Video |
|
Imaging Device |
1/3" CMOS |
Resolution |
2560x1440, 1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
Max. Framerate |
H.265/H.264 : Max. 30fps at 4M all resolutions, MJPEG : Max. 15fps |
NETD |
None |
Pixel Size |
None |
Min. Illumination |
Color : 0.1Lux (F1.6, 1/30sec) B/W : 0Lux (IR LED On) |
Video Out |
CVBS : 1.0 Vpp/75Ω composite, 720x480(N), 720x576(P) for installation |
Video Transmission Distance |
None |
Lens |
Focal Length (Zoom Ratio) |
3.2~10mm (3.1x) motorized varifocal |
Max. Aperture Ratio |
F1.6(Wide) ~ F2.9(Tele) |
Angular Field of View |
H : 98.6˚(Wide) ~ 30.8˚(Tele), V : 52.3˚(Wide) ~ 17.3˚(Tele), D : 115.7˚(Wide) ~ 35.3˚(Tele) |
Min. Object Distance |
None |
Focus Control |
Simple focus |
Lens Type |
DC auto iris |
Mount Type |
None |
Optional Lens |
None |
Pan / Tilt / Rotate |
Pan / Tilt / Rotate Range |
None |
Pan Range |
None |
Pan Speed |
None |
Tilt Range |
None |
Tilt Speed |
None |
Rotate Range |
None |
Sequence |
None |
Preset Accuracy |
None |
Operational |
Camera Title |
Displayed up to 85 characters |
Direction Indicator |
None |
Day & Night |
Auto(ICR) |
Backlight Compensation |
BLC, WDR, SSDR |
Wide Dynamic Range |
120dB |
Digital Noise Reduction |
SSNR |
Digital Image Stabilization |
None |
Defog |
None |
Motion Detection |
4ea, polygonal zones |
Privacy Masking |
6ea, rectangular zones |
Gain Control |
Low / Middle / High |
White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
LDC |
Support |
Electronic Shutter Speed |
Minimum/Maximum/Anti flicker (1/5~1/12,000sec) |
Digital PTZ |
None |
Video Rotation |
Flip, Mirror, Hallway view(90°/270°) |
Analytics |
Defocus detection, Directional detection, Motion detection, Enter/Exit, Tampering, Virtual line |
Business Intelligence |
None |
Serial Interface |
None |
Alarm I/O |
Input 1ea / Output 1ea |
Alarm Triggers |
Analytics, Network disconnect, Alarm input |
Alarm Events |
File upload via FTP and e-mail, Notification via e-mail, SD/SDHC/SDXC or NAS recording at event triggers, Alarm output, Handover |
Audio In |
Line in |
Audio Out |
None |
IR Viewable Length |
30m(98.42ft) |
IR Illuminator (Optional) |
None |
Water Removal |
None |
Auto Tracking |
None |
Coaxial Protocol |
None |
Color Palettes |
None |
Radiometry |
Temperature Detect Range |
None |
Temperature Accuracy |
None |
Temperature Detection |
None |
Additional |
None |
Network |
Ethernet |
RJ-45 (10/100BASE-T) |
Video Compression |
H.265/H.264 : Main/High, MJPEG |
Audio Compression |
G.711 u-law / G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz, G.726 16Kbps, 24Kbps, 32Kbps, 40Kbps |
Smart Codec |
Manual (5ea area), WiseStreamⅡ |
Video Quality Adjustment |
H.265/H.264 : Target bitrate level control, MJPEG : Quality level control |
Bitrate Control |
H.264/H.265 : CBR or VBR MJPEG : VBR |
Streaming |
Unicast (6 users) / Multicast Multiple streaming (Up to 3 profiles) |
Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP |
Security |
HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access Log 802.1X Authentication |
Application Programming Interface |
ONVIF Profile S/G/T, SUNAPI (HTTP API) |
General |
Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
Web Viewer |
None |
Edge Storage |
Micro SD/SDHC/SDXC 1slot 128GB |
Memory |
512MB RAM, 256MB Flash |
Environmental & Electrical |
Operating Temperature / Humidity |
-40°C~+55°C (-40°F~+131°F) / Less than 95% RH ＊Start up should be done at -30°C or above |
Storage Temperature / Humidity |
-40°C~+60°C (-40°F~+140°F) / Less than 95% RH |
Certification |
IP66, IK10 |
Input Voltage |
PoE(IEEE802.3af, Class3), 12VDC |
Power Consumption |
PoE: Max 11.4W, typical 8W 12VDC: Max 9.6W, typical 7W |
Mechanical |
Color / Material |
Dark grey / Aluminum |
RAL Code |
None |
Product Dimensions / Weight |
Ø78.0 x 259.8mm (Ø3.07 x 10.23"), 900g (1.984 lb) |
Compatible Conduit hole / Gangbox |
3/4"(M25) Single, Double, 4"Octagon |
Hanging Mount (Dome) |
None |
Skin Cover (Dome) |
None |
Weather Cap (Dome) |
None |
Power Module |
None |
Backbox |
SBO-100B1, SBO-147B |
DORI (EN62676-4 standard) |
Detect (25PPM/ 8PPF) |
Wide: 27m(89.86ft) / Tele: 129m(422.61ft) |
Observe (63PPM/ 19PPF) |
Wide: 11m(35.95ft) / Tele: 52m(169.04ft) |
Recognize (125PPM/ 38PPF) |
Wide: 6m(17.97ft) / Tele: 26m(84.52ft) |
Identify (250PPM/ 76PPF) |
Wide: 3m(8.99ft) / Tele: 13m(42.26ft) |
