| SMD Plus |
| SMD Plus by Recorder |
32-channel: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change |
| SMD Plus by Camera |
64 channels |
| Video Metadata |
Metadata Performance
of AI by Recorder
(Number of Channels) |
8 channels |
Metadata Performance
of AI by Camera
(Number of Channels) |
32 channels |
| Human Attributes |
Top color, top type, hat, bag, age, gender and umbrella |
| Motor Vehicle Attributes |
License plate, plate color, vehicle model, vehicle logo, plate color, ornament, calling, |
Non-motor Vehicle
Attributes |
Vehicle model, vehicle color, number of persons, helmet. |
| Vehicle License Plate Comparison |
ANPR by Camera
(Number of Channels) |
32 channels |
License Plate Database
Capacity |
Blocklist and allowlist: 20,000 |
| Audio and Video |
| Access Channel |
128 channels |
| Network Bandwidth |
AI disabled: 1024 Mbps incoming, 1024 Mbps recording and 800 Mbps outgoing AI-enabled: 512 Mbps incoming, 512 Mbps recording and
400 Mbps outgoing |
| Resolution |
32 MP; 24 MP; 16 MP; 12 MP; 8 MP; 5 MP; 4 MP; 1080p; 720p; D1 |
| Decoding Capability |
2-channel 32 MP@30 fps; 2-channel 24 MP@30 fps; 4-channel 16 MP@30 fps; 8-channel 8 MP@30 fps; 16-channel 4 MP@30 fps; 32-channel 1080p@30 fps; 72-channel 720P@30 fps 160-channel D1@30 fps |
| Video Output |
2-channel VGA, 4-channel HDMI video output.
Simultaneous mode:
max. resolution of VGA1 and VGA2 is 1080p,
max. resolution of HDMI1 and HDMI2 is 4K
max. resolution of HDMI3 is 8K
max. resolution of HDMI4 is1080p
Heterogeneous mode:
Simultaneous video source output for VGA1 and HDMI1
Simultaneous video source output for VGA2 and HDMI2
max. resolution of VGA1 and VGA2 is 1080p,
max. resolution of HDMI1, HDMI2 and HDMI3 is 4K
max. resolution of HDMI4 is 1080p |
| Multi-screen Display |
Main screen: 1/4/8/9/16/25/36/64
Sub screen: 1/4/8/9/16/25/36 |
Third-party Camera
Access |
ONVIF; RTSP; Sony; Axis; Arecont; Pelco; Canon; Samsung |
