| Video |
|---|
| Imaging Device |
1/1.8" 6MP CMOS |
| Effective Pixels |
2048(H)x2048(V) |
| Min. Illumination |
Color: 0.2 Lux (F2.5, 1/30sec) |
| Video Out |
CVBS : 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P), for Installation |
| Lens |
|---|
| Focal Length (Zoom Ratio) |
1.14mm fixed focal |
| Max. Aperture Ratio |
F2.5 |
| Angular Field of View |
H: 187˚ / V: 187˚ / D: 187˚ |
| Min. Object Distance |
0.3m |
| Operational |
|---|
| Camera Title |
Displayed up to 85 characters |
| Day & Night |
Auto(Electrical) |
| Backlight Compensation |
BLC, HLC, WDR, SSDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
SSNRⅤ |
| Motion Detection |
8ea, polygonal zones |
| Privacy Masking |
6ea, Rectangle zones
- Color: Grey/Green/Red/Blue/Black/White
- Mosaic |
| Gain Control |
Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2~1/12,000sec) |
| Video Rotation |
Flip, Mirror |
| Analytics |
Defocus detection, Motion detection, Tampering |
| Business Intelligence |
People counting, Heatmap |
| Alarm Triggers |
Analytics, Network disconnect |
| Alarm Events |
File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC or NAS recording at event triggers |
| Network |
|---|
| Ethernet |
RJ-45(10/100BASE-T) |
| Video Compression |
H.265/H.264: Main/Baseline/High, MJPEG |
| Resolution |
Original view: 2048x2048, 1280x1280, 1080x1080, 960x960, 768x768, 720x720, 640x640, 480x480
Single panorama: 2048x512, 1920x480, 1280x320, 640x160, 704x176
Double panorama: 2048x1024, 1920x960, 1280x640, 640x320, 704x352
Quad view: 2048x1536, 1600x1200, 1280x960, 1024x768, 800x600, 640x480, 704x576
Q1/2/3/4: 1024x768, 800x600, 640x480 |
| Max. Framerate |
H.264/H.265 : 30fps/25fps@2048x2048(60Hz/50Hz)
MJPEG : Max 15fps |
| Smart Codec |
WiseStreamⅡ |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(6 users) / Multicast
Multiple streaming(Up to 3 profiles) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
| Security |
HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access log
802.1X Authentication(EAP-TLS, EAP-LEAP) |
| Edge Storage |
Micro SD/SDHC/SDXC 1slot 256GB |
| Application Programming Interface |
ONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platform |
| Web Viewer |
Supported OS: Windows 7, 8.1, 10, Mac OS X 10.12, 10.13, 10.14
Recommended Browser: Google Chrome
Supported Browser : MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OS X only) |
| Memory |
1024MB RAM, 256MB Flash |
| Environmental |
|---|
| Operating Temperature / Humidity |
-10°C ~ +55°C(+14°F ~ +131°F) / Less than 90% RH |
| Storage Temperature / Humidity |
-50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH |
| Certification |
IP42 |
| Electrical |
|---|
| Input Voltage |
PoE(IEEE802.3af, Class3) |
| Power Consumption |
PoE: Max 6.4W, typical 4.6W |
| Mechanical |
|---|
| Color / Material |
White / Plastic |
| RAL Code |
RAL9003 |
| Product dimensions / weight |
Ø99x49mm(Ø3.9x1.93"), 320g(0.705 lb) |
