Video |
|
Imaging Device |
1/2" CMOS |
Resolution |
1920x1080, 1280x1024,1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360 |
Max. Framerate |
H.265/H.264: Max. 60/50fps(60Hz/50Hz, AI analytics on), Max. 120/100fps(60Hz/50Hz, AI analytics off) MJPEG: Max. 15fps/12fps(60Hz/50Hz) |
NETD |
None |
Pixel Size |
None |
Min. Illumination |
Color: 0.007Lux(F1.3, 1/30sec, 30IRE) B/W : 0.0007Lux(F1.3, 1/30sec, 30IRE), 0Lux(IR LED on), 30/25fps Color: 0.014Lux(F1.3, 1/60sec, 30IRE) B/W : 0.0014Lux(F1.3, 1/60sec, 30IRE), 0Lux(IR LED on), 60/50fps Color: 0.028Lux(F1.3, 1/120sec,30IRE) B/W : 0.0028Lux(F1.3, 1/120sec, 30IRE), 0Lux(IR LED on), 120/100fps |
Video Out |
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation USB: Micro USB Type B, 1280x720 for installation |
Video Transmission Distance |
None |
Lens |
Focal Length (Zoom Ratio) |
4.38~9.33mm(2.13x) motorized varifocal |
Max. Aperture Ratio |
F1.3(Wide)~F2.15(Tele) |
Angular Field of View |
H:103.1°(Wide)~44.5°(Tele) / V:54.2°(Wide)~24.9°(Tele) / D:124°(Wide)~51.1°(Tele) |
Min. Object Distance |
0.5m(1.64ft) |
Focus Control |
Simple focus |
Lens Type |
P iris |
Mount Type |
None |
Optional Lens |
None |
Pan / Tilt / Rotate |
Pan / Tilt / Rotate Range |
0˚~360˚ / -45˚~85˚ / 0˚~355˚ |
Pan Range |
None |
Pan Speed |
None |
Tilt Range |
None |
Tilt Speed |
None |
Rotate Range |
None |
Sequence |
None |
Preset Accuracy |
None |
Operational |
Camera Title |
Displayed up to 85 characters |
Direction Indicator |
None |
Day & Night |
Auto(ICR) |
Backlight Compensation |
BLC, WDR, SSDR |
Wide Dynamic Range |
120dB |
Digital Noise Reduction |
SSNR, WiseNR Ⅱ(using AI engine) |
Digital Image Stabilization |
Stabilization Support(built-in gyro sensor) |
Defog |
None |
Motion Detection |
8ea, polygonal zones |
Privacy Masking |
6ea, rectangle zones - Color: Gray/Green/Red/Blue/Black/White |
Gain Control |
Low / Middle / High |
White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
LDC |
Support |
Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (1/5~1/12,000sec) Auto prefer shutter control based on AI engine |
Digital PTZ |
None |
Video Rotation |
Flip, Mirror, Hallway view(90˚/270˚) |
Analytics |
Classified object type : Person/Face/Vehicle/License plate Attributes : Person(Gender, Color and Bag), Face(Age, Gender, Mask and Glasses), Vehicle(Type:car/bus/truck/motorcycle/bicycle and Color) Support Bestshot per object Analytics events based on AI engine - Object detection, Virtual line*(Crossing/Direction), Virtual area*(Loitering/Intrusion/Enter/Exit), Face mask detection, Digital auto tracking, Social distancing detection Analytics events - Defocus detection, Motion detection, Tampering, Audio detection, Sound classification, Shock detection, Virtual area(Appear/Disappear) *Some of the video analytics only works with people and vehicle detection |
Business Intelligence |
People counting, Queue management, Heatmap based on AI engine |
Serial Interface |
None |
Alarm I/O |
2 configurable I/O ports, DC 12V output(Max. 50mA) |
Alarm Triggers |
Analytics, Network disconnect, Alarm input |
Alarm Events |
File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers Alarm output Handover Audio playback |
Audio In |
Selectable(mic in/line in) Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
Audio Out |
Line out, Max.output level: 1Vrms |
IR Viewable Length |
40m(131.23ft), Wise IR |
IR Illuminator (Optional) |
None |
Water Removal |
None |
Auto Tracking |
None |
Coaxial Protocol |
None |
Color Palettes |
None |
Radiometry |
Temperature detect range |
None |
Temperature accuracy |
None |
Temperature detection |
None |
Additional |
None |
Network |
Ethernet |
Metal shielded RJ-45(10/100/1000 BASE-T) |
Video Compression |
H.265/H.264: Main/High, MJPEG |
Audio Compression |
G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps AAC-LC: 48Kbps at 16KHz |
Smart Codec |
Manual(5ea area), WiseStreamⅡ, WiseStreamⅢ(using AI engine) |
Video Quality Adjustment |
H.264/H.265: Target bitrate level control MJPEG: Target bitrate level control |
Bitrate Control |
H.264/H.265: CBR or VBR MJPEG: VBR |
Streaming |
Unicast(6 users) / Multicast Multiple streaming(Up to 5 profiles) |
Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP (TCP, UDP Unicast) |
Security |
HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP) Device Certificate(Hanwha Techwin Root CA) TPM with FIPS 140-2 level2 Secure boot, Verify firmware forgery |
Application Programming Interface |
ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform |
General |
Webpage Language |
English, French, German, Spanish, Italian, Chinese, Korean, Russian, Japanese, Swedish, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
Web Viewer |
None |
Edge Storage |
Micro SD/SDHC/SDXC 2slots 512GB |
Memory |
4096MB RAM, 512MB Flash |
Environmental & Electrical |
Operating Temperature / Humidity |
-50°C ~ +55°C(-58°F ~ +131°F) / Less than 90% RH * Start up should be done at above -30°C |
Storage Temperature / Humidity |
-50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH |
Certification |
IP66/IP67/IP6K9K, IK10+, NEMA4X |
Input Voltage |
PoE+(IEEE802.3at), 12VDC |
Power Consumption |
PoE+: Max 19.50W, typical 16.00W 12VDC: Max 17.00W, typical 13.50W |
Mechanical |
Color / Material |
White / Aluminum, Hard-coated dome bubble |
RAL Code |
RAL9003 |
Product dimensions / weight |
Ø180x125mm(7.09x4.92"), Weight : 1.90Kg (4.19lb) |
Compatible Conduit hole / Gangbox |
3/4"(M25) Single, Double, 4"Octagon, Square |
Hanging mount(Dome) |
SBP-187HMW |
Skin cover(Dome) |
SBC-180B(Black), SPB-VAN85W(Smoke dome cover) |
Weather cap(Dome) |
None |
Power module |
None |
Backbox |
None |
DORI (EN62676-4 standard) |
Detect (25PPM/ 8PPF) |
Wide: 30.5m(100.03ft) / Tele: 93.9m(307.95ft) |
Observe (63PPM/ 19PPF) |
Wide: 12.2m(40.01ft) / Tele: 37.5m(123.18ft) |
Recognize (125PPM/ 38PPF) |
Wide: 6.1m(20.01ft) / Tele: 18.8m(61.59ft) |
Identify (250PPM/ 76PPF) |
Wide: 3.0m(10.00ft) / Tele: 9.4m(30.79ft) |
