Ethernet |
10 / 100 Base-TX, M12 connector (4 poles, Female, D-coding) |
Video Compression Format |
H.264 (MPEG-4 part 10/AVC), MJPEG |
Resolution |
1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 |
Maximum Frame Rate |
H.264: Maximum 60 fps at all resolutions
MJPEG: 1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768 (maximum 15 fps)
800 x 600, 800 x 450, 640 x 480, 640 x 360, 320 x 240, 320 x 180 (maximum 30 fps) |
Video Quality Adjustment |
H.264: Compression level, Target bitrate level control,
MJPEG: Quality level control |
Bit-Rate |
Control Method: H.264: CBR or VBR, MJPEG: VBR |
Streaming Capability |
Multiple streaming (Up to 10 profiles) |
IP |
IPv4, IPv6 |
Protocol |
TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3 (MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
Security |
HTTPS (SSL) login authentication, digest login authentication, IP address filtering, user access log, 802.1x authentication |
Streaming Method |
Unicast / Multicast |
Maximum User Access |
15 users at Unicast mode |
Memory Slots |
microSD/SDHC/SDXC
Recorded data in the SDXC/SDHC/SD memory card can be downloaded |
Application Programming Interface |
ONVIF profile S, HTTP API v2.0, SVNP 1.2 |
Webpage Language |
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Danish, Portuguese, Turkish, Polish, Czech, Rumanian, Serbian, Dutch, Croatia, Hungarian, Greek, Finnish, Norwegian |
Web Viewer |
Supported OS: Windows XP / VISTA / 7 / 8, MAC OS X 10.7
Supported Browsers: Microsoft Internet Explorer (versions 7 and up)
Mozilla Firefox (version 9 to version 19)
Google Chrome (version 15 to version 25)
Apple Safari ( versions 6.0.2 (Mac OS X 10.8, 10.7 only), 5.1.7) |
CMS |
SmartViewer 4.0, SSM (DVD included) |
Mobile View Support |
iPOLiS mobile v2.0 or higher |
