Video |
|
Imaging Device |
1/2.8" CMOS |
Resolution |
1920x1080, 1600x1200, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
Max. Framerate |
H.265/H.264: Max. 120fps/100fps(60Hz/50Hz)(WDR off) Max. 60fps/50fps(60Hz/50Hz)(WDR on) MJPEG: Max. 30fps/25fps(60Hz/50Hz) |
Min. Illumination |
Color: 0.03Lux(F1.6, 1/30sec, 30IRE) B/W : 0.003Lux(F1.6, 1/30sec, 30IRE), 0Lux(IR LED on), 30/25fps Color: 0.06Lux(F1.6, 1/60sec, 30IRE) B/W : 0.006Lux(F1.6, 1/60sec, 30IRE), 0Lux(IR LED on), 60/50fps Color: 0.12Lux(F1.6, 1/120sec, 30IRE) B/W : 0.012Lux(F1.6, 1/120sec, 30IRE), 0Lux(IR LED on), 120/100fps |
Video Out |
CVBS : 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P), for installation USB : Micro USB type B, 1280x720 for installation |
Lens |
Focal Length (Zoom Ratio) |
5.2~62.4mm(12x) zoom (digital 32x, total 384x zoom) |
Max. Aperture Ratio |
F1.6(Wide) - F3.0(Tele) |
Angular Field of View |
H: 54.58˚(Wide)~5.30˚(Tele) V: 32.19˚(Wide)~3.00˚(Tele) |
Min. Object Distance |
1.5m(4.92ft) |
Focus Control |
Oneshot AF, Focus save |
Lens Type |
DC auto iris |
Pan / Tilt / Rotate |
Sequence |
Preset(300ea) |
Operational |
Camera Title |
Displayed up to 85 characters |
Day & Night |
Auto(ICR)/Color/BW/Schedule |
Backlight Compensation |
BLC, HLC, WDR, SSDR |
Wide Dynamic Range |
extremeWDR(150dB) |
Digital Noise Reduction |
WiseNRⅡ(Based on AI engine), SSNRⅤ |
Digital Image Stabilization |
Support(built-in gyro sensor) |
Defog |
Support |
Motion Detection |
8ea, 8point Polygonal zones |
Privacy Masking |
32ea, 4point Quadrangle zones - Color : Gray, Green, Red, Blue, Black, White - Mosaic |
Gain Control |
Support |
White Balance |
ATW / Narrow ATW / AWC / Manual / Indoor / Outdoor |
LDC |
Support (Fill/stretch mode) |
Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2~1/12,000sec) prefer shutter control(Based on AI engine) |
Video Rotation |
Flip, Mirror, Hallway view(90°/270°) |
Analytics |
Classified object type : Person/Face/Vehicle/License plate Attributes : Vehicle(Type:car/bus/truck/motorcycle/bicycle) Analytics events based on AI engine - Object detection, Virtual line*(Crossing/Direction), Virtual area*(Loitering/Intrusion/Enter/Exit) Analytics events - Defocus detection, Motion detection, Tampering, Fog detection, Audio detection, Sound classification, Shock detection, Virtual area(Appear/Disappear) * Some of the video analytics only works with people and vehicle detection |
Alarm I/O |
2 configurable I/O ports, DC 12V output(Max. 50mA) |
Alarm Triggers |
Analytics, Network disconnect, Alarm input, App event, Time schedule |
Alarm Events |
When alarm trigger occurred - File upload(image) : e-mail/FTP - Notification : e-mail - Recording : SD/SDHC/SDXC or NAS recording at event triggers - Alarm output - Handover(PTZ preset, Send message by HTTP/HTTPS/TCP) - Audio clip playback |
Audio In |
Selectable(mic in/line in) Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
Audio Out |
Line out, Max.output level: 1Vrms |
IR Viewable Length |
WiseIR 90m(295.28ft) |
Network |
Ethernet |
Metal shielded RJ-45(10/100/1000BASE-T) |
Video Compression |
H.265/H.264: Main/High, MJPEG |
Audio Compression |
G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps AAC-LC: 48Kbps at 16KHz |
Smart Codec |
Manual(5ea area), WiseStreamⅡ, WiseStreamⅢ(Based on AI engine) |
Bitrate Control |
H.264/H.265: CBR or VBR MJPEG: VBR |
Streaming |
Unicast(20 users) / Multicast Multiple streaming(Up to 10 profiles) |
Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast) |
Security |
TPM 2.0 (FIPS 140-2 level 2) HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2) Device Certificate(Hanwha Techwin Root CA, pre-installed) Secure by default certificate Secure OS/Boot/Storage, Verify firmware forgery |
Application Programming Interface |
ONVIF Profile S/G/T/M SUNAPI(HTTP API) Wisenet open platform |
General |
Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish,, Portuguese, Czech, Polish, Turkish, Dutch, Greek, Hungarian |
Edge Storage |
Micro SD/SDHC/SDXC 2slot Max. 1TB (512GB * 2) |
Memory |
2GB RAM, 512MB Flash |
Environmental & Electrical |
Operating Temperature / Humidity |
-40°C~+60°C(-40°F ~ +140°F) / Less than 95% RH(Non-condensing) * Start up should be done at above -30°C Maximum Temperature based on NEMA-TS 2(2.2.7) : +74°C(+165°F) Humidity control /w GORE vent |
Storage Temperature / Humidity |
-50°C~+60°C (-58°F~+140°F) / Less than 95% RH(Non-condensing) |
Certification |
IP66/67, IK10, NEMA4X, NEMA-TS 2(2.2.8, 2.2.9) |
Input Voltage |
PoE+(IEEE802.3at, Class4), 12VDC |
Power Consumption |
PoE+: Max 19.5W, typical 15.5W 12VDC: Max 16.5W, typical 13.1W Power redundancy failover |
Mechanical |
Color / Material |
White / Aluminum Hard-coated window |
RAL Code |
RAL9003 |
Product Dimensions / Weight |
Ø93.4x298.4mm(3.68"x11.75") / 2300g(5.07 lb) |
Compatible Conduit hole / Gangbox |
3/4" (M25) single, double, 4" octagon, 4" square |
DORI (EN62676-4 standard) |
Detect (25PPM/ 8PPF) |
Wide: 74.4m(244.19ft) / Tele: 829.7m(2721.97ft) |
Observe (63PPM/ 19PPF) |
Wide: 29.8m(97.68ft) / Tele: 331.9m(1088.79ft) |
Recognize (125PPM/ 38PPF) |
Wide: 14.9m(48.84ft) / Tele: 165.9m(544.39ft) |
Identify (250PPM/ 76PPF) |
Wide: 7.4m(24.42ft) / Tele: 83.0m(272.20ft) |
