Hanwha Wisenet 2MP Outdoor IR PTZ Camera, H.265, 37x Zoom WDR, IP66, IK10, 6-222mm - HAN-XNP-6371RH

Description

Description

With cutting-edge WDR technology, the Hanwha HAN-XNP-6371RH conquers limitations found in conventional WDR cameras while producing clear and vivid images through 150dB WDR. Part of the Wisenet X series, this camera can achieve optimal performance in low-light conditions by capturing and producing flawless images regardless of the environment or time of day. Using WiseStream II, the HAN-XNP-6371RH reduces data by up to 99% when combined with H.265 compression, through this, system costs are greatly reduced without compromising image quality. Installation is convenient as you can connect cameras and mobile devices through USB and Wi-Fi, so no additional devices are required, saving time and money. The HAN-XNP-6371RH is jam-packed with other features such as loitering detection, queue management, sound classification, lens distortion correction, fog detection and PTZ handover, making this camera a holistic solution for a variety of security environments.

Features
  • Max. 2MP (1920 x 1080) resolution
  • 6 - 222, (37x), 16x digital zoom
  • H.265, H.264, MJPEG codec supported, multiple streaming
  • WiseStream support
  • DIS and shock detection with built-in gyro sensor
  • Intelligent video/audio analytics, defog
  • Day and night (ICR), WDR (150dB)
  • SD / SDHC / SDXC memory 2 slots
  • Max. IR viewable length 350m
  • IP66, IK10
Datasheet
Tech Specs

VIDEO

Imaging Device

1 / 2" 2MP CMOS

Effective Pixels

1937 (H) X 1097 (V)

Min. Illumination

Color : 0.01 lux ( F1.5, 1/30sec), BW : 0 Lux (IR LED)

Video Out

CVBS : 1.0 Vp-p / 75Ω composite, 720x480 (N), 720x576 (P), for installation

LENS

Focal Length (Zoom Ratio)

6~222mm (37x) zoom

Max. Aperture Ratio

F1.5(Wide)~F4.6(Tele)

Angular Field of View

H : 59.3°(Wide) ~ 1.9°(Tele) / V : 35.8°(Wide)~1.1°(Tele)

Min. Object Distance

1.5m (3.28ft)

Focus Control

OneShot AF

Lens Type

DC auto iris

PAN / TILT / ROTATE

Pan Range

360˚ Endless

Pan Speed

Preset : 400˚/ sec, Manual : 0.024˚/ sec ~ 250˚/ sec

Tilt Range

190˚(-5˚ ~ 185˚)

Tilt Speed

Preset : 300˚/sec, Manual : 0.024˚/ sec ~ 250˚/ sec

Sequence

Preset (300ea), Swing, Group (6ea), Trace, Tour, Auto Run, Schedule

Preset Accuracy

±0.2˚

Azimuth

Support

Auto Tracking

Support

OPERATIONAL

IR Viewable Length

350m (1,148.29ft)

Camera Title

Displayed up to 85 characters

Day & Night

Auto (ICR)

Backlight Compensation

BLC, HLC, WDR, SSDR

Wide Dynamic Range

150dB

Digital Noise Reduction

SSNR V

Digital Image Stabilization

Support (built-in gyro sensor)

Defog

Support

Motion Detection

8ea, rectangular zones

Privacy Masking

24ea, rectangular zones

  • Color : Grey / Green / Red / Blue / Black / White

  • Mosaic

Gain Control

Low / Middle / High

White Balance

ATW / AWC / Manual / Indoor / Outdoor

Electronic Shutter Speed

Minimum / Maximum / Anti flicker ( 2 ~ 1 / 12,000 sec )

Video Rotation

Flip, Mirror

Analytics

Defocus detection, Directional detection, Fog detection, Face detection, Motion detection,

Digital auto tracking, Appear / Disappear, Enter / Exit, Loitering, Tampering, Virtual line, Audio detection, Sound classification, Shock detection

Serial Interface

RS-485 (Samsung-T, Pelco-D / P, Panasonic, Bosch, AD, GE, Vicon, Honeywell)

Alarm I/O

Input 4ea / Output 2ea

Alarm Triggers

Analytics, Network disconnect, Alarm input

Alarm events

File upload via FTP and e-mail Notification via e-mail

SD/SDHC/SDXC or NAS recording at event triggers Alarm output

PTZ Preset

Audio In

Selectable(mic in / line in / built-in mic)

Supply voltage : 2.5VDC(4mA), Input impedance : 2K Ohm

Audio out

Line out, Max.output level : 1Vrms

NETWORK

Ethernet

RJ-45 (10/100BASE-T) / SFP (Optional)

Video Compression

H.265 / H.264 : Main / Baseline / High, MJPEG

Resolution

1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 448, 720 x 576,

720 x 480, 640 x 480, 640 x 360, 320 x 240

Max. Framerate

H.265 / H.264: Max. 60fps / 50fps (60Hz / 50Hz) MJPEG : Max. 30fps / 25fps (60Hz / 50Hz)

Smart Codec

Manual (5ea area), WiseStream II

Video Quality Adjustment

H.264 / H.265 : Target bitrate level control MJPEG : Target bitrate level control

Bitrate Control

H.264 / H.265 : CBR or VBR MJPEG : VBR

Streaming

Unicast (20 users) / Multicast

Multiple streaming (Up to 10 profiles)

Audio Compression

G.711 u-law / G.726 Selectable G.726 (ADPCM) 8KHz, G.711 8KHz

G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps AAC-LC : 48Kbps at 16KHz

Protocol

IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP (TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour

Security

HTTPS (SSL) login authentication, Digest login authentication, IP address filtering, User access log, 802.1X authentication (EAP-TLS, EAP-LEAP)

Edge Storage

Micro SD/SDHC/SDXC 1slot 256GB

ApplicationProgrammingInterface

ONVIF Profile S/G, SUNAPI(HTTP API), Wisenet open platform

Webpage Language

English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek

Web Viewer

Supported OS : Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12 Recommended Browser : Google Chrome

Supported Browser : MS Explorer11, MS Edge, Mozilla Firefox (Window 64bit only), Apple Safari (Mac OS X only)

Memory

1024MB RAM, 256MB Flash

ENVIRONMENTAL

Operating Temperature / Humidity

-50°C~+55°C(-122°F~+131°F) / Less than 90% RH

Storage Temperature / Humidity

-50°C~+60°C(-122°F~+140°F) / Less than 90% RH

Certification

IP66, IK10

ELECTRICAL

Input Voltage

24VAC

Power Consumption

24VAC : Max 90W

MECHANICAL

Color / Material

Body : Ivory / Plastic, Head : Black / Plastic

Product dimensions / weight

Ø236.9 x 407.7mm (9.33x16.05"), 7.1Kg (15.65 lb)

Hanging mount (Dome)

SBP-303HF (SFP)

Read more

Hanwha Wisenet 2MP Outdoor IR PTZ Camera, H.265, 37x Zoom WDR, IP66, IK10, 6-222mm - HAN-XNP-6371RH

Product form

SKU: XNP-6371RH

Out of stock

$4,396.00 Incl. GST
