Video |
|
Imaging Device |
1/2.8" CMOS |
Resolution |
1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
Max. Framerate |
H.265/H.264: Max. 60fps/50fps(60Hz/50Hz) MJPEG: Max. 30fps/25fps(60Hz/50Hz) |
Min. Illumination |
Color: 0.05Lux(F1.6, 1/30sec) BW: 0Lux(IR LED On) |
Video Out |
None |
Lens |
Focal Length (Zoom Ratio) |
4.25~170mm(40x) zoom (digital 32x, total 1280x zoom) |
Max. Aperture Ratio |
F1.6(Wide)~F4.95(Tele) |
Angular Field of View |
H: 65.66˚(Wide)~1.88˚(Tele) / V: 39.40˚(Wide)~1.09˚(Tele) |
Min. Object Distance |
3m(9.84ft) |
Focus Control |
Oneshot AF, Focus save |
Lens Type |
DC auto iris |
Pan / Tilt / Rotate |
Pan Range |
360˚ Endless |
Pan Speed |
Max. 500˚/sec, Manual: 0.024˚/sec~250˚/sec |
Tilt Range |
110˚(-20˚~90˚) |
Tilt Speed |
Max. 350˚/sec, Manual: 0.024˚/sec~250˚/sec |
Sequence |
Preset(300ea), Swing, Group(6ea), Trace, Tour, Auto Run, Schedule |
Preset Accuracy |
±0.1˚, Pan/Tilt correction |
Operational |
Camera Title |
Displayed up to 85 characters |
Direction Indicator |
Support |
Day & Night |
Auto(ICR)/Color/BW/Schedule |
Backlight Compensation |
BLC, HLC, WDR, SSDR |
Wide Dynamic Range |
Extreme WDR(150dB) |
Digital Noise Reduction |
SSNRⅤ |
Digital Image Stabilization |
Support(built-in gyro sensor) |
Defog |
Support |
Motion Detection |
8ea, 8point polygonal zones |
Privacy Masking |
32ea, polygonal Support - Color: Grey/Green/Red/Blue/Black/White - Mosaic |
Gain Control |
Manual / Max |
White Balance |
ATW /Narrow ATW /AWC /Manual /Indoor /Outdoor /Mercury /Sodium |
LDC |
None |
Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2~1/12,000sec) |
Video Rotation |
Flip, Mirror |
Analytics |
Directional detection, Fog detection, Face detection, Motion detection, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Shock detection * Audio detection, Sound classification(with NW I/O Box) |
Business Intelligence |
None |
Serial Interface |
None |
Alarm I/O |
None |
Alarm Triggers |
Analytics, Network disconnect * Alarm input(with NW I/O Box) |
Alarm Events |
File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers PTZ Preset Handover * Alarm output(with NW I/O Box) |
Audio In |
None |
Audio Out |
None |
IR Viewable Length |
200m(656.17ft), Wise IR |
IR Illuminator (Optional) |
None |
Water Removal |
Support(with wiper) |
Auto Tracking |
Object auto tracking(Person/Vehicle), Target lock tracking |
Network |
Ethernet |
Metal shielded RJ-45(10/100BASE-T) |
Video Compression |
H.265/H.264: Main/Baseline/High, MJPEG |
Audio Compression |
None |
Smart Codec |
Manual(5ea area), WiseStreamⅡ |
Video Quality Adjustment |
H.264/H.265: Target bitrate level control MJPEG: Target bitrate level control |
Bitrate Control |
H.264/H.265: CBR or VBR MJPEG: VBR |
Streaming |
Unicast(20 users) / Multicast (128 user) Multiple streaming(Up to 10 profiles) |
Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour,LLDP, SRTP |
Security |
HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP) Device certificate(Hanwha Techwin Root CA) Cyber security assuarance program UL CAP(UL 2900-1) |
Application Programming Interface |
ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform |
General |
Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
Web Viewer |
None |
Edge Storage |
Micro SD/SDHC/SDXC 2slot 1TB |
Memory |
4GB RAM, 512MB Flash |
Environmental & Electrical |
Operating Temperature / Humidity |
Normal : -40°C~+55°C(-40°F ~ +131°F) / Maximum Temperature based on NEMA-TS 2(2.2.7) : +74°C(+165°F) * Start up should be done at above -30°C Less than 95% RH(Non-condensing) |
Storage Temperature / Humidity |
-50°C~+60°C (-58°F~+140°F) / Less than 95% RH(Non-condensing) |
Certification |
IP66, IK10, NEMA4X, NEMA-TS 2(2.2.8, 2.2.9) |
Input Voltage |
HPoE(IEEE802.3bt, Class6, Type3, Injector included) |
Power Consumption |
Typical 20W, Max 42W |
Mechanical |
Color / Material |
White, Black / Aluminum+Polycarbontate |
RAL Code |
White: RAL9003 / Black: RAL9005 |
Product dimensions / weight |
Ø184.9x318.8mm(7.28x12.55") / 5.4Kg(11.90lb) |
DORI (EN62676-4 standard) |
Detect (25PPM/ 8PPF) |
Wide: 59.5m(195.3ft) / Tele: 2340.4m(7678.4ft) |
Observe (63PPM/ 19PPF) |
Wide: 23.8m(78.1ft) / Tele: 936.2m(3071.4ft) |
Recognize (125PPM/ 38PPF) |
Wide: 11.9m(39.1ft) / Tele: 468.1m(1535.7ft) |
Identify (250PPM/ 76PPF) |
Wide: 6.0m(19.5ft) / Tele: 234.0m(767.8ft) |
