Video |
|
Imaging Device |
1/1.8" CMOS |
Resolution |
3840x2160, 3072x1728, 2592x1944, 2688x1520, 2560x1440, 2048x1536, 1920x1080, 1600x1200, 1280x1024,1280x960, 1280x720, 1024x768, 800 x 600, 800 x 448, 720 x 576, 720x480, 640x480, 640x360 |
Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz) MJPEG: Max. 30fps/25fps(60Hz/50Hz) |
NETD |
None |
Pixel Size |
None |
Min. Illumination |
Color: 0.05Lux(F1.6, 1/30sec) BW: 0.005Lux(F1.6, 1/30sec), 0Lux(IR LED on) |
Video Out |
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation USB: Micro USB Type B, 1280x720 for installation |
Video Transmission Distance |
None |
Lens |
Focal Length (Zoom Ratio) |
4.5~10mm(2.2x) motorized varifocal |
Max. Aperture Ratio |
F1.6(Wide)~F2.65(Tele) |
Angular Field of View |
H:101.4°(Wide)~45.5°(Tele) / V:53.6°(Wide)~25.5°(Tele) / D:120.7°(Wide)~52.3°(Tele) |
Min. Object Distance |
0.5m(1.64ft) |
Focus Control |
Simple focus |
Lens Type |
P iris |
Mount Type |
None |
Optional Lens |
None |
Pan / Tilt / Rotate |
Pan / Tilt / Rotate Range |
None |
Pan Range |
None |
Pan Speed |
None |
Tilt Range |
None |
Tilt Speed |
None |
Rotate Range |
None |
Sequence |
None |
Preset Accuracy |
None |
Operational |
Camera Title |
Displayed up to 85 characters |
Direction Indicator |
None |
Day & Night |
Auto(ICR) |
Backlight Compensation |
BLC, WDR, SSDR |
Wide Dynamic Range |
None |
Digital Noise Reduction |
SSNRⅤ |
Digital Image Stabilization |
Stabilization Support(built-in gyro sensor) |
Defog |
None |
Motion Detection |
8ea, polygonal zones |
Privacy Masking |
6ea, rectangle zones - Color: Gray/Black/White |
Gain Control |
Low / Middle / High |
White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
LDC |
Support |
Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (1/5~1/12,000sec) |
Digital PTZ |
None |
Video Rotation |
Flip, Mirror, Hallway view(90˚/270˚) |
Analytics |
Defocus detection, Motion detection, Tampering, Audio detection, Sound classification, Shock detection |
Business Intelligence |
None |
Serial Interface |
None |
Alarm I/O |
Input 1ea / Output 1ea / DC 12V Power(Max. 50mA) 1ea |
Alarm Triggers |
Analytics, Network disconnect, Alarm input |
Alarm Events |
File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers Alarm output Handover Audio playback |
Audio In |
Selectable(mic in/line in/Built in mic) Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
Audio Out |
Line out, Max.output level: 1Vrms |
IR Viewable Length |
30m(98.42ft) |
IR Illuminator (Optional) |
None |
Water Removal |
None |
Auto Tracking |
None |
Coaxial Protocol |
None |
Color Palettes |
None |
Radiometry |
Temperature detect range |
None |
Temperature accuracy |
None |
Temperature detection |
None |
Additional |
None |
Network |
Ethernet |
Metal shielded RJ-45(10/100/1000 BASE-T) |
Video Compression |
H.265/H.264: Main/High, MJPEG |
Audio Compression |
G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps AAC-LC: 48Kbps at 16KHz |
Smart Codec |
Manual(5ea area), WiseStreamⅡ |
Video Quality Adjustment |
H.264/H.265: Target bitrate level control MJPEG: Target bitrate level control |
Bitrate Control |
H.264/H.265: CBR or VBR MJPEG: VBR |
Streaming |
Unicast(6 users) / Multicast Multiple streaming(Up to 3 profiles) |
Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast) |
Security |
HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP) Device Certificate(Hanwha Techwin Root CA) Secure boot |
Application Programming Interface |
ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform |
General |
Webpage Language |
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
Web Viewer |
None |
Edge Storage |
Pre-installed with 32GB Micro SD to support 10,000 LPR images |
Memory |
4096MB RAM, 512MB Flash |
Environmental & Electrical |
Operating Temperature / Humidity |
-40°C ~ +55°C(-40°F ~ +131°F) / Less than 90% RH * Start up should be done at above -30°C |
Storage Temperature / Humidity |
-50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH |
Certification |
IP66/IP67, IK10, NEMA4X |
Input Voltage |
PoE+(IEEE802.3at), 12VDC |
Power Consumption |
PoE+: Max 20.0W, typical 17.00W 12VDC: Max 18.00W, typical 16.00W |
Mechanical |
Color / Material |
Dark gray / Aluminum |
RAL Code |
None |
Product dimensions / weight |
Ø91.0x368.6mm (3.58" x 14.51") (Without sunshield), Weight : 2.48Kg (5.47lb) |
Compatible Conduit hole / Gangbox |
None |
Hanging mount(Dome) |
None |
Skin cover(Dome) |
None |
Weather cap(Dome) |
None |
Power module |
None |
Backbox |
None |
DORI (EN62676-4 standard) |
Detect (25PPM/ 8PPF) |
None |
Observe (63PPM/ 19PPF) |
None |
Recognize (125PPM/ 38PPF) |
None |
Identify (250PPM/ 76PPF) |
None |
Wisenet Road AI LPR/ANPR/MMCR |
Solution > Community Traffic |
Parking Application |
Speed Description > Moderate Speed |
Low speed |
Lane Coverage > 1 lane (3.6m/12ft Wide) (with built in IR) |
1 lane (3.6m/12ft Wide) (with built in IR) |
Speed limit > Up to 70kmh (45mph) (with built in IR) |
Up to 40kmh (25mph) (with built in IR) |
Min. Forward Distance > 12m (38ft) |
10m (33ft) |
Max. Forward Distance > 12m (40ft) (with built in IR) |
13m (45ft) (with built in IR) |
Max. Horizontal Angle > 25° |
30° |
Max. Vertical Angle > 25° |
30° |
Horizontal Offset > Up to 5m (18ft) |
Up to 7m (24ft) |
Camera Height > Up to 5m (18ft) |
Up to 7m (24ft) |
Vehicle Recognition |
Make : 70+ Model : 600+ Color : 11 |
Available Countries |
Albania, Armenia, Austria, Belarus, Belgium, Bosnia and Herzegovina, Bulgaria, Cyprus, Czechia, Denmark, Estonia, Finland, France, Greece, Germany, Hungary, Ireland, Iceland, Italy, Lithuania, Luxembourg, Latvia, Montenegro, North Macedonia, Malta, Netherlands, Norway, Poland, Portugal, Romania, Serbia, Slovenia, Slovakia, Spain, Switzerland, Turkey, United Kingdom, United States of America, Canada, Russian Federation, Azerbaijan, Uzbekistan, Ukraine, Kyrgyzstan, Kazakhstan, Tajikistan, Georgia, Turkmenistan, Australia, New zealand, Indonesia, Vietnam, Bahrain, Kuwait, Oman, Qatar, KSA (Kingdom of Saudi Arabia), UAE, South Africa, Hongkong/Taiwan (MMCR is not available) |
