Grandstream Powerful 8 ports FXS Gateway with Gigabit NAT Router - HT818

Description

Description

The HT818 is a powerful 8-port VoIP gateway with 8 FXS ports and an integrated Gigabit NAT router. Built for users looking for a strong analog-to-VoIP converter, it features Grandstream’s market-leading SIP ATA/gateway technology with millions of units successfully deployed worldwide. This powerful gateway carries exceptional voice quality in various application environments, strong encryption with unique security certificate per unit, automated provisioning for volume deployment and device management, and outstanding network performance for enterprise use.

Features

  • Supports 2 SIP profiles and 8 FXS ports
  • Strong AES encryption with security certificate per unit
  • Automated & secure provisioning options using TR069
  • 3-way voice conferencing per port
  • Exceptional voice quality with wide-band HD codec
  • Supports T.38 Fax for reliable Fax-over-IP
  • Supports dual Gigabit network ports
  • High performance NAT router
Datasheet
Tech Specs

Grandstream Powerful 8 ports FXS Gateway with Gigabit NAT Router - HT818

Interfaces
Telephone Interfaces Eight (8) RJ11 FXS ports
Network Interface Two (2) 10/100/1000Mbps RJ45 ports
LED Indicators POWER, LAN, WAN, PHONE1, PHONE2, PHONE3, PHONE4, PHONES, PHONE6,PHONE7, PHONES
Factory Reset Button Yes
Voice, Fax, Modem
Telephony Features Caller ID display or block, call waiting, flash, blind or attended transfer, forward. hold, do not disturb, 3 way conference
Voice Codecs G.711 with Annex I (PLC) and Annex II (VAD/CNG), G.723.1, G.729A/B, G.726, ILBC, OPUS, dynamic jitter buffer, advanced line echo cancellation
Fax over IP T.38 compliant Group 3 Fax Relay up to 14.4kpbs and auto switch to G.711 for Fax Pass through
Short/Long Haul Ring Load 2 REN, up to 1km on 24AWG line
Caller ID Bellcore Type 1 & 2, ETSIL, BT, NTT, and DTMF-based CID
Disconnect Methods Busy Tone, Polarity Reversal/Wink, Loop Current
Signaling
Network Protocols TFTP, SSH, STUN, SIP (RFC3261) SIP over TCP/TLS, SRTP, TR 069
QoS Layer 2 (802.1Q VLAN, SIP/RTP 802.1p) and Layer 3 (ToS, Diffserv, MPLS)
DTMF Method In-audio, RFC2833 and/or SIP INFO
Provisioning and Control HTTP, HTTPS, SSH, TFTP, TR-069, secure and automated provisioning using AES encryption, syslog
Security
Media SRTP
Control TLS/SIPS/HTTPS
Management Syslog support, SSH, remote management using web browser
Physical
Universal Power Supply

Input: 100-240VAC, 50-60Hz

Output: 12V/1.5A
Environmental

Operational: 320-1040F or 0°-40°C

Storage: 140-1400F or -10°-60°C

Humidity: 10-90% Non-condensing
Dimension and Weight

(L)180mm*(W)120mm*(H)36mm

356g
Compliance FCC/CE/RCM

Read more

Grandstream Powerful 8 ports FXS Gateway with Gigabit NAT Router - HT818

Product form

SKU: HT818

$366.60 $349.00 Incl. GST

    • Guaranteed secure & safe checkout.

      paypal
    • FREE Express Courier Shipping for all orders over $100
    • 30-Day Returns Policy
    • Back to Base Australian Warranty & Tech Support
    • Australian Stock, No Grey Import Products

    Product Datasheet

    Description

    Description

    The HT818 is a powerful 8-port VoIP gateway with 8 FXS ports and an integrated Gigabit NAT router. Built for users looking for a strong analog-to-VoIP converter, it features Grandstream’s market-leading SIP ATA/gateway technology with millions of units successfully deployed worldwide. This powerful gateway carries exceptional voice quality in various application environments, strong encryption with unique security certificate per unit, automated provisioning for volume deployment and device management, and outstanding network performance for enterprise use.

    Features

    • Supports 2 SIP profiles and 8 FXS ports
    • Strong AES encryption with security certificate per unit
    • Automated & secure provisioning options using TR069
    • 3-way voice conferencing per port
    • Exceptional voice quality with wide-band HD codec
    • Supports T.38 Fax for reliable Fax-over-IP
    • Supports dual Gigabit network ports
    • High performance NAT router
    Datasheet
    Tech Specs

    Grandstream Powerful 8 ports FXS Gateway with Gigabit NAT Router - HT818

    Interfaces
    Telephone Interfaces Eight (8) RJ11 FXS ports
    Network Interface Two (2) 10/100/1000Mbps RJ45 ports
    LED Indicators POWER, LAN, WAN, PHONE1, PHONE2, PHONE3, PHONE4, PHONES, PHONE6,PHONE7, PHONES
    Factory Reset Button Yes
    Voice, Fax, Modem
    Telephony Features Caller ID display or block, call waiting, flash, blind or attended transfer, forward. hold, do not disturb, 3 way conference
    Voice Codecs G.711 with Annex I (PLC) and Annex II (VAD/CNG), G.723.1, G.729A/B, G.726, ILBC, OPUS, dynamic jitter buffer, advanced line echo cancellation
    Fax over IP T.38 compliant Group 3 Fax Relay up to 14.4kpbs and auto switch to G.711 for Fax Pass through
    Short/Long Haul Ring Load 2 REN, up to 1km on 24AWG line
    Caller ID Bellcore Type 1 & 2, ETSIL, BT, NTT, and DTMF-based CID
    Disconnect Methods Busy Tone, Polarity Reversal/Wink, Loop Current
    Signaling
    Network Protocols TFTP, SSH, STUN, SIP (RFC3261) SIP over TCP/TLS, SRTP, TR 069
    QoS Layer 2 (802.1Q VLAN, SIP/RTP 802.1p) and Layer 3 (ToS, Diffserv, MPLS)
    DTMF Method In-audio, RFC2833 and/or SIP INFO
    Provisioning and Control HTTP, HTTPS, SSH, TFTP, TR-069, secure and automated provisioning using AES encryption, syslog
    Security
    Media SRTP
    Control TLS/SIPS/HTTPS
    Management Syslog support, SSH, remote management using web browser
    Physical
    Universal Power Supply

    Input: 100-240VAC, 50-60Hz

    Output: 12V/1.5A
    Environmental

    Operational: 320-1040F or 0°-40°C

    Storage: 140-1400F or -10°-60°C

    Humidity: 10-90% Non-condensing
    Dimension and Weight

    (L)180mm*(W)120mm*(H)36mm

    356g
    Compliance FCC/CE/RCM

    Read more
