Video |
|
Imaging Device |
1/2.3" 12MP CMOS |
Resolution |
Original view(1:1): 3008x3008~480x480, Double panorama(2:1): 3584x1792~640x320, Single panorama(4:1): 3584x896~640x160, Quad view: 3584x2688~640x480, Q1/Q2/Q3/Q4(4:3): 1792x1344~640x480 |
Max. Framerate |
H.265/H.264: Original view-Max.30fps/25fps@3008x3008(60Hz/50Hz), Double panorama-Max.30fps/25fps@3584x1792(60Hz/50Hz) Single panorama-Max.30fps/25fps@3584x896(60Hz/50Hz) MJPEG: Max.30fps/25fps@1080x1080(60Hz/50Hz) |
NETD |
None |
Pixel Size |
None |
Min. Illumination |
Color: 0.39 Lux (F2.2, 1/30sec), BW : 0Lux(IR LED on) |
Video Out |
CVBS : 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P), for Installation USB: Micro USB Type B, 1280x720 for installation |
Video Transmission Distance |
None |
Lens |
Focal Length (Zoom Ratio) |
1.08mm fixed focal |
Max. Aperture Ratio |
F2.2 |
Angular Field of View |
H: 187° / V: 187° / D: 187° |
Min. Object Distance |
0.5m(1.64ft) |
Focus Control |
Simple focus |
Lens Type |
None |
Mount Type |
None |
Optional Lens |
None |
Pan / Tilt / Rotate |
Pan / Tilt / Rotate Range |
Lens Rotation |
Pan Range |
None |
Pan Speed |
None |
Tilt Range |
None |
Tilt Speed |
None |
Rotate Range |
None |
Sequence |
None |
Preset Accuracy |
None |
Operational |
Camera Title |
Displayed up to 85 characters |
Direction Indicator |
None |
Day & Night |
Auto(ICR) |
Backlight Compensation |
BLC, HLC, WDR, SSDR |
Wide Dynamic Range |
extremeWDR (120dB) |
Digital Noise Reduction |
WiseNRⅡ(Based on AI engine), SSNRⅤ |
Digital Image Stabilization |
None |
Defog |
None |
Motion Detection |
8ea, 8point polygonal zones |
Privacy Masking |
32ea, polygonal zones - Color: Grey/Green/Red/Blue/Black/White - Mosaic |
Gain Control |
Off / Max Gain / Manual |
White Balance |
ATW / Narrow ATW / AWC / Manual / Indoor / Outdoor |
LDC |
None |
Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (1/5~1/12,000sec) Prefer shutter control(Based on AI engine) |
Digital PTZ |
Support(Preset, Group) |
Video Rotation |
Flip, Mirror |
Analytics |
Classified object type : Person/Face/Vehicle/License plate Support DetectionShot Analytics events based on AI engine - Object detection, Virtual line(Crossing/Direction), Virtual area(Loitering/Intrusion/Enter/Exit) Analytics events - Defocus detection, Motion detection, Tampering, Audio detection, Sound classification, Virtual area(Appear/Disappear) |
Business Intelligence |
Based on AI engine : People counting, Queue management, Heatmap |
Serial Interface |
None |
Alarm I/O |
2 configurable I/O ports |
Alarm Triggers |
Analytics, Network disconnect, Alarm input |
Alarm Events |
File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers Alarm output PTZ Preset Handover Audio playback |
Audio Streaming |
None |
Audio In |
Selectable(mic in/line in/built-in mic) Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
Audio Out |
Line out, Max. output level: 1Vrms |
IR Viewable Length |
Wise IR, PoE : 8m(26.25ft), PoE+ : 13m(42.65ft) |
IR Illuminator (Optional) |
None |
IR Radiation angle |
None |
IR LED |
None |
IR Wavelength |
None |
IR Operation |
None |
Water Removal |
None |
Auto Tracking |
None |
Coaxial Protocol |
None |
Color Palettes |
None |
Radiometry |
Temperature Detect Range |
None |
Temperature Accuracy |
None |
Temperature Detection |
None |
