (Up to 40 Profiles) |
| IP |
IPv4, IPv6 |
| Protocol |
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
| Security |
HTTPS (SSL) Login Authentication, Digest Login Authentication
IP Address Filtering, User Access Log, 802.1X Authentication (EAP-TLS, EAP-LEAP) |
| Streaming Method |
Unicast / Multicast |
| Max. User Access |
20 users at Unicast Mode |
| Edge Storage |
SD / SDHC / SDXC 4slot (Each CH)
- Motion Images recorded in the SD / SDHC / SDXC memory card can be downloaded.
Local PC for Instant Recording |
| Application Programming Interface |
ONVIF profile S, SUNAPI (HTTP API) |
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungary, Greek |
| Web Viewer |
Supported OS : Windows 7, 8, 10, Mac OS X 10.10, 10.11, 10.12
Non-plugin WebViewer
Supported Browser : Google Chrome 54, MS Edge 38, Mozilla Firefox 49 (Windows 64bit only), Apple Safari 9 (Mac OS X only)
Plug-in WebViewer
Supported Browser : MS Explore 11, Apple Safari 9 (Mac OS X only) |
| ENVIRONMENTAL |
| Operating Temperature / Humidity |
-40°C ~ +55°C (-40°F ~ +131°F) / Less than 90% RH |
| Storage Temperature / Humidity |
-50°C ~ +60°C (-58°F ~ +140°F) / Less than 90% RH |
| Ingress Protection / Vandal Resistance |
IP66 / IK10 |
| ELECTRICAL |
| Input Voltage / Current |
12V DC, PoE+ |
| Power Consumption |
Max. 21.6W (12V DC), Max. 25.5W (PoE+) |
| MECHANICAL |
| Color / Material |
Ivory / Aluminum |
| Dimensions (WxH) |
Ø314 x 152mm (Ø12.36" x 5.98") |
| Weight |
4.83kg (10.65 lb) |
