| VIDEO |
| Imaging Device |
1/2.8" 2M CMOS |
| Total Pixels |
1,945(H) x 1,109(V) 2.16M |
| Effective Pixels |
1,945(H) x 1,097(V) 2.13M |
| Scanning System |
Progressive Scan |
| Min. Illumination |
Color : 0.04Lux (F2.0), B/W : 0Lux (IR LED On) |
| S / N Ratio |
50dB |
| Video Out |
USB : Micro USB type B, 1280 x 720, for installation |
| LENS |
| Focal Length (Zoom Ratio) |
3.6mm fixed |
| Max. Aperture Ratio |
F2.0 |
| Angular Field of View |
H : 94.8° / V : 49.3° / D : 114.3° |
| Focus Control |
Manual |
| Lens / Mount Type |
Fixed / Board type |
| PAN / TILT / ROTATE |
| Pan / Tilt / Rotate Range |
±5° / 0° ~ 67° / ±90° |
| OPERATIONAL |
| IR Viewable Length |
15m (49.21ft) |
| Camera Title |
Off / On (Displayed up to 85 characters)
- W/W : English / Numeric / Special characters
- China : English / Numeric / Special / Chinese characters
- Common : Multi-line (Max. 5), Color (Gray / Green / Red / Blue / Black / White), Transparency, Auto scale by resolution |
| Day & Night |
Auto (ICR) / Color / B/W / Schedule |
| Backlight Compensation |
Off / BLC / HLC (Masking / Dimming), WDR |
| Wide Dynamic Range |
150dB |
| Contrast Enhancement |
SSDR (Off / On) |
| Digital Noise Reduction |
SSNRV (2D + 3D noise filter) (Off / On) |
| Digital Image Stabilization |
Off / On |
| Defog |
Off / Auto / Manual |
| Motion Detection |
Off / On (8ea, 8point polygonal zones), Handover |
| Privacy Masking |
Off / On (32ea, polygonal zones)
- Color : Gray / Green / Red / Blue / Black / White - Mosaic |
| Gain Control |
Off / Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor (Included mercury & Sodium) |
| Contrast |
Level adjustment |
| LDC (Lens Distortion Correction) |
Off / On (5 Levels with min / max) |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2 ~ 1/12,000sec) |
| Digital PTZ |
24x, Digital PTZ (Preset, Group) |
| Flip / Mirror |
Off / On, Hallway view : 90°/270° |
| Video & Audio Analytics |
Tampering, Loitering, Directional detection, Defocus detection, Fog detection, Virtual line, Enter/Exit, (Dis)Appear, Audio detection, Face detection,
Motion detection, Digital auto tracking, Sound classification (w/ external MIC) |
| Alarm Triggers |
Motion detection, Video & Audio analytics, Network disconnect |
| Alarm Events |
File upload via FTP, E-mail, Notification via E-mail, Local storage (SD/SDHC/SDXC) or NAS recording at event triggers, External output, DPTZ preset |
| Audio Noise Reduction |
Off / On |
| Pixel Counter |
Support |
| NETWORK |
| Ethernet |
M12 connector (10/100 BASE-T) |
| Video Compression Format |
H.265 / H.264 (MPEG-4 part 10/AVC) : Main / Baseline / High, MJPEG |
| Resolution |
1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 448, 720 x 576, 720 x 480, 640 x 480, 640 x 360, 320 x 240 |
| Max. Framerate |
H.265 / H.264 : Max. 60fps at all resolutions, MJPEG : Max. 30fps |
| Smart Codec |
Manual mode (Area-based : 5ea) |
| WiseStream II |
Support |
| Video Quality Adjustment |
H.265 / H.264, MJPEG : Target bitrate level control |
| Bitrate Control Method |
H.265 / H.264 : CBR or VBR, MJPEG : VBR |
| Streaming Capability |
Multiple streaming (Up to 10 profiles) |
| Audio In |
Selectable (Mic in / Line in), Built-in micophone
Supply voltage : 2.5V DC (4mA), Input impedance : approx. 2K Ohm |
| Audio Out |
Line out, Max output level : 1Vrms |
| Audio Compression Format |
G.711 u-law/G.726 selectable, G.726 (ADPCM) 8KHz, G.711 8KHz,
G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps, AAC-LC : 48Kbps at 16KHz |
| Audio Communication |
Bi-dierctional (2-Way) |
| IP |
IPv4, IPv6 |
| Protocol |
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour |
| Security |
HTTPS(SSL) login authentication, Digest login authentication,
IP address filtering, User access log, 802.1X authentication (EAP-TLS, EAP-LEAP) |
| Streaming Method |
Unicast / Multicast |
| Max. User Access |
20 users at unicast mode |
| Edge Storage |
SD/SDHC/SDXC 1slot (up to 256GB)
- Motion Images recorded in the SD/SDHC/SDXC memory card can be downloaded. NAS (Network Attached Storage), Local PC for instant recording |
| Application Programming Interface |
ONVIF profile S/G, SUNAPI (HTTP API), Wisenet Open Platform |
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Web Viewer |
Supported OS : Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12
Non-plugin Webviewer
- Supported Browser : Google Chrome 54, MS Edge 38, Mozilla Firefox 49
(Window 64bit only), Apple Safari 9 (Mac OS X only)
Plug-in Webviewer
- Supported Browser : MS Explore 11, Apple Safari 9 (Mac OS X only) |
| Central Management Software |
SmartViewer, SSM |
| ENVIRONMENTAL |
| Operating Temperature / Humidity |
-30°C ~ +55°C (-22°F ~ +131°F) / Less than 90% RH
* Start up should be done at above -20°C (-4°F) |
| Storage Temperature / Humidity |
-50°C ~ +60°C (-58°F ~ +140°F) / Less than 90% RH |
| Ingress Protection |
IP66 |
| Vibration Resistance |
EN55011:2009+A1:2010, EN50581:2012,EN50121-3-2:2015, EN61000-4-2:2009,
EN61000-4-3:2006+A2:2010, EN61000-4-4:2012, EN61000-4-5:2014
EN61000-4-6:2009, EN50155:2007, NEMA 4X |
| Vandal Resistance |
IK10, NEMA4X |
| ELECTRICAL |
| Input Voltage / Current |
PoE (IEEE802.3af, Class3) |
| Power Consumption |
Max. 6.7W |
| MECHANICAL |
| Color / Material |
Ivory (NCS S 0502-Y) / Metal |
| Dimensions (WxHxD) |
98.9 x 52.0 x 100.0mm (3.89" x 2.05" x 3.94") |
| Weight |
295g (0.65 lb) |
