Ethernet |
RJ-45(10/100BASE-T) |
Video Compression |
H.265/H.264: Main/Baseline/High, MJPEG |
Resolution |
2560x1920, 2560x1440, 1920x1080, 1600x1200, 1280x1024, 1280x960, 1280x720,
1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
|
Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz) MJPEG: Max. 30fps/25fps(60Hz/50Hz) |
Smart Codec |
Manual(5ea area), WiseStreamⅡ |
Bitrate Control |
H.264/H.265: CBR or VBR MJPEG: VBR |
Streaming |
Unicast(20 users) / Multicast
Multiple streaming(Up to 10 profiles)
|
Audio Compression |
G.711 u-law /G.726 Selectable G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps AAC-LC: 48Kbps at 16KHz
|
Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP, SRTP |
Security |
HTTPS(SSL) Login Authentication Digest Login Authentication
IP Address Filtering User access log
802.1X Authentication(EAP-TLS, EAP-LEAP) Device Certificate(Hanwha Techwin Root CA)
|
Edge Storage |
Micro SD/SDHC/SDXC 2slot 512GB |
Application Programming Interface |
ONVIF Profile S/G/T SUNAPI(HTTP API)
Wisenet open platform
|
Web Viewer |
Supported OS: Windows 8.1, 10, Mac OS X 10.13 Recommended Browser: Google Chrome
Supported Browser: MS Internet Explorer 11, MS Edge, Mozilla Firefox(Windows 64bit only), Apple Safari(Mac OS X only)
|
Memory |
1024MB RAM, 256MB Flash |
