| Wi-Fi Standards |
IEEE 802.11 a/b/g/n/ac |
| Antennas |
Two 5G & two double frequency internal antennas
2.4GHz, gain 3dBi;
5GHz, gain 5dBi |
| Wi-Fi Data Rates |
5G:
IEEE 802.11ac: 6.5 Mbps to 1733 Mbps IEEE 802.11n: 6.5Mbps to 600Mbps
IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
2.4G:
IEEE 802.11n: 6.5Mbps to 300Mbps
IEEE 802.11b: 1, 2, 5.5, 11 Mbps
IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
*Actual throughput may vary depending on many factors including environmental conditions, distance between
devices, radio interference in the operating environment and mix of devices in the network |
| Frequency Bands |
2.4GHz Radio: 2412 - 2484 MHz
5GHz Radio: 5180 - 5825 MHz
*Not all frequency bands can be used in all regions |
| Channel Bandwidth |
2.4G: 20 and 40 MHz
5G: 20, 40 and 80 MHz |
| Wi-Fi and System Security |
WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical
data/control lockdown via digital signatures, unique security certificate and random default password
per device |
| MIMO |
2×2:2 2.4GHz(MIMO)
4×4:4 5GHz(MU-MIMO) |
| Coverage Range |
Up to 100 meters
*coverage range can vary based on environment |
| Maximum TX Power |
2.4G: 23dBm
5G: 25dBm
*Maximum power varies by country, frequency band and MCS rate |
| Receiver Sensitivity |
5G
802.11a: -92dBm @6Mbps, -74dBm @54Mbps;
802.11n 20MHz: -74dBm @MCS7; 802.11n 40MHz:-71dBm @MCS7
802.11ac 20MHz: -67dBm@MCS8; 802.11ac: HT40:- 63dBm @MCS9; 802.11ac 80MHz: -59dBm @MCS9
2.4G
802.11b: -96dBm@1Mbps, -88dBm@11Mbps;
802.11g: -93dBm @6Mbps, -75dBm@54Mbps;
802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz:-70dBm @MCS7 |
