Tech Specs
System |
Main Processor |
Embedded Processor |
Internet Protocol |
IPv4; RTSP; RTP; TCP; UDP; P2P |
OSDP Protocol |
Support |
Interoperability |
CGI |
SDK |
Support |
Basic |
Display |
4.3 inch TFT screen |
Screen Type |
Capacitive touch screen |
Screen Resolution |
480 × 272 |
Camera |
2MP CMOS high definition camera |
WDR |
DWDR |
Light Compensation |
Auto white light Auto IR light |
Voice Prompt |
Support |
Casing |
PC Metal rear case |
Function |
Unlock Mode |
Card/Password/Face unlock and unlock through their combinations |
Card Reading Type |
IC card |
Period List |
128 |
Holiday Period |
128 |
First-Card Unlock |
Support |
Remote Verification |
Support |
Peripheral Card Reader |
1 RS-485 1 Wiegand |
Multiple User Unlock |
Support |
Real-Time Surveillance |
Support |
Web Configuration |
Support |
Performance |
Face Recognition Height |
0.9 m–2.4 m |
Face Recognition Distance |
0.3 m–1.5 m |
Face Verification Accuracy |
99.50% |
Face Recognition Time |
0.3 s |
Capacity |
User Capacity |
6,000 |
Face Image Capacity |
6,000 |
Card Capacity |
6,000 |
Password Capacity |
6,000 |
Record Capacity |
150,000 |
Port |
RS-485 |
1 |
Wiegand |
1 |
USB |
1 × USB2.0 port |
Network |
1 × RJ-45 10/100 Mbps self-adaption |
Alarm Input |
1 |
Alarm Linkage |
Support |
Exit Button |
1 |
Door Status Detection |
1 |
Lock Control |
1 |
Alarm |
Anti-Passback |
Support |
Tamper |
Support |
Duress |
Support |
Door Sensor Timeout |
Support |
Intrusion |
Support |
Illegal Card Exceeding Threshold |
Support |
General |
Power Supply Mode |
12V DC, 2A |
Protection Grade |
IP65 (Apply silica gel to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick startguide.) |
Power Consumption |
≤ 24W |
Product Dimensions |
174.0 mm × 87.5 mm × 22.5 mm
(6.85" × 3.44" × 0.88" ) (H × W × D)
|
Working Temperature |
–30°C to 60°C (–22°F to 140°F) |
Working Humidity |
5%RH–95%RH (non-condensing) |
Working Environment |
Indoor Outdoor |
Gross Weight |
0.78 kg (1.72 lb) |
Accessory |
Bracket (provided) |
Installation Method |
Surface mount |
Certification |
CE FCC |
