Alarm Events |
File upload via FTP and e-mail Notification via e-mail
NAS recording at event triggers Alarm output
PTZ Preset
|
Audio In |
Selectable(mic in/line in)
Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm
|
Audio Out |
Line out, Max.output level: 1Vrms |
Water Removal |
Support (with Wiper) |
Network |
Ethernet |
RJ-45 (10/100BASE-T) |
Video Compression |
H.265/H.264: Main/Baseline/High, MJPEG |
Audio Compression |
G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps AAC-LC: 48Kbps at 16KHz
|
Smart Codec |
Manual(5ea area), WiseStreamⅡ |
Bitrate Control |
H.264/H.265: CBR or VBR MJPEG: VBR |
Streaming |
Unicast(20 users) / Multicast Multiple streaming(Up to 10 profiles) |
Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM,
UPnP, Bonjour
|
Security |
HTTPS(SSL) login authentication Digest login authentication
IP address filtering User access log
802.1X authentication(EAP-TLS, EAP-LEAP)
|
Application Programming Interface |
ONVIF Profile S/G/T SUNAPI(HTTP API)
Wisenet open platform
|
General |
Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
Memory |
1024MB RAM, 256MB Flash |
Environmental & Electrical |
Operating Temperature / Humidity |
-40°C~+60°C(-40°F ~ +140°F) / Less than 95% RH |
Storage Temperature / Humidity |
-30°C~+60°C(-22°F ~ +140°F) / Less than 95% RH |
Certification |
IECEx, ATEX, KCs, KC, CE IP67, IK10 |
Input Voltage |
24VAC |
Power Consumption |
24VAC: Max. 99W |
Mechanical |
Color / Material |
Metalic Silver / Stainless 316L |
