Video |
|
Imaging Device |
None |
Resolution |
1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
Max. Framerate |
H.265/H.264: 2MP Max. 60fps/50fps(60Hz/50Hz) MJPEG: Max. 30fps/25fps(60Hz/50Hz) |
NETD |
None |
Pixel Size |
None |
Min. Illumination |
None |
Video Out |
CVBS : 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P), for installation |
Video Transmission Distance |
None |
Lens |
Focal Length (Zoom Ratio) |
None |
Max. Aperture Ratio |
None |
Angular Field of View |
None |
Min. Object Distance |
None |
Focus Control |
None |
Lens Type |
None |
Mount Type |
None |
Optional Lens |
SLA-2M2402D(2MP 2.4mm) SLA-2M2802D(2MP 2.8mm) SLA-2M3602D(2MP 3.6mm) SLA-2M6002D(2MP 6.0mm |
Pan / Tilt / Rotate |
Pan / Tilt / Rotate Range |
None |
Pan Range |
None |
Pan Speed |
None |
Tilt Range |
None |
Tilt Speed |
None |
Rotate Range |
None |
Sequence |
None |
Preset Accuracy |
None |
Operational |
Camera Title |
Displayed up to 85 characters |
Direction Indicator |
None |
Day & Night |
Auto(Electrical) |
Backlight Compensation |
BLC, HLC, WDR, SSDR |
Wide Dynamic Range |
150dB |
Digital Noise Reduction |
SSNRⅤ |
Digital Image Stabilization |
Support |
Defog |
Support |
Motion Detection |
8ea, 8point polygonal zones |
Privacy Masking |
32ea, polygonal zones - Color: Grey/Green/Red/Blue/Black/White - Mosaic |
Gain Control |
Low / Middle / High |
White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
LDC |
Support |
Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2~1/12,000sec) |
Digital PTZ |
None |
Video Rotation |
Flip, Mirror, Hallway view(90˚/270˚) |
Analytics |
Defocus detection, Directional detection, Face detection, Fog detection, Motion detection, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line |
Business Intelligence |
None |
Serial Interface |
None |
Alarm I/O |
None |
Alarm Triggers |
Analytics, Network disconnect |
Alarm Events |
File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC recording at event triggers |
Audio In |
None |
Audio Out |
None |
IR Viewable Length |
None |
IR Illuminator (Optional) |
None |
Water Removal |
None |
Auto Tracking |
None |
Coaxial Protocol |
None |
Color Palettes |
None |
Radiometry |
Temperature detect range |
None |
Temperature accuracy |
None |
Temperature detection |
None |
Additional |
None |
Network |
Ethernet |
RJ-45(10/100/1000BASE-T) |
Video Compression |
H.265/H.264: Main/Baseline/High, MJPEG |
Audio Compression |
None |
Smart Codec |
Manual(5ea area), WiseStreamⅡ |
Video Quality Adjustment |
None |
Bitrate Control |
H.264/H.265: CBR or VBR MJPEG: VBR |
Streaming |
Unicast(20 users) / Multicast Multiple streaming(Up to 10 profiles) |
Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP |
Security |
HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP) |
Application Programming Interface |
ONVIF Profile S/T SUNAPI(HTTP API) |
General |
Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
Web Viewer |
None |
Edge Storage |
Micro SD/SDHC/SDXC 2 slots 256GB (One for each channel) |
Memory |
3GB RAM, 768MB Flash |
Environmental & Electrical |
Operating Temperature / Humidity |
-40°C ~ +55°C(-40°F ~ +131°F) / Less than 90% RH |
Storage Temperature / Humidity |
-50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH |
Certification |
IP66, IK10 |
Input Voltage |
PoE(IEEE802.3af, Class3) |
Power Consumption |
Typical: 12.00W, Max: 12.95W |
Mechanical |
Color / Material |
White / Aluminum |
RAL Code |
RAL9003 |
Product dimensions / weight |
Ø197.6x84mm(7.78x3.31"), 1250g(2.76lb) |
Compatible Conduit hole / Gangbox |
3/4" |
Hanging mount(Dome) |
SBP-201HMW |
Skin cover(Dome) |
None |
Weather cap(Dome) |
None |
Power module |
None |
Backbox |
None |
DORI (EN62676-4 standard) |
Detect (25PPM/ 8PPF) |
None |
Observe (63PPM/ 19PPF) |
None |
Recognize (125PPM/ 38PPF) |
None |
Identify (250PPM/ 76PPF) |
None |
