Video |
|
Imaging Device |
1/1.8" CMOS |
Resolution |
3840x2160, 3072x1728, 2592x1944, 2688x1520, 2560x1440, 2048x1536, 1920x1080, 1600x1200, 1280x1024,1280x960, 1280x720, 1024x768, 800 x 600, 800 x 448, 720 x 576, 720x480, 640x480, 640x360 |
Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz) MJPEG: Max. 30fps/25fps(60Hz/50Hz) |
Min. Illumination |
Color: 0.05Lux(F1.6, 1/30sec) BW: 0.005Lux(F1.6, 1/30sec), 0Lux(IR LED on) |
Video Out |
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation USB: Micro USB Type B, 1280x720 for installation |
Lens |
Focal Length (Zoom Ratio) |
4.5~10mm(2.2x) motorized varifocal |
Max. Aperture Ratio |
F1.6(Wide)~F2.65(Tele) |
Angular Field of View |
H:101.4°(Wide)~45.5°(Tele) / V:53.6°(Wide)~25.5°(Tele) / D:120.7°(Wide)~52.3°(Tele) |
Min. Object Distance |
0.5m(1.64ft) |
Focus Control |
Simple focus |
Lens Type |
P iris |
Pan / Tilt / Rotate |
Pan / Tilt / Rotate Range |
0˚~360˚ / -45˚~85˚ / 0˚~355˚ |
Operational |
Camera Title |
Displayed up to 85 characters |
Day & Night |
Auto(ICR) |
Backlight Compensation |
BLC, WDR, SSDR |
Digital Noise Reduction |
SSNRⅤ |
Digital Image Stabilization |
Stabilization Support(built-in gyro sensor) |
Motion Detection |
8ea, polygonal zones |
Privacy Masking |
6ea, rectangle zones - Color: GrayBlack/White |
Gain Control |
Low / Middle / High |
White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
LDC |
Support |
Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (1/5~1/12,000sec) |
Video Rotation |
Flip, Mirror, Hallway view(90˚/270˚) |
Analytics |
Defocus detection, Motion detection, Tampering, Audio detection, Sound classification, Shock detection |
Alarm I/O |
Input 1ea / Output 1ea / DC 12V Power(Max. 50mA) 1ea |
Alarm Triggers |
Analytics, Network disconnect, Alarm input |
Alarm Events |
File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers Alarm output Handover Audio playback |
Audio In |
Selectable(mic in/line in/Built in mic) Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
Audio Out |
Line out, Max.output level: 1Vrms |
IR Viewable Length |
30m(98.42ft) |
Network |
Ethernet |
Metal shielded RJ-45(10/100/1000 BASE-T) |
Video Compression |
H.265/H.264: Main/High, MJPEG |
Audio Compression |
G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps AAC-LC: 48Kbps at 16KHz |
Smart Codec |
Manual(5ea area), WiseStreamⅡ |
Bitrate Control |
H.264/H.265: CBR or VBR MJPEG: VBR |
Streaming |
Unicast(6 users) / Multicast Multiple streaming(Up to 3 profiles) |
Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast) |
Security |
HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP) Device Certificate(Hanwha Techwin Root CA) Secure boot |
Application Programming Interface |
ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform |
General |
Webpage Language |
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
Edge Storage |
Pre-installed with 32GB Micro SD to support 10,000 LPR images |
Memory |
4096MB RAM, 512MB Flash |
Environmental & Electrical |
Operating Temperature / Humidity |
-40°C ~ +55°C(-40°F ~ +131°F) / Less than 90% RH * Start up should be done at above -30°C |
Storage Temperature / Humidity |
-50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH |
Certification |
IP66/IP67/IP6K9K, IK10+, NEMA4X |
Input Voltage |
PoE+(IEEE802.3at), 12VDC |
Power Consumption |
PoE+: Max 20.00W, typical 17.00W 12VDC: Max 18.70W, typical 15.00W |
Mechanical |
Color / Material |
White / Aluminum |
RAL Code |
RAL9003 |
Product Dimensions / Weight |
Ø180x125mm(7.09x4.92"), Weight : 1.90Kg (4.19lb) |
Compatible Conduit hole / Gangbox |
3/4"(M25) Single, Double, 4"Octagon, Square |
Hanging Mount (Dome) |
SBP-187HMW |
Wisenet Road AI LPR/ANPR/MMCR |
Solution |
Community Traffic |
Speed Description |
Moderate Speed |
Lane Coverage |
1 lane (3.6m/12ft Wide) (with built in IR) |
Speed limit |
Up to 45mph (with built in IR) |
Min. Forward Distance |
12m (38ft) |
Max. Forward Distance |
12m (40ft) (with built in IR) |
Max. Horizontal Angle |
25° |
Max. Vertical Angle |
25° |
Horizontal Offset |
Up to 5m (18ft) |
Camera Height |
Up to 5m (18ft) |
Vehicle Recognition |
Make : 70+ Model : 600+ Color : 11 |
Available Countries |
USA, Canada, Mexico, Brazil, Uruguay, Paraguay, Argentina, Colombia, Chile |
