Camera Features |
|
Image sensor |
1/3.1" Progressive CMOS |
Resolution |
SD:1280 x 720
HD: 1920 x 1080
|
Lens Types |
Fixed-focal |
Focal Length |
f = 2.8 mm |
Aperture |
F2.0 |
Iris |
Fixed iris |
Field of View |
116° (Horizontal)
65° (Vertical)
140° (Diagonal)
|
Camera Movement |
Pan: ±175° Tilt: -10°~75° |
Shutter Speed |
1/5 sec. to 1/32,000 sec. |
Day/Night |
Yes |
IR Cut Filter |
Yes |
IR Range |
30 meters |
WDR Technology |
WDR Enhanced |
Minimum Illumination |
0.08 lux @ F2.0 (Color)
<0.005 lux @ F2.0 (B/W)
0 lux with IR illumination on
|
Onboard Storage |
MicroSD/SDHC/SDXC card slot
(Built-in 128GB industrial SDCard)
|
Standard Video Settings |
Frame Rate |
15FPS |
Video Streaming Settings |
HD Video 1920 x 1080@15fps 600Kbps upload
SD Video 1280 x 720@15fps 200Kbps upload
|
Standard Audio Settings |
Audio |
One-way Audio |
Interface |
Built-in microphone |
Effective Range |
5 meters |
Power and Network |
Power input |
IEEE 802.3af Class 0 PoE, DC 12V
(Simultaneous Power Redundancy Supported) |
Power Consumption |
PoE:
Max. 6.49W/4W (IR on/off)
DC 12V:
Max. 5.1W/3.4W (IR on/off)
|
Connectivity |
RJ-45 cable connector for 10/100 Mbps PoE network connection |
RTSP |
WebRTC, ARP, DHCP, DNS, HTTP, HTTPS, ICMP, IPv4, IPv6, NTP, QoS (CoS/DSCP), RTSP/RTP/RTCP, SSL, TCP/IP, TLS 1.2, UDP |
Users |
Up to 4 clients
*Live viewing for 4 clients
*live viewing up to 2 clients and playback 2 clients)
|
Security |
Signed firmware
HTTPS/TLS encryption
Video encryption
|
Interface |
10 Base-T/100 Base-TX Ethernet (RJ-45)
*It is highly recommended to use standard CAT5e & CAT6 cables which are compliant with the 3P/ETL standard.
|
General |
Operating Temperature |
Starting Temperature:
-30°C ~ 50°C (-22°F ~ 122°F)
Working Temperature:
-30°C ~ 55°C (-22°F ~ 131°F) (IR off)
-30°C ~ 50°C (-22°F ~ 122°F) (IR on)
|
Humidity |
95% RH (non-condensing) |
Certifications |
EMC: CE (EN55032 Class B,EN55035), FCC (FCC Part 15 Subpart B Class B), ICES-003 issue 7,RCM (AS/NZS CISPR 32 Class B),
VCCI (VCCI-CISPR 32 Class B); Safety: UL (UL 62368-1), CB (IEC/EN 62368-1, IEC/EN 62471,IEC/EN 60950-22); Environment: IK10 (IEC
62262), IP66(IEC 60529)
|
Warranty |
120-month |
Included Accessories |
Quick installation guide, alignment sticker, screw pack, cable gland, dessicant bag |
Mechanical |
Weight |
465g |
Dimensions |
Ø110x85mm |
Body |
Plastic upper cover , Metal bottom |
AI Analytics |
Audio detection |
Yes |
Tampering detection |
Yes |
People Analytics |
Intrusion detection, Line crossing detection,Loitering detection, Scene Search |
Vehicle Analytics |
Intrusion detection, Line crossing detection,Loitering detection, Scene Search |
Object Analytics |
Unattended object detection, Missing object detection |
