| Video |
| Imaging Device |
1/2.8" 2M CMOS |
| Total Pixels |
1,945(H) x 1,109(V) 2.16M |
| Effective Pixels |
1,945(H) x 1,097(V) 2.13M |
| Scanning System |
Progressive |
| Min. Illumination |
Color : 0.03 Lux (F1.6, 1/30sec), B/W : 0Lux (IR LED on) |
| S / N Ratio |
50dB |
| Video Out |
CVBS : 1.0 Vp-p / 75Ω Composite, 720 x 480(N), 720 x 576(P), for Installation
USB : Micro USB Type B, 1280 x 720, for Installation |
| Lens |
| Focal Length (Zoom Ratio) |
5.2 ~ 62.4mm (Optical 12X) |
| Max. Aperture Ratio |
F1.6(Wide) ~ F3.0(Tele) |
| Angular Field of View |
H : 54.58˚(Wide) ~ 5.30˚(Tele) / V : 32.19˚(Wide) ~ 3.00˚(Tele) / D : 61.40˚(Wide) ~ 6.06˚(Tele) |
| Min. Object Distance |
2.1m (6.89ft) |
| Focus Control |
Auto / Manual / One shot AF |
| Lens / Mount Type |
DC Auto Iris / Board-in Type |
| Pan / Tilt / Rotate |
| Pan / Tilt / Rotate Range |
0° ~ 354° / 0° ~ 75° / 0° ~ 355° |
| Operational |
| IR Viewable Length |
70m (229.66ft) |
| Camera Title |
Off / On (Displayed up to 85 Characters)
- W/W : English / Numeric / Special Characters
- China : English / Numeric / Special / Chinese Characters
- Common : Multi-line (Max. 5), Color (Grey / Green / Red / Blue / Black / White), Transparency, Auto scale by Resolution |
| Day & Night |
Auto (ICR) / Color / B/W / External / Schedule |
| Backlight Compensation |
Off / BLC / HLC (Masking / Dimming), WDR |
| Wide Dynamic Range |
150dB |
| Contrast Enhancement |
SSDR (Off / On) |
| Digital Noise Reduction |
SSNRV (2D + 3D Noise filter) (Off / On) |
| Digital Image Stabilization |
Off / On |
| Defog |
Off / Auto / Manual |
| Motion Detection |
Off / On (8ea, 8Point polygonal zones), Handover |
| Privacy Masking |
Off / On (32ea, Rectangle zones) - Color : Grey / Green / Red / Blue / Black / White - Mosaic |
| Gain Control |
Off / Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor (Included Mercury & Sodium) |
| Contrast |
Level Adjusment |
| LDC (Lens Distortion Correction) |
Off / On (5 Levels with Min / Max) |
| Electronic Shutter Speed |
Minimum / Maximum / Anti Flicker (2 ~ 1/12,000sec) |
| Digital Zoom |
24x |
| Preset |
300ea |
| Rotate Image |
Flip : Off / On , Mirror : Off / On, Hallway : 90° / 270° |
| Video & Audio Analytics |
Tampering, Loitering, Directional detection, Defocus Detection, Fog Detection, Virtual Line, Enter / Exit, (Dis)Appear, Audio detection, Face detection, Motion detection, Sound Classification |
| Alarm I/O |
Input 1ea / Output 1ea |
| Alarm Triggers |
Alarm Input, Motion detection, Video & Audio Analytics, Network disconnect |
| Alarm Events |
File Upload Via FTP, E-mail, Notification via e-mail, Local Storage (SD / SDHC / SDXC) or NAS recording at event triggers, External output, Preset |
| Pixel Counter |
Support |
| Network |
| Ethernet |
RJ-45 (10 / 100 BASE-T) |
| Video Compression Format |
H.265 / H.264 (MPEG-4 part 10/AVC) : Main / Baseline / High, MJPEG |
| Resolution |
1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 448, 720 x 576, 720 x 480, 640 x 480, 640 x 360, 320 x 240 |
| Max. Framerate |
H.265 / H.264 : Max. 60fps at all resolutions, MJPEG : Max. 30fps at all resolutions |
| Smart Codec |
Manual Mode (Area-Based : 5ea) |
| WiseStreamII |
Support |
| Video Quality Adjustment |
H.265 / H.264 : MJPEG : Target bitrate level control |
| Bitrate Control Method |
H.265 / H.264 : CBR or VBR, MJPEG : VBR |
| Streaming Capability |
Multiple streaming (Up to 10 Profiles) |
| Audio In |
Selectable (Mic in / Line in), Supply Voltage : 2.5V DC (4mA), Input Impedance : Approx. 2K Ohm |
| Audio Out |
Line Out (3.5mm Mono Jack), Max Output Level: 1 Vrms |
| Audio Compression Format |
G.711 u-law/G.726 Selectable, G.726 (ADPCM) 8KHz, G.711 8KHz
G.726 : 16Kbps, 24Kbps, 32Kbps, 40Kbps, AAC-LC : 48Kbps at 16KHz |
| Audio Communication |
Bi-directional (2-way) |
| IP |
IPv4, IPv6 |
| Protocol |
TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3 (MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
| Security |
HTTPS (SSL) Login Authentication, Digest Login Authentication
IP address filtering, User access log, 802.1X Authentication (EAP-TLS, EAP-LEAP) |
| Streaming Method |
Unicast / Multicast |
| Max. User Access |
20 Users at Unicast Mode |
| Edge Storage |
SD / SDHC / SDXC 2Slot (Up to 512GB) - Continuous Recording (1st Slot to 2nd Slot)
- Motion Images recorded in the SD / SDHC / SDXC Memory Card Can be Downloaded.
NAS (Network Attached Storage), Local PC for Instant Recording |
| Application Programming Interface |
ONVIF Profile S/G, SUNAPI 2.0 (HTTP API), Wisenet Open Platform |
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Web Viewer |
Supported OS : Windows 7, 8.1, 10, Mac OS X 10.10. 10.11 10.12
Non-Plugin Web Viewer
Supported Browser : Google Chrome 56, MS Edge 39, Mozilla Firefox 49
(Window 64bit only), Apple Safari 10 (Mac OS X only)
Plug-in Web Viewer
Supported Browser : MS Explore 11, Apple Safari 10 (Mac OS X only) |
| Central Management Software |
SmartViewer |
| Environmental |
| Operating Temperature / Humidity |
-40°C ~ +55°C (-40°F ~ +131°F) / Less than 90% RH
* Start up should be done at above -35°C (-31°F) |
| Storage Temperature / Humidity |
-50°C ~ +60°C (-58°F ~ +140°F) / Less than 90% RH |
| Ingress Protection / Vandal Resistance |
IP67, IP66, NEMA 4X / IK10 |
| Electrical |
| Input Voltage / Current |
24V AC, 12V DC, PoE (IEEE802.3af Class3) |
| Power Consumption |
24V AC : Max 14W, 12V DC : Max 11.5W, PoE : Max 12.95W |
| Mechanical |
| Color / Material |
Ivory / Aluminum |
| Dimensions (WxH) |
Ø160 x 128.45mm (Ø6.30" x 5.06") |
| Weight |
995g (2.19 lb) |