Additional |
None |
Network |
Ethernet |
Metal shielded RJ-45(10/100BASE-T) |
Video Compression |
H.265/H.264: Main/Baseline/High, MJPEG |
Audio Compression |
G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps AAC-LC: 48Kbps at 16KHz |
Smart Codec |
Manual(5ea area), WiseStreamⅡ, WiseStreamⅢ(Based on AI engine) |
Video Quality Adjustment |
H.264/H.265: Target bitrate level control MJPEG: Quality level control |
Bitrate Control |
H.264/H.265: CBR or VBR MJPEG: VBR |
Streaming |
Unicast(20 users) / Multicast Multiple streaming(Up to 10 profiles) Up to 5 virtual channel support |
Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast) |
SIP support (VoIP, Peer-to-peer, SIP/PBX integration) |
None |
Security |
TPM 2.0 (FIPS 140-2 level 2) HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2) Device Certificate(Hanwha Techwin Root CA, pre-installed) Secure by default certificate Secure OS/Boot/Storage, Verify firmware forgery |
Application Programming Interface |
ONVIF Profile S/G/T/M SUNAPI(HTTP API) Wisenet open platform |
General |
Webpage Language |
None |
Web Viewer |
None |
Edge Storage |
Micro SD/SDHC/SDXC 2slot 1TB(512GBx2) |
Memory |
4096MB RAM, 512MB Flash |
Environmental & Electrical |
Operating Temperature / Humidity |
-40°C ~ +60°C (-40°F ~ +140°F) / Less than 95% RH POE+ Mode 55°C (Hysteresis 5°C) Wise IR 8m(26.25ft) |
Storage Temperature / Humidity |
-50°C ~ +60°C(-58°F ~ +140°F) / Less than 95% RH |
Certification |
IP66, IK10, NEMA4X |
Input Voltage |
PoE(IEEE802.3af, Class3), PoE+, 12VDC |
Power Consumption |
PoE: Max 12.95W, typical 9.4W, 12VDC: Max 12.9W, typical 9.0W PoE+: Max 23.0W, typical 9.4W, 12VDC: Max 22.0W, typical 9.0W |
Mechanical |
Color / Material |
White / Aluminum, Hard-coated dome bubble |
RAL Code |
RAL9003 |
Product Dimensions / Weight |
Ø160x72mm(6.23x2.84"), 1,170g (2.58lb) |
Compatible Conduit hole / Gangbox |
None |
Hanging Mount (Dome) |
SBP-167HMW |
Skin Cover |
SBC-160BF |
Skin Cover (Dome) |
None |
Weather Cap (Dome) |
None |
Power Module |
None |
Backbox |
None |
Certifications & Standards |
Network |
None |
EMC |
FCC 47 CFR 15 Subpart B Class A ICES-3(A)/NMB-3(A) CE/UKCA - EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3 VCCI CISPR 32 Class A RCM AS/NZS CISPR 32 Class A KS C 9832 Class A , KS C 9835 |
Safety |
UL 62368-1, CAN/CSA C22.2 NO. 62368-1 IEC/EN 62471 |
Environment |
IEC/EN 63000 IEC 60529 IP66, IEC 62262 IK10 NEMA 250 type 4X |
Video |
None |
DORI (EN62676-4 standard) |
Detect (25PPM/ 8PPF) |
34.9m(114.49ft) |
Observe (63PPM/ 19PPF) |
13.9m(45.60ft) |
Recognize (125PPM/ 38PPF) |
7.0m(22.96ft) |
Identify (250PPM/ 76PPF) |
3.5m(11.48ft) |
LPR/ANPR/MMCR |
Speed Description |
None |
Speed limit |
None |
Min. Forward Distance |
None |
Max. Forward Distance |
None |
Max. Horizontal Angle |
None |
Max. Vertical Angle |
None |
Horizontal Offset |
None |
Camera Height |
None |
Lane Coverage |
None |
Vehicle Recognition |
None |
Available Countries |
None |
Wisenet Road AI LPR/ANPR/MMCR |
Solution |
None |
Speed Description |
None |
Lane Coverage |
None |
Speed limit |
None |
Min. Forward Distance |
None |
Max. Forward Distance |
None |
Max. Horizontal Angle |
None |
Max. Vertical Angle |
None |
Horizontal Offset |
None |
Camera Height |
None |
Vehicle Recognition |
None |
Available Countries |
None |
