Video |
|
Imaging Device |
1/2.8" CMOS x 2CH |
Resolution |
1920x1080, 1600x1200, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
Max. Framerate |
H.265/H.264: 2MP Max. 30fps/25fps(60Hz/50Hz) MJPEG: Max. 30fps/25fps(60Hz/50Hz) |
Min. Illumination |
Color: 0.035lux(F2.2, 1/30sec, 30IRE) BW: 0.0035lux(F2.2, 1/30sec, 30IRE), 0lux(IR LED on) |
Video Out |
USB: micro USB Type B, 1280x720 for installation |
Lens |
Focal Length (Zoom Ratio) |
3~6mm(2x) motorized varifocal per CH |
Max. Aperture Ratio |
F2.2(Wide)~F3.1(Tele) |
Angular Field of View |
H: 107˚(Wide)~56.3˚(Tele) V: 57˚(Wide)~31.5˚(Tele) D: 126˚(Wide)~64.3˚(Tele) |
Min. Object Distance |
0.5m(1.64ft) |
Focus Control |
Simple focus |
Lens Type |
Fixed IRIS |
Pan / Tilt / Rotate |
Pan / Tilt / Rotate Range |
0~355°/0~78°/0~180° |
Operational |
Camera Title |
Displayed up to 85 characters |
Day & Night |
Auto(ICR) |
Backlight Compensation |
BLC, WDR, SSDR |
Wide Dynamic Range |
extremeWDR(120dB) |
Digital Noise Reduction |
WiseNRⅡ(Based on AI engine), SSNRⅤ |
Motion Detection |
8ea, 8point Polygonal zones |
Privacy Masking |
6ea, Quadrangle zones - Color : Gray, Black, White |
Gain Control |
Support |
White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
LDC |
Support |
Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (1/5~1/12,000sec) Auto prefer shutter control(Based on AI engine) |
Video Rotation |
Flip, Mirror, Hallway view (90°/270°) - Each channel separately |
Analytics |
Classified object type : Person/Face/Vehicle/License plate Attributes : Vehicle(Type:car/bus/truck/motorcycle/bicycle) Support Bestshot Analytics events based on AI engine - Object detection, Virtual line(Crossing/Direction), Virtual area(Loitering/Intrusion/Enter/Exit) Analytics events* - Defocus detection, Motion detection, Tampering, Virtual area(Appear/Disappear) * Support Audio detection, Sound classification via optional SPM-4210 I/O box |
Alarm I/O |
* Support Alarm via optional SPM-4210 I/O box |
Alarm Triggers |
Analytics, Network disconnect, Alarm input via optional SPM-4210 I/O box |
Alarm Events |
When alarm trigger occurred - File upload(image) : e-mail/FTP - Notification : e-mail - Recording : SD/SDHC/SDXC or NAS recording at event triggers - Handover(PTZ preset, Send message by HTTP/HTTPS/TCP) - * Alarm output via optional SPM-4210 I/O box |
Audio In |
* Audio in via optional SPM-4210 I/O box |
Audio Out |
* Audio out via optional SPM-4210 I/O box |
IR Viewable Length |
25m(82ft) |
Network |
Ethernet |
Metal shielded RJ-45 (10/100/1000BASE-T) |
Video Compression |
H.265/H.264: Main/Baseline/High, MJPEG |
Smart Codec |
Manual(5ea area), WiseStreamⅡ, WiseStreamⅢ(Based on AI engine) |
Bitrate Control |
H.264/H.265: CBR or VBR MJPEG: VBR |
Streaming |
Unicast(10 users) / Multicast 5 profiles per channel |
Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast) |
Security |
TPM 2.0 (FIPS 140-2 level 2) HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2) Device Certificate(Hanwha Techwin Root CA, pre-installed) Secure by default certificate Secure OS/Boot/Storage, Verify firmware forgery |
Application Programming Interface |
ONVIF Profile S/T SUNAPI(HTTP API) Open platform |
General |
Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Greek, Hungarian |
Edge Storage |
Micro SD/SDHC/SDXC 1slot Max. 512GB |
Memory |
2GB RAM, 512MB Flash |
Environmental & Electrical |
Operating Temperature / Humidity |
-40°C~+55°C(-40°F ~ +131°F) / Less than 95% RH(Non-condensing) |
Storage Temperature / Humidity |
-50°C~+60°C (-58°F~+140°F) / Less than 95% RH(Non-condensing) |
Certification |
IP66, IK10, NEMA4X |
Input Voltage |
PoE+(IEEE802.3at, Class4) |
Power Consumption |
PoE+: Max 20W, typical 15.5W |
Mechanical |
Color / Material |
White / Aluminum Hard-coated dome bubble |
RAL Code |
RAL9003 |
Product Dimensions / Weight |
215(W)x135(D)x93.2(H)mm(8.46"x5.31"x3.67") / 1330g |
Compatible Conduit hole / Gangbox |
3/4" (M25) single, double, 4" octagon, 4" square |
DORI (EN62676-4 standard) |
Detect (25PPM/ 8PPF) |
Wide: 28.4m(93.22ft) / Tele: 71.8m(235.45ft) |
Observe (63PPM/ 19PPF) |
Wide: 11.4m(37.29ft) / Tele: 28.7m(94.18ft) |
Recognize (125PPM/ 38PPF) |
Wide: 5.7m(18.64ft) / Tele: 14.4m(47.09ft) |
Identify (250PPM/ 76PPF) |
Wide: 2.8m(9.32ft) / Tele: 7.2m(23.55ft) |
