Ethernet |
RJ-45 (10/100 BASE-T) |
Video Compression Format |
H.265 / H.264 / MJPEG |
Resolution |
Original view : 2048 x 2048, 1280 x 1280, 1080 x 1080, 960 x 960, 768 x 768, 720 x 720, 640 x 640, 480 x 480
Single panorama : 2048 x 512, 1920 x 480, 1280 x 320, 640 x 160, 704 x 176
Double panorama : 2048 x 1024, 1920 x 960, 1280 x 640, 640 x 320, 704 x 352
Quad View : 2048 x 1536, 1600 x 1200, 1280 x 960, 1024 x 768, 800 x 600, 640 x 480, 704 x 576
[Q1 / 2 / 3 / 4] 1024 x 768, 800 x 600, 640 x 480
|
Max. Framerate |
H.265 / H.264 : 30fps@2,048 x 2,048, MJPEG : Max. 15fps |
Smart Codec / WiseStreamII |
Manual mode (area-based : 5ea) / support |
Video Quality Adjustment |
H.265 / H.264 : Target bitrate level control, MJPEG : Quality level control |
Bitrate Control Method |
H.265 / H.264 : CBR or VBR, MJPEG : VBR |
Streaming Capability |
Multiple streaming (Up to 10 profiles) |
Audio In |
Selectable (Mic in / Line in / Built-in mic)
Supply voltage : 2.5V DC (4mA), Input impedance: Approx. 2K Ohm
|
Audio Out |
Line out (3.5mm mono jack), Max output level : 1 Vrms |
Audio Compression Format |
G.711 u-law/G.726 Selectable, G.726 (ADPCM) 8KHz, G.711 8KHz G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps, AAC-LC : 48Kbps at 16KHz |
Audio Communication |
Bi-directional (2way) |
IP |
IPv4, IPv6 |
Protocol |
TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3 (MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, SIP |
Security |
HTTPS (SSL) login authentication, Digest login authentication
IP address filtering, User access log, 802.1x Authentication (EAP-TLS, EAP-LEAP)
|
Streaming Method |
Unicast / Multicast |
Max. User Access |
20 users at unicast mode |
Edge Storage |
SD/SDHC/SDXC 2slot (up to 512GB) - Continuous recording (1st slot to 2nd slot)
Motion images recorded in the SD/SDHC/SDXC memory card can be downloaded.
Camera can detect automatically when the memory is connected
Memory status display (Normal / Error / Active / Formatting / Lock)
NAS (Network Attached Storage), Local PC for instant recording (Plug-in Viewer only)
|
Application Programming Interface |
ONVIF Profile S/G, SUNAPI, Wisenet open platform |
Webpage Language |
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Portuguese, Turkish, Polish, Czech, Dutch, Hungary, Greek |
Web Viewer |
Supported OS : Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12 [Plug-in Free Webviewer]
Supported Browser : Google Chrome 60, MS Edge 40, Mozilla Firefox 55 (Window 64bit only), Apple Safari 10 (Max OS X only)
[Plug-in Webviewer]
Supported Browser : MS Explore 11, Apple Safari 10 (Mac OS X only)
|
Central Management Software |
SmartViewer, SSM |
