| Physical & Power |
|
- Button: 1 call button
- Camera: 2M Pixels, automatic lighting
|
- Ethernet port: RJ45, 10/100Mbps adaptive
|
- Light Sensor: 1
- Relays put: 1
- Inputs: 2
- TF card slot: 1
- Microphone: 1
- Speaker: 1
|
- 802.3af Power-over-Ethernet
|
|
- Installation: Wall mounted
|
|
- 12V DC connector (if not using PoE)
|
- Working Humidity: 10~90%
- Working Temperature: -40°C ~ +60°C
- Storage Temperature: -40°C ~ +70°C
|
- Audio codecs: G.711a, G.711μ, G.722
|
- QoS support: Yes
- QoS support: Yes
|
- Network mode: DHCP or Static IP
- System time: NTP for auto time setting
- Protocols support: IPv4, HTTP, HTTPS, FTP,
DNS, NTP, RTP, TCP, UDP, ICMP, DHCP, ARP
|
| Audio |
- Wideband Audio Codec: G. 722
- SIP v1, (RFC2543), SIP v2 (RFC3261)
- Narrowband audio codec: G.711a, G.711μ
- Wideband Audio Codec: G. 722
- DTMF: In-band, out-of-band DTMF (RFC2833), SIP Info
- Echo Cancellation
- Voice Activation Detection
- Comfort Noise Generator
|
| Video |
- Sensor: 1/2.7", CMOS
- Pixels: CIF, VGA, 4CIF, 720p, 1080p
- Video codec: H.264
- Video Resolution: up to 1920 X 1080
- Max. Image transfer rate: 1080p-25fps
- White LEDs for picture lighting during dark hours
- Compatible to 3rd part video components, e.g. NVRs
|
| Door Entry Feature |
- Relays controlled individually by DTMF tones
- Camera permanently operational
- Auto night mode with LED illumination
- White balance
|
| Network &Protocol |
- Protocols support: IPv4, HTTP, HTTPS, FTP, DNS, NTP, RTSP, RTP, TCP,UDP, ICMP, DHCP, ARP
|
| Deployment &Maintenance |
- Auto-Provisioning
- Web management portal
- Web-based packet dump
- Access able export/ import
- System logs ( include door access logs)
|
| Application Scenario |
- Remote site entry over internet
- Apartment/flat intercom with door access control
|
