| Video |
|---|
| Imaging Device |
1/2.8”CMOS |
| Resolution |
3840x2160, 3328x1872,3072x1728, 2592x1944, 2688x1520, 1920x1080, 1600x1200, 1280x1024,
1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
| Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 15fps/12fps(60Hz/50Hz) |
| Min. Illumination |
Color: 0.05Lux(F1.2, 1/30sec)
B/W: 0Lux(IR LED On) |
| Video Out |
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation
USB: Micro USB Type B, 1280x720 for installation |
| Lens |
|---|
| Focal Length (Zoom Ratio) |
2.8~8.4mm(3x) motorized varifocal |
| Max. Aperture Ratio |
F1.2(Wide)~F2.8(Tele) |
| Angular Field of View |
H: 114°(Wide)~40.2°(Tele) / V: 62.0°(Wide)~22.5°(Tele) / D: 133.0°(Wide)~46.3°(Tele) |
| Min. Object Distance |
0.7m (2.23ft) |
| Focus Control |
Simple focus |
| Lens Type |
DC Auto Iris, P iris |
| Operational |
|---|
| Camera Title |
Displayed up to 85 characters |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, HLC, WDR, SSDR |
| Wide Dynamic Range |
extremeWDR |
| Digital Noise Reduction |
SSNRⅤ |
| Digital Image Stabilization |
Support(built-in gyro sensor) |
| Defog |
Support |
| Motion Detection |
8ea, 8point Polygonal zones |
| Privacy Masking |
32ea, polygonal zones
- Color : Gray, Green, Red, Blue, Black, White
- Mosaic |
| Gain Control |
Support |
| White Balance |
ATW / Narrow ATW / AWC / Manual / Indoor / Outdoor |
| LDC |
Support |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (1/5~1/12,000sec) |
| Video Rotation |
Flip, Mirror, Hallway view(90˚/270˚) |
| Analytics |
Defocus detection, Directional detection, Motion detection, Digital auto tracking, Appear/Disappear,
Enter/Exit, Loitering, Tampering, Virtual line, Audio detection, Sound classification,
Shock detection, Face/upper body detection |
| Business Intelligence |
People counting, Queue management, Heatmap |
| Alarm I/O |
2 configurable I/O ports |
| Alarm Triggers |
Analytics, Network disconnect, Alarm input |
| Alarm Events |
File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC or NAS recording at event triggers
Alarm output
PTZ Preset
Handover
Audio playback |
| Audio In |
Selectable(mic in/line in)
Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
| Audio Out |
Line out, Max.output level: 1Vrms |
| IR Viewable Length |
40m(131.23ft) |
| Network |
|---|
| Ethernet |
RJ-45(10/100/1000BASE-T) |
| Video Compression |
H.265/H.264: Main/High, MJPEG |
| Audio Compression |
G.711 u-law /G.726 Selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
AAC-LC: 48Kbps at 16KHz |
| Smart Codec |
Manual(5ea area), WiseStreamⅡ |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(20 users) / Multicast
Multiple streaming(Up to 10 profiles) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP,
ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast) |
| Security |
HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access log
802.1X Authentication(EAP-TLS, EAP-LEAP)
Device Certificate(Hanwha Techwin Root CA) |
| Application Programming Interface |
ONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platform |
| General |
|---|
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish,, Portuguese, Czech,
Polish, Turkish, Dutch, Hungarian, Greek |
| Web Viewer |
Supported OS: Windows 8.1 or later, Mac OS X 10.13 or later
Recommended Browser: Google Chrome
Supported Browser: MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OS X only) |
| Edge Storage |
Micro SD/SDHC/SDXC 2slot 512GB(256Gx2) |
| Memory |
4GB RAM, 512MB Flash |
| Environmental & Electrical |
|---|
| Operating Temperature / Humidity |
-50°C~+60°C(-58°F ~ +140°F) / Less than 95% RH(non condensing)
* Start up should be done at above -30°C |
| Storage Temperature / Humidity |
-50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH |
| Certification |
IP66/IP67, IK10, NEMA4X |
| Input Voltage |
PoE(IEEE802.3af), 12VDC, 24VAC |
| Power Consumption |
PoE : Max 12.,95W, typical 10.5W
12VDC : Max 12.5W, typical 9.4W
24VAC : Max 14.5W, typical 11.2W |
| Mechanical |
|---|
| Color / Material |
Dark grey / Aluminum |
| Product dimensions / weight |
Ø91x368.6mm(Ø3.85"x14.51"), 2.2kg(4.85 lb) |
| DORI (EN62676-4 standard) |
|---|
| Detect (25PPM/ 8PPF) |
Wide: 49.9m(163.71ft) / Tele: 209.9m(688.65ft) |
| Observe (63PPM/ 19PPF) |
Wide: 19.9m(65.29ft) / Tele: 83.9m(275.26ft) |
| Recognize (125PPM/ 38PPF) |
Wide: 10.0m(32.80ft) / Tele: 42.0m(137.80ft) |
| Identify (250PPM/ 76PPF) |
Wide: 5.0m(16.40ft) / Tele: 21.0m(68.90ft) |
