Video |
Imaging Device |
1/1.8" 6MP CMOS |
Resolution |
2560x1920, 2560x1440, 1920x1080, 1600x1200, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz) MJPEG: Max. 30fps/25fps(60Hz/50Hz) |
NETD |
None |
Pixel Size |
None |
Min. Illumination |
Color: 0.07Lux(F1.3, 1/30sec) BW: 0Lux(IR LED) |
Video Out |
CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation USB: Micro USB Type B, 1280x720 for installation |
Video Transmission Distance |
None |
Lens |
Focal Length (Zoom Ratio) |
3.9~9.4mm(2.4x) motorized varifocal |
Max. Aperture Ratio |
F1.3 |
Angular Field of View |
H: 92.1˚(Wide)~38.7˚(Tele), V: 67.2˚(Wide)~29.0˚(Tele), D: 119.9˚(Wide)~48.6˚(Tele) |
Min. Object Distance |
0.5m(1.64ft) |
Focus Control |
Simple focus |
Lens Type |
DC auto iris, P iris |
Mount Type |
None |
Optional Lens |
None |
Pan / Tilt / Rotate |
Pan / Tilt / Rotate Range |
0˚~360˚ / -45˚~85˚ / 0˚~355˚ |
Pan Range |
None |
Pan Speed |
None |
Tilt Range |
None |
Tilt Speed |
None |
Rotate Range |
None |
Sequence |
None |
Preset Accuracy |
None |
Operational |
Camera Title |
Displayed up to 85 characters |
Direction Indicator |
None |
Day & Night |
Auto(ICR) |
Backlight Compensation |
BLC, HLC, WDR, SSDR |
Wide Dynamic Range |
120dB |
Digital Noise Reduction |
SSNRⅤ |
Digital Image Stabilization |
Support(built-in gyro sensor) |
Defog |
Support |
Motion Detection |
8ea, 8point polygonal zones |
Privacy Masking |
32ea, rectangular zones - Color: Grey/Green/Red/Blue/Black/White - Mosaic |
Gain Control |
Low / Middle / High |
White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
LDC |
Support |
Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2~1/12,000sec) |
Digital PTZ |
None |
Video Rotation |
Flip, Mirror, Hallway view(90˚/270˚) |
Analytics |
Defocus detection, Directional detection, Fog detection, Face detection, Motion detection, Digital auto tracking, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Audio detection, Sound classification, Shock detection |
Business Intelligence |
People counting, Queue management, Heatmap |
Serial Interface |
None |
Alarm I/O |
Input 1ea / Output 1ea |
Alarm Triggers |
Analytics, Network disconnect, Alarm input |
Alarm Events |
File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers Alarm output Handover Audio playback |
Audio In |
Selectable(mic in/line in), Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
Audio Out |
Line out, Max. output level: 1Vrms |
IR Viewable Length |
50m(164.04ft) |
IR Illuminator (Optional) |
None |
Water Removal |
None |
Auto Tracking |
None |
Coaxial Protocol |
None |
Color Palettes |
None |
Radiometry |
Temperature detect range |
None |
Temperature accuracy |
None |
Temperature detection |
None |
Additional |
None |
Network |
Ethernet |
Metal shielded RJ-45(10/100BASE-T) |
Video Compression |
H.265/H.264: Main/Baseline/High, MJPEG |
Audio Compression |
G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps AAC-LC: 48Kbps at 16KHz |
Smart Codec |
Manual(5ea area), WiseStreamⅡ |
Video Quality Adjustment |
None |
Bitrate Control |
H.264/H.265: CBR or VBR MJPEG: VBR |
Streaming |
Unicast(20 users) / Multicast Multiple streaming(Up to 10 profiles) |
Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP, SRTP |
Security |
HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP) Device Certificate(Hanwha Techwin Root CA) |
Application Programming Interface |
ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform |
General |
Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish,, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
Web Viewer |
None |
Edge Storage |
Micro SD/SDHC/SDXC 2slot 512GB |
Memory |
1024MB RAM, 256MB Flash |
Environmental & Electrical |
Operating Temperature / Humidity |
-50°C ~ +60°C (-58°F ~ +140°F) / Less than 90% RH * Start up should be done at above -35°C |
Storage Temperature / Humidity |
-50°C ~ +60°C (-58°F ~ +140°F) / Less than 90% RH |
Certification |
IP66/IP67/IP6K9K, IK10+, NEMA4X |
Input Voltage |
PoE+(IEEE802.3at, Class4) |
Power Consumption |
Max 25.5 W (Main CAM + Extension CAM) Typical 10.2W (Main CAM) * PoE Out: Max 12.95W at 80meters using CAT5/5E cable |
Mechanical |
Color / Material |
White / Aluminum |
RAL Code |
RAL9003 |
Product dimensions / weight |
Ø180x125mm(7.09x4.92"), 1.75kg(3.86 lb) |
Conduit hole |
3/4" |
Hanging mount(Dome) |
SBP-187HM |
Skin cover(Dome) |
SBC-180B |
Weather cap(Dome) |
None |
Power module |
None |
Backbox |
None |
DORI (EN62676-4 standard) |
Detect (25PPM/ 8PPF) |
Wide: 49.4m(162.07ft) / Tele: 146m(479.00ft) |
Observe (63PPM/ 19PPF) |
Wide: 19.7m(64.63ft) / Tele: 58m(190.29ft) |
Recognize (125PPM/ 38PPF) |
Wide: 9.9m(32.48ft) / Tele: 29m(95.14ft) |
Identify (250PPM/ 76PPF) |
Wide: 4.9m(16.08.22ft) / Tele: 15m(49.21ft) |
