System |
Main Processor |
Embedded Processor |
Operating System |
Embedded operating system |
Network Protocol |
IPv4; UDP; DNS; TCP |
Basic |
Screen Type |
Capacitive Touchscreen |
Display Screen |
7" TFT |
Screen Resolution |
1024 (H) × 600 (V) |
Audio Compression |
G.711a; G.711u; PCM |
Audio Input |
1 |
Audio Output |
Built-in speaker |
Audio Mode |
Two-way audio with VTO (half–duplex);Two-way audio with app (full–duplex) |
Audio Enhancement |
Echo suppression/digital noise reduction |
Audio Bit Rate |
16KHz;16 Bit |
Function |
Leave Videos |
Yes (SD card needed) |
DND Mode |
Do not disturb period can be set; Do not disturb mode can be set. |
Number of Extensions |
5 |
Wi-Fi |
Yes |
Wireless Standard |
IEEE802.11b/802.11g/802.11n |
Wireless Frequency Range |
2.4 GHz |
Storage |
Micro SD card (up to 64 GB) |
Port |
RS-485 |
1 |
Alarm Input |
6 |
Alarm Output |
1 |
Power Output |
1 (12 V, 200 mA) |
Door Bell |
Yes (use the alarm input port) |
Performance |
Casing Material |
PC + ABS |
General |
Appearance Color |
White |
Power Supply |
2-wire Controller |
Power Adapter |
Optional |
Installation |
Surface Mount |
Certifications |
CE; FCC |
Accessory |
Included: Power cord, 485 and Power output ribbon cable, alarm ribbon cable, bracket, branch terminal
Sold separately: 2-wire controller |
Product Dimensions |
130 mm × 189 mm × 23.9 mm (5.12" × 7.44" × 0.94") |
Operating Temperature |
–10 °C to +55 °C (14 °F to +131 °F) |
Operating Humidity |
10%–95% (RH) |
Operating Altitude |
0 m–3000 m (0 ft – 9842.52 ft) |
Power Consumption |
≤ 2.5 W (standby), ≤ 10 W(working) |
Gross Weight |
0.633 kg (1.40 lb) |
Storage Temperature |
–40 °C to +70 °C (–40 °F to +158 °F) |
Storage Humidity |
95% (RH), (non-condensing) |
