| VIDEO |
| Imaging Device |
1/1.8" 6M CMOS |
| Total Pixels / Effective Pixels |
3,096(H) x 2,094(V) / 2,048(H) x 2,048(V) |
| Scanning System |
Progressive |
| Min. Illumination |
Color : 0.1 Lux (F1.6), B/W : 0 Lux (IR LED On) |
| S/N Ratio |
50dB |
| Video Output |
CVBS : 1.0 Vpp / 75O Composite, 714 x 480(N), 702 x 576(P) for Installation, DIP Connector Type, USB |
| LENS |
| Focal Length / Max. Aperture Ratio |
1.6mm / F1.6 |
| Angular Field of View |
H : 192° / V : 192° / D : 192° |
| Min. Object Distance |
0.3m (0.98ft) |
| Focus Control |
Simple focus / Manual, Remote control Via network |
| Lens Type / Mount Type |
Fixed / Board-in Type |
| OPERATIONAL |
| Viewable Length |
15m (49.21ft) |
| Camera Title |
Off / On (Displayed up to 85 characters)
- W/W : English / Numeric / Special characters
- China : English / Numeric / Special / Chinese characters
- Common : Multi-line (Max. 5), Color (Gray / Green / Red / Blue / Black / White), Transparency, Auto scale by resolution |
| Day & Night |
Auto (ICR) / Color / B/W / External / Schedule |
| Backlight Compensation |
Off / BLC / HLC / WDR |
| Wide Dynamic Range |
120dB |
| Contrast Enhancement |
SSDR (Off / On) |
| Digital Noise Reduction |
SSNRV (2D + 3D Noise filter) (Off / On) |
| Digital Image Stabilization |
Off / On |
| Defog |
Off / Auto (input from fog detection) / Manual |
| Motion Detection |
Off / On (8ea, 8point polygonal zones), Handover |
| Privacy Masking |
Off / On (32ea, polygonal) - Color : Gray, Green, Red, Blue, Black, White - Mosaic |
| Gain Control |
Off / Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor (Included mercury & Sodium) |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec) |
| Digital Zoom |
8x, Digital PTZ (Preset, Group) |
| Flip / Mirror |
Off / On |
| Intelligent Video Analytics |
Tampering, Loitering, Directional detection, Virtual line, Enter/Exit, (Dis)Appear, Audio detection, Sound classification, People counting, Heatmap, Queue management |
| Alarm I/O |
Input 1ea / Output 1ea |
| Alarm Triggers |
Alarm Input, Motion detection, Video & Audio analytics, Network disconnect |
| Alarm Events |
File upload Via FTP and E-Mail, Notification Via E-Mail, Local storage (SD/SDHC/SDXC) or NAS recording at event triggers, External output |
| Viewing Composition |
Camera Side : Fisheye, Single panorama, Double panorama,
Fisheye + 4 PTZ Quad View, Fisheye + 8 PTZ |
| Pixel Counter |
Support |
| NETWORK |
| Ethernet |
RJ-45 (10/100 BASE-T) |
| Video Compression Format |
H.265 / H.264 / MJPEG |
| Resolution |
Original view : 2048 x 2048, 1280 x 1280, 1080 x 1080, 960 x 960, 768 x 768, 720 x 720, 640 x 640, 480 x 480
Single panorama : 2048 x 512, 1920 x 480, 1280 x 320, 640 x 160, 704 x 176
Double panorama : 2048 x 1024, 1920 x 960, 1280 x 640, 640 x 320, 704 x 352
Quad View : 2048 x 1536, 1600 x 1200, 1280 x 960, 1024 x 768, 800 x 600, 640 x 480, 704 x 576
[Q1 / 2 / 3 / 4] 1024 x 768, 800 x 600, 640 x 480 |
| Max. Framerate |
H.265 / H.264 : 30fps@2,048 x 2,048, MJPEG : Max. 15fps |
| Smart Codec / WiseStreamII |
Manual mode (area-based : 5ea) / support |
| Video Quality Adjustment |
H.265 / H.264 : Target bitrate level control, MJPEG : Quality level control |
| Bitrate Control Method |
H.265 / H.264 : CBR or VBR, MJPEG : VBR |
| Streaming Capability |
Multiple streaming (Up to 10 profiles) |
| Audio In |
Selectable (Mic in / Line in / Built-in mic)
Supply voltage : 2.5V DC (4mA), Input impedance: Approx. 2K Ohm |
| Audio Out |
Line out (3.5mm mono jack), Max output level : 1 Vrms |
| Audio Compression Format |
G.711 u-law/G.726 Selectable, G.726 (ADPCM) 8KHz, G.711 8KHz
G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps, AAC-LC : 48Kbps at 8 / 16 / 32 / 48KHz |
| Audio Communication |
Bi-directional (2way) |
| IP |
IPv4, IPv6 |
| Protocol |
TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3 (MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, SIP |
| Security |
HTTPS (SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x Authentication (EAP-TLS, EAP-LEAP) |
| Streaming Method |
Unicast / Multicast |
| Max. User Access |
20 users at unicast mode |
| Edge Storage |
SD/SDHC/SDXC 2slot (up to 512GB) - Continuous recording (1st slot to 2nd slot)
- Motion images recorded in the SD/SDHC/SDXC memory card can be downloaded.
- Camera can detect automatically when the memory is connected
- Memory status display (Normal / Error / Active / Formatting / Lock)
NAS (Network Attached Storage), Local PC for instant recording (Plug-in Viewer only) |
| Application Programming Interface |
ONVIF Profile S/G, SUNAPI, Wisenet open platform |
| Webpage Language |
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Portuguese, Turkish, Polish, Czech, Dutch, Hungary, Greek |
| Web Viewer |
Supported OS : Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12
[Plug-in Free Webviewer]
Supported Browser : Google Chrome 60, MS Edge 40, Mozilla Firefox 55
(Window 64bit only), Apple Safari 10 (Max OS X only)
[Plug-in Webviewer]
Supported Browser : MS Explore 11, Apple Safari 10 (Mac OS X only) |
| Central Management Software |
SmartViewer, SSM |
| ENVIRONMENTAL |
| Operating Temperature / Humidity |
-40°C ~ +55°C (-40°F ~ +131°F) / Less than 90% RH |
| Storage Temperature / Humidity |
-50°C ~ +60°C (-58°F ~ +140°F) / Less than 90% RH |
| Ingress Protection / Vandal Resistance |
IP66 / IK10 |
| ELECTRICAL |
| Input Voltage / Current |
12V DC ±10%, PoE (IEEE802.3af, Class3) |
| Power Consumption |
Max. 12W (12V DC), Max. 12.95W (PoE) |
| MECHANICAL |
| Color / Material |
Ivory / Aluminum |
| Dimension (WxHxD) |
Ø146 x 65.8mm (Ø5.75" x 2.59") |
| Weight |
785g (1.73 lb) |
