Ethernet |
RJ45 (10/100Base-T) |
Video Compression Format |
H.265 / H.264 (MPEG-4 part 10/AVC): Main / Baseline / High, MJPEG |
Resolution |
1920 x 1080, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 448, 720 x 576, 720 x 480, 640 x 480, 640 x 360, 320 x 240 |
Frame Rate |
H.265 / H.264: Maximum 60 fps at all resolutions
MJPEG: Maximum 30 fps |
Smart Codec |
Manual mode (Area-based: 5)
WiseStream II |
Video Quality Adjustment |
H.265 / H.264: Target bit rate level control
MJPEG: Target bit rate level control |
Bit Rate Control |
H.265 / H.264: CBR or VBR, MJPEG: VBR |
Streaming Capability |
Multiple streaming (up to 10 profiles) |
Audio In |
Selectable (Mic in / Line in), Maximum Output Level: 1 Vrms
Supply Voltage: 2.5 VDC (4 mA)
Input Impedance: Approximately 2 kOhms |
Audio Out |
Line out, Maximum Output Level: 1 Vrms |
Audio Compression Format |
G.711 u-law/G.726 selectable, G.726 (ADPCM) 8 kHz, G.711 8 kHz
G.726: 16 kbps, 24 kbps, 32 kbps, 40 kbps, AAC-LC: 48 kbps at 8/16/32/48 kHz |
Audio Communication |
Bi-directional (2-way) |
IP |
IPv4, IPv6 |
Protocols |
TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
Security |
HTTPS (SSL) login authentication, Digest login authentication, IP address filtering, User access log, 802.1X authentication (EAP-TLS, EAP-LEAP) |
Streaming Method |
Unicast / Multicast |
Maximum User Access |
20 users at unicast mode |
Edge Storage |
2 x SD/SDHC/SDXC slots (Up to 512 GB)
Continuous recording (1st slot to 2nd slot)
NAS (Network Attached Storage), Local PC for instant recording |
Application Programming Interface |
ONVIF profile S/G, SUNAPI (HTTP API), Wisenet Open Platform |
Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
Web Viewer |
Supported OS: Windows 7, 8.1, 10 / Mac OS X 10.10, 10.11, 10.12
Non-plugin Webviewer: Supported Browser: Google Chrome 54, MS Edge 38, Mozilla Firefox 49 (Windows 64-bit only), Apple Safari 9
Mac OS X only
Plugin Webviewer: Supported Browser: MS Explore 11, Apple Safari 9
Mac OS X only |
CMS |
SmartViewer, SSM |
