Video |
|
Imaging Device |
1/1.8" progressive CMOS |
Resolution |
3328x1872, 3072x1728, 2592x1944, 2688x1520, 1920x1080, 1600x1200, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz) MJPEG: Max. 15fps/12fps(60Hz/50Hz) |
Min. Illumination |
Color: 0.04Lux(F1.3, 1/30sec, 30IRE) BW: 0.004Lux(F1.3, 1/30sec, 30IRE), 0Lux(IR LED on) |
Video Out |
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation USB: Micro USB Type B, 1280x720 for installation |
Lens |
Focal Length (Zoom Ratio) |
4.4~9.3mm(2.1x) motorized varifocal |
Max. Aperture Ratio |
F1.3(Wide) ~ F2.15(Tele) |
Angular Field of View |
H : 112.1°(Wide)~47.5°(Tele) V : 58.0°(Wide)~26.6°(Tele) D : 137.5°(Wide)~54.6°(Tele) |
Min. Object Distance |
0.5m(1.64ft) |
Focus Control |
Simple focus, Manual |
Lens Type |
P-iris(IR corrected) |
Pan / Tilt / Rotate |
Pan / Tilt / Rotate Range |
0°~360° / -45°~85° / 0°~355° |
Operational |
Camera Title |
Displayed up to 85 characters |
Day & Night |
Auto(ICR) |
Backlight Compensation |
BLC, HLC, WDR, SSDR |
Wide Dynamic Range |
extremeWDR (120dB) |
Digital Noise Reduction |
WiseNRⅡ(Based on AI engine), SSNRⅤ |
Digital Image Stabilization |
Support(built-in gyro sensor) |
Defog |
Support |
Motion Detection |
8ea, 8point Polygonal zones |
Privacy Masking |
32ea, Quadrangle zones - Color : Gray, Green, Red, Blue, Black, White - Mosaic |
Gain Control |
Support |
White Balance |
ATW / Narrow ATW / AWC / Manual / Indoor / Outdoor |
LDC |
Support (Fill/stretch mode) |
Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2~1/12,000sec) Prefer shutter control(Based on AI engine) |
Video Rotation |
Flip, Mirror, Hallway view(90°/270°) |
Analytics |
- Analytics events based on AI engine : Object detection (Person/Face/Vehicle(car/bus/truck/motorcycle/bicycle)/License plate), IVA (Virtual line/Area, Enter/Exit, Loitering, direction, Appear/Disappear, intrusion) - Analytics events : Defocus detection, Motion detection, Tampering, Fog detection, Audio detection, Sound classification, Shock detection |
Business Intelligence |
Based on AI engine : People counting, Queue management, Heatmap |
Alarm I/O |
2 configurable I/O ports, DC 12V output(Max. 50mA) |
Alarm Triggers |
Analytics, Network disconnect, Alarm input, App event, Time schedule |
Alarm Events |
When alarm trigger occurred - File upload(image) : e-mail/FTP - Notification : e-mail - Recording : SD/SDHC/SDXC or NAS recording at event triggers - Alarm output - Handover(PTZ preset, Send message by HTTP/HTTPS/TCP) - Audio clip playback |
Audio In |
Selectable(mic in/line in) Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
Audio Out |
Line out, Max.output level: 1Vrms |
IR Viewable Length |
WiseIR 50m(164.04ft) |
Network |
Ethernet |
Metal shielded RJ-45(10/100/1000BASE-T) |
Video Compression |
H.265/H.264: Main/High, MJPEG |
Audio Compression |
G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps AAC-LC: 48Kbps at 16KHz |
Smart Codec |
Manual(5ea area), WiseStreamⅡ, WiseStreamⅢ(Based on AI engine) |
Bitrate Control |
H.264/H.265: CBR or VBR MJPEG: VBR |
Streaming |
Unicast(20 users) / Multicast Multiple streaming(Up to 10 profiles, 3 virtual channel support) |
Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast) |
Security |
TPM 2.0 (FIPS 140-2 level 2) HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2) Device Certificate(Hanwha Techwin Root CA, pre-installed) Secure by default certificate Secure OS/Boot/Storage, Verify firmware forgery |
Application Programming Interface |
ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform |
General |
Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish,, Portuguese, Czech, Polish, Turkish, Dutch, Greek, Hungarian |
Edge Storage |
Micro SD/SDHC/SDXC 2slot Max. 1TB (512GB * 2) |
Memory |
4GB RAM, 512MB Flash |
Environmental & Electrical |
Operating Temperature / Humidity |
-50°C~+55°C(-58°F ~ +131°F) * Maximum temperature : +60°C (intermittent) NEMA TS-2 : 74°C * Start up should be done at above -30°C less than 95%RH(non-condensing) Humidity control /w GORE vent |
Storage Temperature / Humidity |
-50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH |
Certification |
IP66/IP67/IP6K9K, NEMA4X, IK10+ |
Input Voltage |
PoE+(IEEE802.3at, Class4), 12VDC |
Power Consumption |
PoE+: Max 22.5W, typical 17.9W 12VDC: Max 20.0W, typical 15.6W Power redundancy failover |
Mechanical |
Color / Material |
White / Aluminum Hard-coated dome bubble |
RAL Code |
RAL9003 |
Product Dimensions / Weight |
Ø180x125mm(7.09x4.92"), 1900g(4.19 lb) |
DORI (EN62676-4 standard) |
Detect (25PPM/ 8PPF) |
Wide: 44.8m(147.02ft) / Tele: 151.3m(496.29ft) |
Observe (63PPM/ 19PPF) |
Wide: 17.9m(58.81ft) / Tele: 60.5m(198.52ft) |
Recognize (125PPM/ 38PPF) |
Wide: 9.0m(29.4ft) / Tele: 30.3m(99.26ft) |
Identify (250PPM/ 76PPF) |
Wide: 4.5m(14.7ft) / Tele: 15.1m(49.63ft) |
